the continued evolution of re configurable fpgas for aerospace and defense strategic applications

The Continued Evolution of Re-Configurable FPGAs for Aerospace and Defense Strategic Applications

Howard Bogrow

abstract
Abstract

Present and future aerospace and defense applications continue to demand ever increasing performance, density, and above all flexibility from FPGAs. The Virtex families of re-configurable FPGAs provide the technology to meet these demands. Various members of these families are currently available in both COTs and SMD formats, as well as in radiation tolerant versions. Xilinx is also fully supporting a recently announced software tool that automates the implementation of TMR (Triple Modular Redundancy) into members of these FPGA families for mission critical applications.

Xilinx has received government funding towards the development of a Single Event Immune Re-configurable FPGA (SIRF) with possibly strategic performance. This paper will focus on Xilinx currently available Virtex solutions, while also discussing Xilinx's future development efforts. There will also be some discussion of the various manufacturing flows utilized by Xilinx to address the stringent requirements of current and future space missions, as well as the latest package developments.

xilinx long term commitment to aerospace defense
Xilinx Long-Term Commitment to Aerospace & Defense

1st 90nm Virtex-4 Platform FPGA

Rad tolerant Virtex-II Pro

04

Xilinx on Mars

1st 130nm Virtex-II Pro

SEE Consortium formed

02

1st 150nm Virtex-II Platform FPGA

Rad tolerant Virtex & SPROMs

00

98

Virtex million-gate FPGAs

1st rad tolerant devices

1st 0.35 & 0.25mm FPGAs

QML & ISO9001 certifications

97

95

ISO 9002 certification

91

1st Standard Military Drawing (SMD) released

89

1st device qualified to MIL-STD-883

85

Introduced 1st field programmable gate array (FPGA)

84

Xilinx Founded

1985 1990 1995 2000 2005

Source: Company reports

xilinx technology roadmap

1 year Technology

Leadership

First to 300 mm

First to 90 nm

Xilinx Technology Roadmap

180 nm

Virtex-E

Extended Memory

  • Leading SIA Roadmap
    • 150nm, 130nm and90nm
    • 300mm wafers starting with Virtex-II and Virtex-E
  • First 90nm Spartan-3 family in full production
  • First Virtex-4 devices now shipping

150 nm

Virtex-II

SIA Roadmap

130 nm

Virtex-IIPRO

Virtex-4

90 nm

Spartan-3

65 nm

45 nm

1999

2000

2001

2002

2003

2004

2005

slide5

Aerospace and DefenseVirtex Mil Spec Products

65nm

Next Generation

Virtex-4

90nm

Mil-Temp Space Grades

Virtex-IIPRO

130nm

Mil-Temp Space Grades

Virtex-II

150nm

Mil-Temp Space Grades

180nm

Rad Tolerant

220nm

“Rad by Design” Program

2003 2004 2005 2006

slide6

RadHard By

Design Program

Virtex-II

Virtex-II Pro

Virtex-4

Virtex-II

Virtex-II Pro

Virtex-4

Aerospace and Defense QualificationsClosing the Gap with Commercial

Years from Commercial Production

Qualification

4

XC3000

XQ4000XL

XC4000 XC4000E XQ4000EX

Virtex

3

Virtex-E

XQ4000XL

Virtex

Virtex-E

2

Military Qualification

1

Space Qualification

Program Goals

FPGA Family Generations

virtex 4 asmbl columnar architecture
Virtex-4 ASMBL™ ColumnarArchitecture
  • Virtex 4th Generation advanced FPGA architecture
  • Enables “dial-In” resource allocation mix
    • Logic, DSP, BRAM, I/O, MGT,DCM, PowerPC
  • Enabled by Flip-Chippackaging technology
    • I/O columns distributed throughout the device
slide8

Three Virtex-4 Platforms

LX

FX

SX

Resource

23-55K LCs

14-200K LCs

12-140K LCs

Logic

Memory

DCMs

DSP Slices

SelectIO

RocketIO

PowerPC

Ethernet MAC

2.3-5.7Mb

0.9-6Mb

0.6-10Mb

4-12

4-8

4-20

128-512

32-96

32-192

320-640

240-896

240-960

N/A

N/A

0-24 Channels

N/A

N/A

1 or 2 Cores

N/A

N/A

2 or 4 Cores

DSP

Density

Processor Cores

slide9

Drain

Metal

Connection

Source

Metal

Connection

Gate

Channel

Source

Drain

Process Technology Advances

  • Advanced 90-nm process
  • 11-Layer metallization
    • 10 copper + 1 aluminum
  • New Triple-Oxide Structures
    • Lower quiescent power consumption
  • Benefits:
    • Best cost
    • Highest performance
    • Lowest power
    • Highest density
  • Over 1 million 90 nm FPGAs shipped
dramatic power reduction in virtex 4
Dramatic Power Reduction in Virtex-4
  • Challenges
  • Static power grows with process generations
    • Transistor leakage current
  • Dynamic power grows with frequency
    • P = cv2f

Power Consumption

130 nm FPGAs

Virtex-4 cuts power by 50%

  • Measured 40% lower static power with Triple-Oxide technology

50%

  • 50% lower dynamic power with 90-nm
    • Lower core voltage
    • Less capacitance
  • Up to 10x lower dynamic power with hard IP
    • Integration means fewer transistors per function

Frequency

slide11

TCK

TDO

TDI

TMS

DOUT_BUSY

D[7:0]

DIN

MODE[2:0]

PROG_B

DONE

RDWR_B

CS_B

INIT

CCLK

Virtex-4 Configuration Features

  • Higher configuration speed
    • 100MHz Serial & Parallel interface
    • 66MHz JTAG interface
  • CCLK available to users
  • 256 bit AES security
  • Configuration ECC
  • ICAP and DRP support
  • Dedicated configuration I/O bank
  • Enhanced partial reconfiguration
  • Compatible with previous FPGAs
    • Supports earlier configuration modes
slide12

FPGA Radiation ToleranceTID Trends vs Product/Technology

  • 350nm - XQ4000XL
    • 60 krad (Si)
  • 220nm - XQVR (Virtex)
    • 100 krad (Si)
  • 150nm - XQR2V (Virtex-II)
    • 200 krad (Si)
  • 130nm – XQR2VP
    • 250 krad (Si)
  • 90nm (Preliminary)
    • 300 krad (Si)
  • Process trends*:
  • Gate oxide continues to thin
  • Oxide tunnel currents increase
  • Gate stress voltage decreases

*See “CMOS SCALING, DESIGN PRINCIPLES and HARDENING-BY-

DESIGN METHODOLOGIES” by Ron Lacoe, Aerospace Corp

2003 IEEE NSREC Short Course 2003

see consortium platform fpga test phases

V-4

V-4

V-4

SEE Consortium Platform FPGA Test Phases
  • Parallel Test Approach to accelerate product qualification
  • 3 SEE Consortium Tiger Teams: Fabric, Processor, Serial Transceiver

Dynamic(2Q05)

Mitigation (3Q05)

Special Solutions

Static

(1Q05)

V-2pro

FPGA Fabric and Static Cells

V-2pro

PowerPC Processor & IP

V-2pro

Multi-Gigabit

Serial Transceivers

slide14

Dose Rate Testing

  • Current Test Program
    • XC2VP40
      • Work is funded by MDA
      • Testing is being done by a consortium consisting of AFRL, Crane, Xilinx and Raytheon
      • Initial tests were run July 2004 at Navsea Crane using 60 MeV electron beam source utilized commercial Virtex-IIpro performance board and commercial V-IIpro parts
      • Tests to compare RH (epi) performed in November 2004 at Navsea Crane
      • No upset until > 3.0E8
      • RH (epi) no POR until >1.0E9
      • No Latch-up through >1.0E10
  • Historical Testing
    • XC4036XL
      • Testing was done by Lockheed
      • Testing range of 1.0E7 to 4.0E11 (20 nsec pulse) tested
      • No data upset >1.3E9 to >3.0E9
      • No latch-up beyond 4.0E11
    • XCVR300E
      • Testing done by ITT (MRC)
      • Testing range of 6.3E7 to 3.0E9
      • No upset until > 4.0E8 (non-epi) to >1.0E9 (epi)
      • No latch-up beyond 3.0E9
slide15

TMRTool

  • Software development tool to automatically implement TMR customer designs optimized for Xilinx FPGAs
  • Result of Xilinx/Sandia National Labs partnership
    • Released to Production in Sept 2004
  • Support all design entry methods and HLLs
    • NGO & NGC based input
    • EDIF based output
  • OS Support
    • Windows 2000/XP GUI Support
    • Windows/UNIX PERL Command Line Support
  • Supports ISE 5.2i, 6.1i, 6.2i
slide16

TMRTool Netlist Flow

Xilinx Design Flow

slide17

RadHard by Design Program

SEU Immune Reconfigurable FPGA (SIRF)

Configuration Memory

Control Logic

Logic Fabric

DSP Fabric

Block Memory

Clocking & Clock Mgmt

RocketIO™Multi-Gigabit Transceiver

SelectIO

PowerPC™

Virtex-4Silicon Floorplan

Phase-1: Design Feasibility, Test Chip

Phase-2: Chip Development

Phase-2A: Advanced Features

slide19

Advanced Packaging

  • CG717
    • 35 x 35mm body, 1.27mm pitch, cavity-up
    • Footprint compatible with the BG728
    • Developed for the 2V3000
    • Wire Bond, gold
    • Au-Sn lid (hermetically sealed)
  • CF1144
    • 35 x 35mm body, 1.00mm pitch
    • Footprint compatible with the FF1152
    • Developed for the 2V6000
    • Flipchip with high lead balls, MSL1
summary
Summary
  • Virtex-4 architecture and design methodology enables rapid development of Platform-specific FPGAs with embedded cores
  • Advances in 90nm chip design resulted in optimized performance, lower power, and first-silicon success of Virtex-4
  • SEE Consortium primary vehicle for radiation characterization testing (US and European)
  • Rad Tolerant program will continue with concurrent phase-in of Rad Hard by Design program
  • Advanced packaging and enhanced process flows integral part of overall development efforts
