  1. Extrinsic Semiconductors ECE 2204

  2. Definitions • Intrinsic • Pure • There are an equal number of electrons and holes • Extrinsic • Contains impurities (donors, acceptors, and traps) • The material properties are dominated by the concentration of the impurities and their effect on the crystal • Usually, n ≠ p

  3. Back to the Periodic Table

  4. Column V Atoms Have 5 outer shell electrons

  5. The extra electron on the phosphorous atom is easily removed and becomes a free electron without generating a hole. The phosphorous atom becomes positively charged (ionized).

  6. Back to the Periodic Table (again)

  7. Column III Atoms Have 3 outer shell electrons Missing outer shell electron when compared to Si

  8. The gallium atom ‘steals’ an electron from a neighboring Si atom to complete the four bonds with the surrounding Si atoms, generating a hole at the neighboring Si atom. The boron atom becomes negatively charged (ionized).

  9. n-type Semiconductors • Are doped with donor atoms, which have an extra electron that they donate to the crystal • When the concentration of donor atoms is much greater than the intrinsic carrier concentration, the electron concentration is composed of these donated electrons.

  10. p-type Semiconductors • Are doped with acceptor atoms, which generate holes in the crystal • When the concentration of acceptor atoms is much greater than the intrinsic carrier concentration, the hole concentration is composed of the holes generated by the acceptors.

  11. p-type semiconductor Minority Carrier Concentrations n-type semiconductor

  12. Energy Diagrams EF EF

  13. Resistivity n-type semiconductor p-type semiconductor

  14. Temperature Effects • Unfortunately, the simplification of the equation for resistivity gets rid of its temperature dependence of the resistivity. Why? • (Always blame the intrinsic carrier concentration for temperature effects – it is usually the cause.)
