1. OPS-7: Building and Deploying a Highly Available Application
2. What part is the most important?
3. Agenda Highly Available Application (HAA) what it means today & tomorrow
Definitions
Levels of Recovery
4. HAA What is it? Ensuring complete application availability during the required business time (5-9S)
Meeting Business Needs
Recovery Time Objective (RTO)
Recovery Point Objective (RPO)
Eliminating all Single Point of Failures (SPF)
(While including as many TLAs as possible in one presentation)
5. Where does a Highly Available Application start? Development
Application Development
We will not discuss this
Deployment
Packaging
Installation
Configuration
Management
Configuration
Monitoring
Upgrading
Managing
Development
Application Development
We will not discuss this
Deployment
Packaging
Installation
Configuration
Management
Configuration
Monitoring
Upgrading
Managing
6. What does a HAA look like to the user? The application is always available*
Performance is always acceptable
Data is NEVER lost
New functionality is timely
7. Agenda Highly Available Application ( HAA) what it means today & tomorrow
Definitions
Levels of Recovery
8. Definitions: High Availability (HA)
9. Its all about perspective
10. Definitions: Complete Application User Interface
Middleware (Application Server / Sonic)
Data (database)
Common Infrastructure Dont tie logical structure to physical structure
We dont recommend collapsing the verticleDont tie logical structure to physical structure
We dont recommend collapsing the verticle
11. Definitions: Complete Application An Example User Interface
Middleware (Application Server / Sonic)
Data (database) Dont tie logical structure to physical structure
We dont recommend collapsing the verticleDont tie logical structure to physical structure
We dont recommend collapsing the verticle
12. Definitions: The Example Application 4 Application Configurations
Hosted (single server)
Client Server
N-Tier
SaaS
Explain N-tier first (most difficult) and then move back to the more basic.
I will focus on n-tier for the rest of this presentation because it is the most detailedExplain N-tier first (most difficult) and then move back to the more basic.
I will focus on n-tier for the rest of this presentation because it is the most detailed
13. Logical vs. Physical Outlook
14. Agenda Highly Available Application ( HAA) what it means today & tomorrow
Definitions
Levels of Recovery
15. Levels of Recovery Planning What is the Business Requirement?
Deployability
Maintainability
Upgradability
Supportability
16. Levels of Recovery Level 1: Bicycle Recovery
17. Level 1: Business Case Easiest environment to work in
RTO and RPO < 1 day
Typically
Host-based
Client Server
Development left to the Application Partner (usually)
18. Level 1: Technology Dependence NO RPO or RTO
Have never had an incident
Not using their existing resources
19. Level 1: Technology Choices Backup
Infrastructure
Hardware
Software
Application
Configuration files
Properties files
Where is your recovery location?
20. Level 2: Business case RTO and RPO < 60 minutes
Typically
Host-based
Client-server
N-tier
Development shared between AP and User
Deployment shared as well
21. Level 2: Choosing The Right Tool Which tool would you choose
22. Level 2: Technology Choices After imaging
Replication or clusters
SAN solutions
Recovery offsite?
23. Level 3: Business Case RTO and RPO < 5 minutes
Typically
All Deployment Models (Host-based, Client-server, N-tier, SaaS)
Real-time and near real-time
Large development organization
Deployment important (and difficult)
24. Level 3: Thinking Ahead Of The Game Rick Mears
4 Time Indianapolis 500 winner
6 Times Poll position
11 Times Front row
25. Level 3: Personnel Choices Technical staff Required
Knowledgeable Personnel are key to success
Preparation
Eliminating Human Error!
26. Level 3: Technology Choices Replication
Clusters
SAN solution with complete redundancy
Sonic ESB / CAA
27. Level 3: Technology Choices: Application Availability eliminating SPFs
28. Level 3: Application Server Choices State* is important
Application plays a critical part here!
Load balancing / configuration
What is the perception of the USER?
29. Level 3: Technology Choices: Sonic CAA
30. Level 3: Technology Choices: SaaS Same Rules Apply except Web Server
31. Wrap-up
32. Summary Business Requirements are critical!
Different
Architectures
Levels of recovery
Business Requirements
Solutions
It is the complete process
Development, Deployment, Maintenance
33. For More Information Sonic CAA
http://www.psdn.com
OpenEdge Reference Architecture
http://www.psdn.com/library/kbcategory.jspa?categoryID=230
Disaster Recovery Resources
http://www.attanium.net
http://www.redorbit.com/news/technology/507076/uk_emergency_preparedness_a_step_in_the_right_direction/index.html
http://www.emdat.be
