  1. 《模拟电子技术》 半导体器件SPICE模型

  2. 半导体三极管的SPICE模型 1.双极型晶体管的EM模型和GP模型 Ebers-Moll（即EM）模型和Gummel-Poon（即GP）模型是SPICE中的最常用的双极型晶体管模型。这两种模型均属于物理模型，其模型参数能较好地反映物理本质并且易于测量，便于理解和使用。

  3. 半导体三极管的SPICE模型 半导体三极管的EM模型

  4. 半导体三极管的SPICE模型 半导体三极管的GP模型 GP模型在EM模型上作了改进

  5. 半导体三极管的SPICE模型 半导体三极管部分模型参数在SPICE中的符号名称

  6. 半导体三极管的SPICE模型 半导体三极管2N2222的模型定义： MODEL Q2N2222  NPN(IS=1.87573e-15 BF=153.575NF=0.897646VAF=74  + IKF =0.410821ISE= 3.0484e- 09 NE=4BR=0.1 + NR=1.00903VAR=1.92063IKR=4.10821ISC=1.94183 e-12 + NC=3.92423RB=8.70248IRB=0.1RBM=0.1 + RE=0.111394RC=0.556972XTB=1.76761XTI=1 + EG=1.05CJE=1.67272 e-11VJE=0.83191MJE=0.23 + TF=3.573 e-10XTF=0.941617VTF=9.22508ITF=0.0107017 + CJC=9.98785 e-12VJC=0.760687MJC=0.345235XCJC=0.9 + FC=0.49264CJS=0VJS=0.75MJS=0.5 + TR=3.55487e-06PTF=0KF=0AF=1)

  7. SPICE仿真举例 例 用SPICE画出三极管2N2222的特性曲线 为了测试三极管的输出特性曲， 必须为三极管加上基极电源和集 电极电源，然后同时对基极电流 和集电极电压进行扫描。基极电 流每扫一步，集电极电压扫描一 周，输出集电极电流。下图对三 极管进行测试的电路，电路中 Um=0是为了输出电极电流。

  8. SPICE仿真举例 三极管2N2222的输出特性曲线

  9. SPICE仿真举例 Output Curve of 2N2222 IS 0 1 DC Q 2 1 0 2N2222 Vm 3 2 DC 0 VC 3 0 DC .DC VC 0 12 0.1 Is 0 100m 10m .model 2N2222 NPN (IS=1.87573e－15 BF=53.575 NF=0.897646 VAF=100 ＋ IKF=0.410821 ISE=3.0484e-09 NE=4 BR=0.1 ＋ NR=1.00903 VAR=1.92063 IKR=4.10821 ISC=1.94183e－12 ＋ NC=3.92423 RB=8.70248 IRB=0.1 RBM=0.1 ＋ RE=0.111394 RC=0.556972 XTB=1.76761 XTI=1 ＋ BG=1.05CJE=1.67272c－11 VJE=0.83191 MJE=0.23 ＋ TF=3.573e-10 XTF=0.941617 VTF=9.22508 ITF=0.107017 ＋ CJC=9.98785e-12 VJC=0.760687 MJC=0.345235 XCJC=0.9 ＋ FC=0.49264 CJS=0.75 MJS=0.5 ＋ TR=3.55487e-06 PTF=0 KF=0 KF=0 AF=1) .plot DC I(Vm) .end
