computer engineering tethered car project university of waterloo summer institute 2005

Computer Engineering Tethered Car ProjectUniversity of WaterlooSummer Institute2005

Graham Smyth

smythel@mnsi.net

computer engineering units
Computer Engineering Units

Grades 10 - 12

Five Hands-0n Units

1. Hardware

2. Networking

3. Integrated Circuits

4. Programming

5. Interfaces

slide3

Tethered Vehicle Approach

  • LEDs
  • DC Power Supply
  • Transistors
  • Uni-direction motor
  • Bi-direction motor
  • Single motor vehicle
  • Two motor vehicle
  • Hand built vehicle
  • Additional Features (head lights, tail lights, turn signals, fog lights etc)
slide4

Hardware

  • Computer’s parallelport through D sub connector
  • D sub to interface (transistors, resistors, diodes)
  • Interface to motor (in car)
slide5

Software

Turing

  • parallelput ( number)
  • put parallelget
  • mousewhere ( x, y, click)
  • play (“CDEFG”)
  • drawline ( x1, y1, x2, y2, red)
  • Provincially Licensed
bidirectional motor interfacing hardware
Bidirectional Motor Interfacing Hardware
  • vehicle with DC motor
  • tethering ribbon cable – 2 meters
  • D sub 3 pair wire
  • solid core wire – various, short
  • 2 TIP 31s
  • 2 TIP 42s
  • 1 D sub connector
  • 12 male pins
  • 9 V DC power supply (white is +)
  • 1 breadboard
  • 4 1K resistors (Brown/black/red)
  • 2 diodes (1N401)
  • LEDs
slide7

Breadboard in Detail

Top Rail Connected

Connected

In Fives

Bottom Rail Connected

Divider

slide8

Interfacing System

Unit 5

Computer Interface Peripheral

  • Parallelport
  • Wires
  • Diodes
  • Resistors
  • Transistors
  • Vehicle

Wires

Wires

slide9

Parallelport Pin Configuration(printer port)

Input

I0 – I3

Output

D0 – D7

13 12 11 10 9 8 7 6 5 4 3 2 1

25 24 23 22 21 20 19 18 17 16 15 14

Grounds

18 - 25

Input I4

View from back of Computer

interface wire
Interface Wire

Male Pin

Insulated Wire

Stripped Wire

Crimp Tabs

slide11

Transistor TIP31 & 42Physical Schematic

Emitter Base Collector

(Right Left Middle)

Base Collector Emitter

disassembling tips
Disassembling Tips
  • Leave wire long on remote board
  • Put car on blocks (gears dislodge)
  • Ribbon cable through antenna hole
  • Knot ribbon cable on interior post of car
  • Feed cable through antenna hole
  • carefully strip ribbon cable
ribbon cable configuration
Ribbon Cable Configuration

Wire # FUNCTION

1 Ground

2 Head and spot lights

3 Right rear signal

4 Left rear signal

5 Motor

6 Motor - marked

separate frame halves
Separate Frame Halves

4. Clip 3

3. Clip 2

1. Remove Aerial

2. Clip 1

Spread Clips Carefully

access motor leads
Access Motor Leads

2. Cut Red/Black Wires

3. Strip Black Wire

4. Strip Red Wire

1. Place Upper Body on Lower

attach ribbon cable
Attach Ribbon Cable

1. Strip All Wires

3. Tie Cable to Post

4. Wrap Red Wire

to Ribbon Wire 5

5. Wrap Black Wire

to Ribbon Wire 6

2. Mark 6th Wire

6. Tape Two Motor Wires

replace frame halves
Replace Frame Halves

Snap Body Together

Feed Cable Through Antenna

re attach body
Re-attach Body

2. Feed Cable Through Antenna

3. Re-attach Body with 3 Screws

1. Identify 6th Wire

4. Attach Male Pins to Wire 5 & 6

wiring interface cable
Wiring Interface Cable

1. Attach Male Pins to the Orange/Blue/Green Wires

2. Strip 1cm from the Orange/Blue/Green Wires

d sub
D sub

1. Attach Wiring Harness

2. Insert Blue Wire Into pin 2

4. Insert Green Wire Into pin 18

3. Insert Orange Wire Into pin 3

wiring interface transistors
Wiring Interface: Transistors

TIP42

TIP42

+ White Stripe

-

TIP31

TIP31

wiring interface diodes back view
Wiring Interface : DiodesBack View

3. Diode Direction

1. Middle Pin of 42

2. To Middle Pin of 31

4. Repeat Steps 1&2 for diode 2

wiring interface resistors
Wiring Interface : Resistors

5. Repeat Steps 1&2

6. Repeat Steps 3&4

3. Left Pin of 31

  • Left Pin of 42
  • (Viewed from front)

4. To Any Spot

2. To Middle Pin of 31

wiring interface
Wiring Interface : +

3. Repeat Steps 1&2

  • Left Pin of 42 (back view)

2. +

wiring interface ground
Wiring Interface : Ground

3. Repeat Steps 1&2

1. Right Pin of 31

2. -

wiring interface d sub
Wiring Interface : D sub
  • Resistor to
  • Pin 2 of D sub

2. Resistor to

Pin 3 of D sub

3. Ground to

Pin 18 of D sub

wiring interface ribbon cable
Wiring Interface : Ribbon Cable

4. To Middle Pin of 42

2. To Middle Pin of 42

3. Wire 5

1. Wire 6

bidirectional motor software
Bidirectional Motor Software
  • Write a program to control the car such that when
  • 1 is pressed the car moves backward
  • 2 is pressed the car moves forward
  • 3 is pressed the car stops.
bidirectional motor software30
Bidirectional Motor Software

var answer : int

var key : string (1)

put “ 0 is stop, 2 is forward, 1 is reverse”

loop

getch (key)

cls

answer := string (1)

if answer = 1 then

parallelput (answer)

put “REVERSE”

elsif answer = 2 then

parallelput (answer)

put “FORWARD”

elsif answer = 0 then

parallelput (answer)

put “STOP”

end if

exit when answer = 0

end loop

additional features
Additional Features
  • Additional options could include:
  • Separate left and right tail lights
  • Head lights
  • Search lights on roof
  • Software control of all lights individually
  • Backup lights
  • Audio backup signal
addresses
Addresses

smythel@mnsi.net

www.classictechnology.ca

www.holtsoft.com
