  1. beta Metering Pumps

  2. beta Metering Pumps • Microprocessor-based and available in two drive (solenoid) sizes: beta/4 and beta/5. • Maximum capacity for the beta/4 is 5.3 gph; the beta/5 is 8.4 gph. • Features include: • Continuous stroke length adjustment • Stroke frequency adjustment • LED fault indicators • Convex diaphragm • Auto-degassing liquid end • External access to relay outputs

  3. beta Features Stroke Length Adjustment Knob Multifunction Switch LED Fault Indicators Level Switch Port Power Input (detachable) External Control Port

  4. Stroke Length Adjustment • Stroke length (fluid displacement per stroke) is manually adjustable using the stroke length knob. • The scale is from 0% to 100% of the maximum stroke length at a ratio of 10:1.

  5. Multifunction Switch • The multifunction switch has settings for manual stroke frequency, external pulse contact, stop and test modes. • Stroke frequency control is adjustable in 10% increments from 10 to 100%. • External pulse is a voltage-free on/off contact. The Stop setting will stop the pumping. The test setting is used for priming the pump. It overrides any of the pump settings and strokes at 100% of the pump frequency

  6. LED Indicators • The 3 LED’s indicate the pump’s operating status: • The green LED flashes with each pump stroke indicating normal pump operation. • The yellow LED lights when the liquid level drops below the first float switch triggering level. • The red LED lights in the presence of faults such as low tank level (with option float switch)

  7. Cable Signals A 5-wire control cable is used for external control. Close brown and black to run, or open them to pause the pump. Use brown and black together for remote pause or pulse signals. Pause: brown External (+): white Not configured: blue Reference potential: black Auxiliary frequency: gray

  8. Relay Outputs • An external panel in the base of the pump enables optional relays to be installed on-site. • The Relay Output can provide fault annunciation, pace a slave pump or allow stroke counting on an external counter. • The SPDT relay is available for collective fault indication as either pulling in or dropping out (which also alarms on loss of power).

  9. Liquid End Options • Liquid end materials include: • Polypropylene (Viton or EPDM seals) • PVC (Viton or EPDM seals) • Acrylic (Viton or EPDM seals) • Carbon-filled Teflon-PTFE (PTFE seals) • 316 Stainless Steel (PTFE seals) • Liquid ends are available with or without a bleed valve. An auto-degassing liquid end is also available for fluids that outgas. • Some liquid ends are interchangeable between the beta/4 and beta/5 versions.

  10. Liquid End w/o Bleed Valve Discharge Valve Suction Valve

  11. Liquid End with Bleed Valve Acrylic liquid end shown. Polypropylene and PVC bleed valves are on the side of the liquid end. Discharge Valve Bleed Valve Suction Valve

  12. Auto-degassing Liquid End The auto-degassing liquid ends for beta pumps automatically evacuate gas bubbles entrained in the solution to prevent the pump from becoming airlocked. The pump can self-prime against system pressure so it does not lose prime. Auto-degassing Port (discharges back to tank) Discharge Valve Suction Valve

  13. beta/4 Capacities Version PSIG GPH ml/strk Strk/min Connectors Suction Lift (ft) 1000 145 0.19 0.07 180 1/4 x 3/16 19.7 1601 253 0.29 0.10 180 1/4 x 3/16 19.7 1602 253 0.55 0.19 180 1/4 x 3/16 19.7 1005 145 1.1 0.41 180 1/2 x 3/8 16.4 0708 101 1.9 0.66 180 1/2 x 3/8 13.1 0413 58 3.2 1.14 180 1/2 x 3/8 9.8 0220 29 5.0 1.76 180 1/2 x 3/8 6.5 Auto-degassing Liquid Ends Version PSIG GPH ml/strk Strk/min Connectors Suction Lift (ft) 1601 253 0.16 0.06 180 1/4 x 3/16 5.9 1602 253 0.37 0.13 180 1/4 x 3/16 6.9 1005 145 0.95 0.33 180 1/2 x 3/8 8.8 0708 101 1.76 0.61 180 1/2 x 3/8 6.5 0413 58 2.8 1.00 180 1/2 x 3/8 8.2 0220 29 4.3 1.50 180 1/2 x 3/8 6.5

  14. beta/5 Capacities Version PSIG GPH ml/strk Strk/min Connectors Suction Lift (ft) 1605 253 1.1 0.38 180 1/2 x 3/8 13.1 1008 145 1.8 0.63 180 1/2 x 3/8 9.8 0713 101 2.9 1.02 180 1/2 x 3/8 9.8 0420 58 4.5 1.58 180 1/2 x 3/8 9.8 0232 29 8.4 2.96 180 1/2 x 3/8 6.5 Auto-degassing Liquid Ends Version PSIG GPH ml/strk Strk/min Connectors Suction Lift (ft) 1605 253 0.87 0.31 180 1/2 x 3/8 9.8 1008 145 1.66 0.58 180 1/2 x 3/8 9.8 0713 101 2.77 0.97 180 1/2 x 3/8 8.2 0420 58 4.12 1.44 180 1/2 x 3/8 8.2

  15. Features • High Viscosity Liquid Ends • PVDF • With valve springs • Viscosity up to 3000 Centipoises • Types 1005/1605, 07081008, 0413/0713 and 0220/0420 • Low Voltage Version • 12-24 VDC and 24 V AC/DC • Available for all pump types • Auto-degassing Liquid Ends
