Presentation Transcript
a distributed intrusion detection system for resource constrained devices in ad hoc networks

A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks

Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

outline
Outline
  • Motivation
  • Methods
  • Results
  • Application to SCADA

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

outline1
Outline
  • Motivation
  • Methods
  • Results
  • Application to SCADA

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

what is hybrids
What is HybrIDS?
  • Hybrid, Distributed, Embedd-able IDS: (HybrIDS)
  • Identify deviant activity on ad-hoc network
  • Distributed implementation strategy
  • Utilize multiple detection strategies
    • Zero-knowledge phase
    • Calibration-based phase
  • Function on resource-constrained devices
  • Integrate with SCADA (Supervisory Control And Data Acquisition) networks

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

why hybrids for scada
Why HybrIDS for SCADA?
  • SCADA implementations are becoming increasingly less localized
  • Wireless and IP-based networks present a significant security vulnerability
  • Sensor/Actuator nodes have no inherent security built in
  • Designed with scalability in mind

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

why is hybrids different
Why is HybrIDS different?
  • It is decentralized
    • Reduce dependence on a single system
    • Reduce power consumption
      • Reduce compute-intensive operations
    • Allows for group consensus decisions
      • Each unit maintains a model of the world
    • Reduces chance of tampering with a centralized system
  • It is resource constrained
    • Runs well on embedded Linux platforms
  • It is portable
    • Uses abstraction to eliminate context exclusivity
    • Coded in Java for enhanced portability
  • It is adaptable
    • HybrIDS can abstract many ad-hoc network scenarios:
      • Autonomous aircraft networks and avionic protocols (ADS-B)
      • Swarm-based microrobotics
      • Self-contained sensor nodes

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

what can hybrids do
What can HybrIDS do?
  • Identify single or multiple anomalies on an ad-hoc network
  • Adaptable to various attack configurations
    • DOS
    • Timed attacks
    • Command injection
    • Network disruption
  • Locate deviant nodes with zero prior knowledge of system architecture
  • Adapt to system changes in a scalable manner

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

outline2
Outline
  • Motivation
  • Methods
  • Results
  • Application to SCADA

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

simplifying by abstraction
Simplifying by Abstraction
  • Node interactions classified by labels
  • Interaction histories recorded
    • Each node maintains action histories from its point of view
  • Abstraction permits context independence
    • Applicable to any system using predetermined actions

April 2-3, 2008

why a hybrid approach
Why a hybrid approach?
  • Phase 1 requires no training data
  • Can isolate a single anomaly
  • Phase 2 requires training data
  • Can detect multiple anomalies
  • More flexible to system changes

Phase 1

Phase 2

Time Progression

April 2-3, 2008

detection method maxima analysis setup
Detection Method: Maxima Analysis: Setup

Labels

  • Histograms formed for each connected node
    • Node A will track B, C, and D.
  • Average system behavior obtained by averaging across observed nodes
  • Bins correspond to action labels
  • Data must be normalized to a distribution
    • E.g. Gaussian, Chi2

Nodes

.

.

.

.

.

Σ/(n-1)

Avg. behavioral PDF for system

April 2-3, 2008

maxima detection algorithm
Maxima Detection Algorithm
  • Resultant vector yields approximate PDF
  • Find global maximum, exclude it
  • Identify, mark local maxima
  • Local maximum yields likely intrusion-motivated behaviors
  • Reverse-map this label to node with most frequent occurrence

April 2-3, 2008

detection method cross correlation
Detection Method: Cross-correlation

Labels

Nodes

.

.

.

.

.

Σ/(n-1)

Average PDF

= Score

13

April 2-3, 2008

score analysis
Score Analysis
  • Average score is computed
  • Each score is compared to the average
  • Deviance determined by a threshold

Suspected Deviant Node

Mean Score Line

Threshold Setting

Score

Threshold Bounds

Node Number

April 2-3, 2008

threshold requirements
Threshold Requirements
  • Threshold varies for each scenario
    • Representative of a percentage deviation required for suspicion of a node
  • Variability of thresholds is a weakness of CCIDS
  • Can cause generation of false positives
    • Reduced by selecting proper threshold
    • Minimal baseline threshold is possible – system may never converge

April 2-3, 2008

required thresholds for proper detection ccids
Required Thresholds for Proper Detection (CCIDS)
  • Deviant node pervasion yields linear change in threshold
  • Number of nodes has negligible impact on threshold requirements
  • 0.2 represents 100% deviation in this figure
    • Detects only nodes that vary significantly
  • 0.02 represents a 10% deviation
    • More sensitive to smaller node deviations

April 2-3, 2008

selecting detection phases
Selecting Detection Phases

HybridState object

determines if transition

point has been reached

If one of the results from

CCIDS matches a suspected

node from MDS, a match

is considered found

April 2-3, 2008

transitioning between phases
Transitioning between phases
  • Increasing the deviant node pervasion requires more tuning cycles
  • Threshold adjusted once per tuning cycle
  • Figure represents an average for all node sizes
    • # transition cycles is independent of node cluster size

April 2-3, 2008

hybrids implementation
HybrIDS Implementation
  • Implemented in Java 5 (1.5)
    • Introduces Code Portability
  • ARM9 development board target
  • 2.73 KB memory footprint for a 35-agent system with 10 behaviors
    • MDS and CCIDS use a shared data structure
  • Storage footprint less than 46 KB
  • Flexible interface implementation
    • TCP/UDP for network interface
    • Disk-based access for simulation
    • RS-232/Serial interface possible

April 2-3, 2008

outline3
Outline
  • Motivation
  • Methods
  • Results
  • Application to SCADA

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

analysis of hybrids performance
Analysis of HybrIDS Performance
  • HybrIDS can reliably detect deviant nodes upto 22% pervasion
  • 25% pervasion and up removes element of determinacy
  • Scalability by percentage pervasion
  • Number of nodes in cluster does not affect scalability concerns
  • Graph includes total time – MDS, transition and CCIDS cycles

April 2-3, 2008

operational footprint
Operational Footprint
  • HybrIDS with its JVM uses 5MB of application memory (Linux 2.6.22)
  • Maximum power requirement is 5 watts + idle power of ARM9 platform

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

outline4
Outline
  • Motivation
  • Methods
  • Results
  • Application to SCADA

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

hybrids and scada
HybrIDS and SCADA
  • HybrIDS is optimized for homogeneous ad-hoc networks
  • While heterogenous, SCADA contains homogeneous components that can exploit HybrIDS’s potential
  • HybrIDS can operate on RTU nodes within SCADA infrastructure

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

hybrids and scada cont d
HybrIDS and SCADA (cont’d)
  • SCADA is migrating increasingly to vulnerable network infrastructures
    • WAN
    • WLAN
  • HybrIDS can be used to detect attack methods on these networks
    • DDOS and packet drops alter interaction request frequencies
    • Targeting of a specific node is easily detected by multiple HybrIDS-enabled nodes

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008

conclusion
Conclusion
  • HybrIDS provides a flexible IDS framework for ad-hoc networks
  • Distributed nature allows for seamless integration and reliability
  • Can easily integrate into existing frameworks, such as SCADA
  • Offers scalable performance for multiple anomaly detection

ARM9 Development Platform

"A Distributed Intrusion Detection System for Resource-Constrained Devices in Ad Hoc Networks", Adrian P. Lauf, Richard A. Peters and William H. Robinson

April 2-3, 2008
