Presentation Transcript
overview
Overview
  • Overview of ADO.NET
  • Creating a Connection to a Database
  • Displaying a DataSet in a List-Bound Control
what is ado net
What is ADO.NET?

ADO.NET provides a set of classes for working with data. ADO.NET provides:

  • An evolutionary, more flexible successor to ADO
  • A system designed for disconnected environments
    • Disconnected Environment: It means Accessing the data provider source, saving it in a Web application Data source object, and then, closing the connection with Data provider
  • A programming model with advanced XML support
  • A set of classes, interfaces, structures, and enumerations that manage data access from within the .NET Framework
using namespaces
Using Namespaces
  • Use the Imports statement to import namespaces
  • Namespaces used with ADO.NET include:
    • System.Data
    • System.Data.SqlClient

Imports System.Data

Imports System.Data.SqlClient

the ado net object model
The ADO.NET Object Model

DataSet

DataTable

DataTable

SqlDataAdapter

SQL Server .NET

Data Provider

  • DataSet object is a group of related data tables

SqlConnection

SQL Server 7.0

(and later)

what is a dataset
What is a Dataset?

DataSet

DataTable

DataTable

DataTable

SqlDataAdapter

Web server memory

Physical storage

SqlConnection

SQL Server 2000

accessing data with ado net

DataSet

Accessing Data with ADO.NET

Database

1

Client makes request

Create the SqlConnection and SqlDataAdapter objects

2

Fill the DataSet from the DataAdapter and close the connection

SqlConnection

3

Web server

Return the DataSet to the Client

4

SqlDataAdapter

Client manipulates the data

5

Update the DataSet

6

Use the SqlDataAdapter to open the SqlConnection, update the database, and close the connection

7

List-Bound Control

Client

using server explorer to generate a connection
Using Server Explorer to Generate a Connection
  • Create a new data connection using the Data Links dialog box
retrieving data in a disconnected environment
Retrieving Data in a disconnected Environment

To retrieve a DataTable from SQL server Database and store it in a DataSet object:

1. Creating a connection with the required Database

Dim strConn As String = "data source=“ & _ “server\instanceName; initial catalog= DB_name;” & _ “integrated security=true“

Dim con As New SqlConnection(strConn)

2. Creating an SqlCommand that will be executed in the DB:

Dim cmd As New SqlCommand(“Sql_Statement", con)

retrieving data in a disconnected environment1
Retrieving Data in a disconnected Environment

3. Determine the SqlStatement type:

cmd.CommandType = CommandType.Text

4. Creating an SqlDataAdapter object (ad)

  • Dim ad As New SqlDataAdapter(cmd)
  • SqlDataAdapter object is used to :
    • open the connection with DB
    • execute the SQL statement passed to (cmd) object
    • retrieve the resulting table ,
    • storing it in a DataSet
    • and finally close the DB connection
retrieving data in a disconnected environment2
Retrieving Data in a disconnected Environment

5. Creating a DataSet object (ds) to store the retrieved data in it.

Dim ds As New DataSet

6. filling the (ds) with the comming table

ad.Fill(ds, “table_name")

binding a dataset to a list bound control
Binding a DataSet to a List-Bound Control
  • Create the control
  • Bind to a DataSet that contains a table (items)

<asp:Repeater ID="Repeater1" runat="server"></asp:Repeater>

dg.DataSource = ds

dg.DataMember = “items"

dg.DataBind()

handling errors
Handling Errors
  • Connection will not open
    • Connection string is invalid
    • Server or database not found
    • Login failed
  • DataAdapter cannot create a DataSet
    • Invalid SQL syntax
    • Invalid table or field name
inserting a row in a table in a certain db
Inserting a row in a table in a certain DB

ex) assume we have the table (news) in the DB (MyDB) in the Sql instance (server\inst_name)

  • News table schema
  • To insert the news item : “New News item”

Dim con As New SqlConnection("server=server\inst_name;Initial Catalog=MyDB;Integrated security=true")

Dim cmd As New SqlCommand("insert into news(news_headline) values(‘New News item’), con)

con.Open()

cmd.ExecuteNonQuery()

con.close()

what is a datareader
What is a DataReader?
  • read-only
    • You can use it just to read data from DataBase
  • Fast access to data
  • Continuous Connecting to a data source until all the data is retrieved
  • Manage the connection yourself
  • Uses fewer server resources
creating a datareader
Creating a DataReader
  • To use a DataReader:
    • Create and open the database connection
    • Create a Command object
    • Create a DataReader from the Command object
    • Call the ExecuteReader method
    • Use the DataReader object
    • Close the DataReader object
    • Close the Connection object
  • Use Try…Catch…Finally error handling

1

2

3

4

5

6

7

reading data from a datareader
Reading Data from a DataReader
  • Call Read for each record
    • Returns false when there are no more records
  • Access fields
    • Parameter is the ordinal position or name of the field
  • Close the DataReader
  • Close the connection

Do While myReader.Read()

str &= myReader(1)

str &= myReader("field")

str &= myReader.GetDateTime(2)

Loop

example retrieving data from database using sqldatareader
Example ) Retrieving Data from DataBase using SqlDataReader

Dim con As New SqlConnection("server=server\inst_name;Initial Catalog=MyDB;Integrated security=true")

Dim cmdAuthors As New SqlCommand("select * from Authors", con)

con.Open()

Dim dr As SqlDataReader

dr = cmdAuthors.ExecuteReader()

Do While dr.Read()

lstBuiltNames.Items.Add(dr("au_lname") + ", " + dr("au_fname"))

Loop

dr.Close()

conn.Close()

binding a datareader to a list bound control
Binding a DataReader to a List-Bound Control
  • Create the Control
  • Bind to a DataReader

<asp:DataGrid id="dgAuthors" runat="server" />

dgAuthors.DataSource = dr

dgAuthors.DataBind()

dgAuthors.DataSource = dr;

dgAuthors.DataBind();
