Applications of probabilistic quorums to iterative algorithms

Applications of Probabilistic Quorums to Iterative Algorithms

HyunYoung Lee, University of Denver

Jennifer L. Welch, Texas A&M University

presented at ICDCS 2001


Outline
Outline Algorithms

  • The Probabilistic Quorum Algorithm (PQA)

  • Abstracting PQA into Random Register (RR)

  • Using RRs in Iterative Convergent Algorithms

  • Monotone RRs and their Performance

  • Simulation Results

  • Conclusions


Outline1
Outline Algorithms

  • The Probabilistic Quorum Algorithm (PQA)

  • Abstracting PQA into Random Register (RR)

  • Using RRs in Iterative Convergent Algorithms

  • Monotone RRs and their Performance

  • Simulation Results

  • Conclusions


Distributed shared memory
Distributed Shared Memory Algorithms

  • Provides illusion of shared variables for inter-process communication on top of a message-passing distributed system

  • Benefits of shared memory paradigm:

    • familiar from uniprocessor case

    • supports good software development practice

  • Examples: Treadmarks [Amza+], DASH [Gharachorloo+], ...


Distributed shared memory1
Distributed Shared Memory Algorithms

app

proc r

app

proc 1

read(Y)

return(Y,5)

write(X,3)

ack(X)

client r

client 1

send

recv

send

recv

network

Implements

shared variables

X, Y, Z, ...

recv

send

recv

send

server 1

server n


Replicated data with quorums
Replicated Data with Quorums Algorithms

  • Keep a copy of shared variable at nreplica servers that communicate by messages.

  • A quorum is a subset of replica servers.

  • To write: client updates copies in a quorum with new value plus timestamp.

  • To read: client receives copies from a quorum and returns value with latest timestamp.


Quorum intersection
Quorum Intersection Algorithms

  • To ensure each read obtains latest value written, every read quorum must intersect every write quorum.

4,9:00

10,8:00

4,9:00

a write quorum

4,9:00

12,7:00

a read quorum


Performance measures for quorum systems
Performance Measures for Quorum Systems Algorithms

  • Availability: minimum number of servers that must fail to disable every quorum [Peleg & Wool].

    • Optimal (largest) availability is (n).

      Achieved when every set of size n/2 +1 is a quorum.

  • Load: probability of accessing the busiest server, in the best case [Naor & Wool].

    • Optimal (smallest) load is (1/n).

      Tradeoff Theorem [Naor & Wool]: For any quorum system, if load is optimal (1/n), then availability is at most (n).


Breaking the tradeoff with probabilistic quorums malkhi reiter wright
Breaking the Tradeoff with Probabilistic Quorums Algorithms[Malkhi, Reiter & Wright]

  • Relax requirement that every read quorum overlap every write quorum.

  • Instead, choose each quorum uniformly at random from the set of all k-sized subsets of the n replica servers, for k < n/2.

    Theorem: If k = (n), then

    • availability is n - k = (n)

    • load is (1/n)

  • To handle server failures: keep trying until enough responses to form a quorum are received.


Probabilistic quorums mrw

4,9:00 Algorithms

10,8:00

12,7:00

A read quorum

4,9:00

12,7:00

Probabilistic Quorums [MRW]

Drawback: A read quorum might not overlap the most recent write quorum, causing a read to return an out-of-date value.

a write quorum

Theorem: Probability of not overlapping is < e-h2, when k = hn.


Programming with pqs
Programming with PQs Algorithms

  • What are the semantics of the shared variable (register) implemented by the PQA?

  • What kind of applications can tolerate reads returning, with low probability, out-of-date values?


Outline2
Outline Algorithms

  • The Probabilistic Quorum Algorithm (PQA)

  • Abstracting PQA into Random Register (RR)

  • Using RRs in Iterative Convergent Algorithms

  • Monotone RRs and their Performance

  • Simulation Results

  • Conclusions


Definition of random register

W Algorithms1(c)

W 2(b)

W3(a)

W4(c)

Definition of Random Register

One writer and multiple readers.

[R1] Every read or write invocation has a response.

[R2] Every read Rreads from some write W:

(1) W begins before R ends.

(2) R’s value is same as W ’s value.

(3) W is latest such write.

R(c)


Definition of random register1
Definition of Random Register Algorithms

[R3] For every finite execution ending with a write W, probability that W is read from infinitely often is 0 (over all extensions with an infinite number of writes).

Related Work:

  • Most work on randomized shared objects concerns termination, not correct responses.

  • [Afek+] and [Jayanti+] assumed a fixed subset of shared objects that can return incorrect values.


Pqa implements an rr
PQA implements an RR Algorithms

Theorem 1: PQA implements an RR.

Proof:

[R1]: Each invocation gets a response since no lost messages and only crash failures of servers.

[R2]: Each read reads a value written by a previous or overlapping write, since no data corruption.


Pqa implements an rr1
PQA Implements an RR Algorithms

[R3]: Show probability that at least one replica in a write quorum is never overwritten is 0:

Pr(  1 replica survives h writes )

 k  Pr( replica j survives h writes )

= k  Pr( j  Q1  …  j  Qh )

= k  hi=1 Pr( j  Qi )

= k((n-k)/n)h

 0 as h  .


Outline3
Outline Algorithms

  • The Probabilistic Quorum Algorithm (PQA)

  • Abstracting PQA into Random Register (RR)

  • Using RRs in Iterative Convergent Algorithms

  • Monotone RRs and their Performance

  • Simulation Results

  • Conclusions


Iterative convergent algorithms uresin dubois
Iterative Convergent Algorithms Algorithms[Uresin & Dubois]

  • Repeatedly apply a function to a vector to produce another vector until reaching a fixed point.

  • Responsibility for vector components is distributed across several processes.

  • Vector component updates are based on possibly out-of-date views of the vector components.


Iterative convergent algorithms ud
Iterative Convergent Algorithms [UD] Algorithms

Requirements:

[A1]: All views come from the past.

[A2]: Every component is updated infinitely often.

[A3]: Each view is used only finitely often.

time

vector components

0

Red views are updated

ones.

1

2

Arrows indicate views

used in last update.

3


Iterative convergent algorithms ud1
Iterative Convergent Algorithms [UD] Algorithms

[A1], [A2], [A3] are equivalent to the existence of a partition of the update sequence into pseudocycles (p.c.’s):

  • at least one update per component, and

  • every view used was created in current or previous p.c.

X

p.c. i -1

p.c. i


Asynchronously contracting operators
Asynchronously Contracting Operators Algorithms

Theorem [UD]: Sufficient condition on F for convergence to fixed point, if update sequence satisfies [A1]-[A3]: There exists integer M and sequence of sets D0, D1,… such that

  • each DK is Cartesian product of m sets (independence)

  • D0 D1 … DM = DM+1 = …= { fixed point }

  • If x DK, then F(x) DK+1 for all K.

  • Why? At end of K-th p.c., computed vector is in DK.

  • m-vector

    ...

    DM

    DM-1

    D1

    D0

    fixed point


    Example all pairs shortest path
    Example: All Pairs Shortest Path Algorithms

    • G is weighted directed graph with n nodes.

    • Compute n x n vector x; process i updates i-th row of x, 1 in.

    • Initially x is adjacency matrix for G.

    • F(x) computes y, where yij = min 1 kn { xik + xkj}.

      Shown to be an ACO by [UD].

      Claim: Worst-case number of pseudocycles for F to converge is log2 diameter(G).


    Acos correct with rrs
    ACOs Correct with RRs Algorithms

    Theorem 2: If F is an ACO, then every iterative execution using RRs for the vector components converges with probability 1.

    Proof: Show the sequence of updates in the execution satisfies [A1], [A2] and [A3] with probability 1.

    [A1]: All views are from the past by [R2].

    [A2]: Application ensures every component is updated i.o.

    [A3] holds with probability 1: Each view is used finitely often with probability 1 by [R3].


    Implications
    Implications Algorithms

    • RRs can be used to implement any ACO, which includes algorithms for

      • APSP

      • transitive closure

      • constraint satisfaction

      • solving system of linear equations

    • If PQA is used for the RRs, improved load and availability are provided.

    • Convergence is guaranteed with probability 1.

    • But how long does it take to converge?


    Measuring time with rounds
    Measuring Time with Rounds Algorithms

    • A round finishes when every process has

      • read all the vector components

      • applied the function

      • updated its own vector components

        at least once.

        How many (expected) rounds per p.c.?

        We don’t know with current RR definition, so modify definition...


    Outline4
    Outline Algorithms

    • The Probabilistic Quorum Algorithm (PQA)

    • Abstracting PQA into Random Register (RR)

    • Using RRs in Iterative Convergent Algorithms

    • Monotone RRs and their Performance

    • Simulation Results

    • Conclusions


    Monotone rr definition
    Monotone RR Definition Algorithms

    [R1] - [R3] plus

    [R4]: If read R by process i reads from W and a later read R' by i reads from W' , then W' does not precede W.

    R(c)

    R'(b)

    X

    W '(b)

    W(c)


    Monotone rr definition cont d
    Monotone RR Definition (cont’d) Algorithms

    [R5]: There exists q s.t. for all r,

    Pr[r reads are needed until W or a later write is read from]  (1 - q)r-1q.

    So q is the probability of a “successful” read (w.r.t. W).


    Monotone rr algorithm

    ( Algorithms

    )

    n

    k

    Monotone RR Algorithm

    Same as previous probabilistic quorum algorithm, except:

    • Read client keeps track of value with latest timestamp that it has seen so far.

    • This value is returned if its timestamp is later than all those obtained from current quorum.

      Theorem 3: Attains q = 1 -

      W ’s or later value is read if a subsequent read quorum overlaps W ’s quorum.

    (

    )

    n - k

    k


    Monotone rr rounds per p c
    Monotone RR Rounds per P.C. Algorithms

    Theorem 4: Expected number of rounds per pseudocycle, when implementing an ACO with monotone RRs, is at most 1/q.

    Proof: For p.c. h to end, each process i must read from a write  first write in p.c. h-1.

    Once this read occurs for i, every later read by i is at least as recent, since monotone.

    Expected # rounds for first read is  1/q by [R5].


    Messages vs rounds for acos
    Messages vs. Rounds for ACOs Algorithms

    Corollary: For monotone PQA, expected # rounds per p.c. is  (1 - ((n-k)/n)k)-1.

    Expression is between 1 and 2 when k = n.

    Strict quorum system has 1 round per p.c.

    Monotone PQA has > 1 expected round per p.c. but may have fewer messages per p.c.

    Which has better message complexity?


    Message complexity for acos
    Message Complexity for ACOs Algorithms

    Messages per round in synchronous case:

    • Each of the m vector components is read by each of the p processes and written by one.

    • Each operation generates two messages to each of the k quorum members.

       2m(p+1)k.

      MPQA: When k = n, expected # messages per p.c. is c2m(p+1)n, 1 < c < 2.


    Comparing message complexity
    Comparing Message Complexity Algorithms

    Recall when k = n, expected # messages per p.c. for MPQA is c2m(p+1)n, 1 < c < 2.

    • High availability (n):

      • Strict: k = n/2 + 1, so # messages per p.c. is 2m(p+1)(n/2 +1). Worse.

    • Low load (1/n):

      • Strict: k = n (e.g., rows and columns of grid), so # messages per p.c. is 2m(p+1)n. Asymptotically same.


    Outline5
    Outline Algorithms

    • The Probabilistic Quorum Algorithm (PQA)

    • Abstracting PQA into Random Register (RR)

    • Using RRs in Iterative Convergent Algorithms

    • Monotone RRs and their Performance

    • Simulation Results

    • Conclusions


    Simulation purpose
    Simulation Purpose Algorithms

    Simulated non-monotone and monotone RR implementations using PQs with APSP application to study:

    • difference between synchronous and asynchronous cases

    • expected convergence time in non-monotone case (no analysis)

    • actual expected convergence time in monotone case compared to computed upper bound


    Simulation details
    Simulation Details Algorithms

    Input graph:

    log2 33 = 6 pseudocycles to converge.

    Measured rounds till convergence (when simulated results equaled precomputed actual answer).

    Each plotted point is average of 7 runs.

    ...

    1

    1

    1

    1

    2

    34


    Simulation results
    Simulation Results Algorithms

    Computed upper

    bound is not tight.

    Synch & asynch are

    very similar.

    Monotone is better

    than non-monotone.


    Outline6
    Outline Algorithms

    • The Probabilistic Quorum Algorithm (PQA)

    • Abstracting PQA into Random Register (RR)

    • Using RRs in Iterative Convergent Algorithms

    • Monotone RRs and their Performance

    • Simulation Results

    • Conclusions


    Summary
    Summary Algorithms

    • Proposed two specifications of randomized shared variables that can return wrong answers, monotone and non-monotone random read-write registers.

    • Both specs can be implemented with PQA of [MRW].

    • Our specs can be used to implement a significant class of iterative convergent algorithms, characterized by [UD]; algorithms converge with probability 1.

    • Computed bounds on convergence time and message complexity for ACOs in monotone case.

    • Simulation results indicate monotone is faster than non-monotone, asynch and synch are similar, and computed upper bound is not tight.


    Future work
    Future Work Algorithms

    • Are our specs of more general interest? Other good algs that implement them? Different specs better?

    • Useful applications for other shared data structures (e.g., stack) with errors? How to specify and implement them?

    • How to tolerate client failures? Approximate agreement as an application?
