  1. APROL 系统概念 TM800

  2. 综述

  3. APROL 体系

  4. WAN LAN 操作站 防火墙 控制总线 (TCP/IP, Ethernet) 冗余服务器 工程服务器 处理总线 (TCP/IP, Ethernet) CPU 冗余 设备 冗余总线 (Powerlink) 三级系统 I/O 控制器 现场设备 电机 总线系统

  5. 小结 • RUNTIME 系统和 OPERATOR系统的区别? • 哪个总线系统重要? • “concurrent engineering” 如何工作? • Linux的优势是什么? • 如何衡量一个APROL系统? • 用 CaeManager 时需要什么登陆机制? • dongle 机制如何工作?
