slide2

Recent Query Processing

Enhancements

NoCOUG Conference

February 19th, 2004

George Lumpkin

query processing
Query processing
  • For the purposes of this presentation, ‘query processing’ includes:
    • The underlying database objects which are being accessed (table, indexes, etc)
    • The SQL functions and capabilities used to access those database objects
    • The internal algorithms for executing SQL statements (table scans, index probes, joins, etc)
    • The optimization techniques applied to SQL statements
    • The capabilities to view and understand Oracle’s query processing
  • Improved performance is the primary benefit of enhanced query processing
database objects1
Database objects
  • Oracle9i:
    • Table Compression
    • List and Range-List Partitioning
    • Bitmap join index
    • IOT’s: hash partitiong, parallel DML, bitmap indexes
    • Datetime datatype
  • Oracle10g:
    • Floating point datatype
    • Global hash-partitioned indexes
    • Datetime improvements
table compression oracle9 i release 2
Table Compression (Oracle9i, Release 2)
  • Tables can be compressed
    • Compression can also be specified at the partition level
    • Indexes are not compressed
  • Typical compression ratios range from 3:1 to 5:1
    • Compression is dependent upon the actual data
    • Compression algorithm based on removing data redundancy
  • Key benefit is cost savings
    • Save TB’s of storage without compromising performance or functionality
  • However, a secondary benefit is often performance due to reduced IO utilization
list and composite range list partitioning
List and Composite Range-List Partitioning
  • List partitioning allows a table to be partitioned with a list of values
    • For example, a table can be partitioned by region or by department
  • Composite Range-List enables logical sub-partitioning for the most commonly used Range partitioning
  • Further flexibility in how a DBA can manage large data sets
  • Provide appropriate partitioning techniques for all business requirements
composite range list partitioning

RANGE (sales_date)

NOV1998North

NOV1998

OCT1998North

OCT1998

SEP1998North

SEP1998

DEC1997North

DEC1997

NOV1997North

NOV1997

...

LIST (geography)

West

West

West

West

West

...

South

South

South

South

South

Composite Range-List Partitioning

Range partition across time

List partition across another major attribute

...

implementation and usage tips list and composite list range partitioning
Implementation and Usage Tips List and Composite List-Range Partitioning
  • Consider LIST (sub)partitioning when:
    • You have a column containing unordered values, which correspond to a logical unit for data maintenance and query access
  • Use a DEFAULT list partition when:
    • You may have unexpected values for the partitioning key
    • You often add or modify values in your partitioning key.
  • Migration of existing nonpartitioned and partitioned tables
    • For online migration, use the dbms_redefinition package
    • For offline creation, use
      • CREATE TABLE AS SELECT
      • INSERT /*+ APPEND */

Performance Benefits

Manageability Benefits

ieee floating point
IEEE Floating Point
  • New datatypes: binary_float and binary_double
  • Precise mapping to Java and other application environments
  • Potential space reduction
    • 4/8 bytes fixed vs. up to 21 bytes variable for Oracle number
  • Increased range of values
    • Binary double’s 11-bit exponent
  • Performance improvement
    • Native hardware vs. proprietary software for calculations
  • Caveat: binary numbers are subject to rounding effects and are never suitable for data requiring precision
ieee floating point1
IEEE Floating Point
  • Biggest potential benefit for BI: Improved performance for lengthy/complex arithmetical expressions
    • Example query with 20X performance gains:
  • Second biggest potential benefit: Space savings for lengthy numeric types

select promotion_name,

exp (geo_mean_temp/count) as geometric_mean

from ( select p.promo_name as promotion_name,   sum (ln (quantity_sold)) as geo_mean_temp   from sales s, promotions p   where p.promo_id = s.promo_id   and time_id between to_date ('01-jan-1998', 'dd-mon-yyyy')   and to_date ('31-dec-1998','dd-mon-yyyy')

and quantity_sold > 0  group by promo_name)

order by geometric_mean desc;

sql functions1
SQL Functions
  • Oracle9i
    • ANSI Joins
    • Full outer joins
    • CASE statement
    • Grouping sets
    • WITH clause
  • Oracle10g
    • Enhanced connect by
    • Partition Outer Join
    • Regular Expressions
    • SQL Models
    • Statistical functions
    • Frequent Itemsets
with clause
WITH clause
  • Useful when a given query accesses the same subquery multiple times:

WITH channel_summary AS

( SELECT channels.channel_desc,

SUM(amount_sold) AS channel_total

FROM sales, channels

WHERE sales.channel_id = channels.channel_id

GROUP BY channels.channel_desc )

SELECT channel_desc, channel_total

FROM channel_summary

WHERE channel_total >

( SELECT SUM(channel_total) * 1/3 FROM channel_summary);

partitioned outer join
Partitioned Outer Join

New outer join syntax enabling easy specification and high performance for joins that "densify" sparse data.

  • To specify comparison calculations and to format reports reliably, best to return a consistent set of dimension members in query results
  • Yet data normally stored in "sparse" form: why waste space storing non-occurrence?
  • Ugly and slow SQL needed to add back rows for nonexistent cases into query output.
  • Most frequently used to replace missing values along time dimension.
  • Accepted for ANSI SQL standard.
partitioned outer join basics
Partitioned Outer Join - Basics

Inventory Tabletime_id product quant

Inventory table holds only changed values. But for calculations & reporting, we want rows for the full set of dates.

1 April 2003 Bottle 10

6 April 2003 Bottle 8

1 April 2003 Can 15

4 April 2003 Can 11

1 April 2003 Bottle 10

2 April 2003 Bottle

3 April 2003 Bottle

4 April 2003 Bottle

5 April 2003 Bottle

6 April 2003 Bottle 8

1 April 2003 Can 15

2 April 2003 Can

3 April 2003 Can

4 April 2003 Can 11

5 April 2003 Can

6 April 2003 Can

SELECT times.time_id, product, quant

FROM inventory PARTITION BY (product)

RIGHT OUTER JOIN times

ON (times.time_id=inventory.time_id);

Similar to a regular outer join, except the

outer join is applied to each partition.

partition outer join repeating values
Partition Outer Join: Repeating Values
  • The last non-null values should be preserved for subsequent records (typical inventory problem)
  • New analytical SQL keyword for LAST_VALUE()

SELECT time_id, product,

LAST_VALUE (quant IGNORE NULLS) OVER

(PARTITION BY product ORDER BY time_id) quant

FROM (

SELECT times.time_id, product, quant

FROM inventory PARTITION BY (product)

RIGHT OUTER JOIN times

ON (times.time_id=inventory.time_id) );

1 April 2003 Bottle 10

2 April 2003 Bottle 10

3 April 2003 Bottle 10

4 April 2003 Bottle 10

5 April 2003 Bottle 10

6 April 2003 Bottle 8

1 April 2003 Can 15

2 April 2003 Can 15

3 April 2003 Can 15

4 April 2003 Can 11

5 April 2003 Can 11

6 April 2003 Can 11

row sources1
Row sources
  • Oracle9i
    • Sampling
    • Index skip scans
  • Oracle10g
    • Table scan speed-up
    • Inline Lob access speedup
index skip scan
Index Skip Scan
  • In Oracle8i, composite index used only if first (prefix) column in the predicate
  • In Oracle9i, skip scan uses the composite index that is far faster than a Full Table Scan
  • No need for another index
  • Especially useful if the number of distinct values of prefix column are relatively low
index skip scan1
Index Skip Scan
  • Business Scenario: Department of Motorized Vehicles
    • A car is uniquely identified by State and registration ID
    • Unique index on (STATE, REGISTRATION#)
  • Query: Find the details of a registration ID when the State is not known
    • Index skip scan allows composite index to be used for this query
      • Can be many times faster than not using an index
    • Before index skip scans,
      • Bad performance because of lack of index
      • Or, extra cost, maintenance to create index on (registration#)
optimizer1
Optimizer
  • Oracle9i
    • Dynamic Sampling
    • Bind Peeking
    • Index Joins
  • Oracle10g
    • Automatic SQL Tuning
bind peeking
Bind peeking
  • In the first invocation of a cursor containing bind variables, the optimizer will ‘peek’ at the bind values and use those values to optimize the query
    • The query plan will remain cached, and will be re-used for future invocations
  • The bind variables in the first invocation should thus be ‘representative’ values
optimizer dynamic sampling oracle9i rel 2
Optimizer Dynamic SamplingOracle9i Rel 2
  • Problem: optimizer statistics may be missing or known to be inaccurate
  • Solution: statistics are dynamically gathered during query optimization
    • Table predicate selectivity and cardinality
    • Sampling is used to minimize the time required to gather statistics
    • Statistics are only gathered for queries which are expected to take a long time (relative to the cost of gathering stats)
optimizer dynamic sampling
Optimizer Dynamic Sampling
  • Settings for OPTIMIZER_DYNAMIC_SAMPLING parameter:
    • 0 -- Off.
    • 1 – Used for multi-table queries for tables w/o both statistics and indexes. Little overhead since you will have to do a full scan anyway. This is the default in 9iR2.
    • 2 -- Used for any unanalyzed object. This is the default in 10g where we have automated stats collection, but users may still have volatile objects without stats. This is the default in 10g
    • 3 – Used when the optimizer has to use a guess, e.g., to_number(c1) > 10.
    • 4 -- Used if correlations could be present, e.g., ANDed or ORed conditions on the same table.
diagnostics1
Diagnostics
  • Oracle9i
    • Query execution statistics
    • Enhanced SQL trace information
    • Enhanced explain plan output (DBMS_XPLAN)
  • Oracle10g
    • Automatic workload repository and automated diagnosis with ADDM
      • Self-tuning SQL optimization
    • Parallel Execution Enhancements: “No Slave SQL”
query execution statistics
Query Execution Statistics
  • Oracle9i introduces new dynamic views for a deeper insight into SQL Execution
    • V$SQL_PLAN_*
      • Execution plans of all cursors in the shared SQL area
      • Cursor runtime statistics can be collected with STATISTICS_LEVEL=ALL
    • V$SQL_WORKAREA_*
      • Detailed information about the memory usage for all running SQL statements down to a row source level
      • Activated when PGA_AGGREGATE_TARGET <> 0
v sql plan
V$SQL_PLAN
  • V$SQL_PLAN equivalent to PLAN_TABLE
  • Shows actual used plan
    • SQL shown to select plan is simplified
    • In Oracle10g, you can use DBMS_XPLAN

SQL> select /* TRACK_ME */ e.ename, d.dname

from scott.emp e, scott.dept d where e.deptno=d.deptno;

SQL> select /* NOT_ME */ id, operation, object_name, cost, bytes from v$sql_plan

where hash_value = (select hash_value from v$sql where sql_text like '%TRACK_ME%'

and sql_text not like '%NOT_ME%') order by 1;

ID OPERATION OBJECT_NAME COST BYTES

---------- ------------------------------ --------------------- ---------- ----------

0 SELECT STATEMENT 5

1 HASH JOIN 4 588

2 TABLE ACCESS DEPT 2 88

3 TABLE ACCESS EMP 2 280

v sql plan statistics all
V$SQL_PLAN_STATISTICS_ALL
  • V$SQL_PLAN_STATISTICS shows actual cursor execution statistics (overhead, not enabled by default)
    • SQL shown to select plan is simplified
    • In Oracle10g, you can use DBMS_XPLAN

SQL> alter session set statistics_level=ALL;

SQL> select /* TRACK_ME */ e.ename, d.dname from scott.emp e, scott.dept d

where e.deptno=d.deptno;

SQL> select /* NOT_ME */ id, operation, object_name, last_output_rows "ROWS",

last_cr_buffer_gets “CR", last_disk_reads “PR", last_elapsed_time "TIME us"

from v$sql_plan_statistics_all

where hash_value = (select hash_value from v$sql where sql_text like '%TRACK_ME%'

and sql_text not like '%NOT_ME%') order by 1;

ID OPERATION OBJECT_NAME ROWS CR PR TIME us

-- ------------ ----------------------- --------- --------- -------- ----------

1 HASH JOIN 14 7 0 2685

2 TABLE ACCESS DEPT 4 3 0 377

3 TABLE ACCESS EMP 14 4 0 426

enhanced sql trace
Enhanced SQL Trace
  • By Default, SQL trace includes some runtime statistics for a SQL statement

PARSING IN CURSOR #11

select e.ename, d.dname from emp e, dept d where e.deptno=d.deptno

END OF STMT

PARSE #11:c=20000,e=13838,p=0,cr=8,cu=0,mis=1,r=0,dep=0,og=1,tim=6389414660329

EXEC #11:c=0,e=102,p=0,cr=0,cu=0,mis=0,r=0,dep=0,og=1,tim=6389414660694

FETCH #11:c=0,e=2132,p=0,cr=6,cu=0,mis=0,r=1,dep=0,og=1,tim=6389414663127

FETCH #11:c=0,e=1329,p=0,cr=1,cu=0,mis=0,r=13,dep=0,og=1,tim=6389414665803

XCTEND rlbk=0, rd_only=1

STAT #11 id=1 cnt=14 pid=0 … op='HASH JOIN (cr=7 pr=0 pw=0 time=3357 us)'

STAT #11 id=2 cnt=4 pid=1 … op='TABLE ACCESS FULL DEPT (cr=3 pr=0 pw=0 time=525 us)'

STAT #11 id=3 cnt=14 pid=1 … op='TABLE ACCESS FULL EMP (cr=4 pr=0 pw=0 time=380 us)'

workload repository
Workload Repository
  • “Data Warehouse” of the Database
  • Facility to collect, process, and maintain important RDBMS statistics and workload: SQL workload, segment statistics, time & wait statistics, metrics, feature usage
  • Efficiently sample and compute statistics in memory
  • Periodically flush coarser-grain information to disk - in a self-managed tablespace
  • Information readily available & real-time accessible when needed
  • On by default - flush to disk every 30 min, keep for 7 days
oracle10g no slave sql
Oracle10g - No Slave SQL
  • In Oracle9i, parallel execution plans were complex
    • Difficult to read/understand due to multiple cursors
    • Difficult to analyze statement-level performance information

SQL> explain plan for select /*+parallel(d) parallel(e) */ dname, ename

from emp e, dept d where e.deptno=d.deptno;

--------------------------------------------…--------------------------------------

| Id | Operation | Name |… | TQ |IN-OUT| PQ Distribution |

-----------------------------------------------------------------------------------

| 0 | SELECT STATEMENT | | | | | |

|* 1 | HASH JOIN | | | 88,01 | P->S | QC (RAND) |

| 2 | TABLE ACCESS FULL | EMP | | 88,01 | PCWP | |

| 3 | TABLE ACCESS FULL | DEPT | | 88,00 | P->P | BROADCAST |

-----------------------------------------------------------------------------------

PX Slave SQL Information (identified by operation id):

------------------------------------------------------

1 - SELECT /*+ ORDERED NO_EXPAND USE_HASH(A2) */ A1.C1,A2.C1

FROM (SELECT /*+ NO_EXPAND ROWID(A3) */ A3."DEPTNO" C0,A3."ENAME" C1

FROM "EMP" PX_GRANULE(0, BLOCK_RANGE, DYNAMIC) A3

) A1,:Q288000 A2 WHERE A1.C0=A2.C0

3 - SELECT /*+ NO_EXPAND ROWID(A1) */ A1."DEPTNO" C0,A1."DNAME" C1

FROM "DEPT" PX_GRANULE(0, BLOCK_RANGE, DYNAMIC) A1

oracle10g no slave sql1
Oracle10g - No Slave SQL
  • Oracle Database 10g: single execution plan, single cursor

SQL> explain plan for select /*+parallel(d) parallel(e) */ dname, ename

from emp e, dept d where e.deptno=d.deptno;

----------------------------------------------.. --------------------------------

| Id | Operation | Name | | TQ |IN-OUT| PQ Distrib |

-----------------------------------------------..--------------------------------

| 0 | SELECT STATEMENT | | | | | |

| 1 | PX COORDINATOR | | | | | |

| 2 | PX SEND QC (RANDOM) | :TQ10001 | | Q1,01 | P->S | QC (RAND) |

|* 3 | HASH JOIN | | | Q1,01 | PCWP | |

| 4 | PX BLOCK ITERATOR | | | Q1,01 | PCWC | |

| 5 | TABLE ACCESS FULL | EMP | | Q1,01 | PCWP | |

| 6 | BUFFER SORT | | | Q1,01 | PCWC | |

| 7 | PX RECEIVE | | | Q1,01 | PCWP | |

| 8 | PX SEND BROADCAST | :TQ10000 | | Q1,00 | P->P | BROADCAST |

| 9 | PX BLOCK ITERATOR | | | Q1,00 | PCWC | |

| 10 | TABLE ACCESS FULL | DEPT | | Q1,00 | PCWP | |

----------------------------------------------..---------------------------------
