微型收音机安装

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 微型收音机安装 杭十四中 劳电组 电阻 电容 晶体管 元件

  2. 无线电收音机电路组合 • R2 R1 • R3R4 Gz • I c • L c5 • 1 . 5V • C4 • BG1 BG2 • C1 C3 • C2 R5sw

  3. 安装A6C911中波微型收音机 提供：A6C911中波微型收音机套件 安装说明书 工具：电子万用表、电烙铁、松香、 斜口钳、焊锡丝

  4. 安装电阻器 R5 R6 R2 R1 R3 R4 R1 2.2K、 R2 100K、 R3 33K、 R4 1.5K、 R5 39Ω、 R6 10Ω

  5. 安装电容器 C2 C3 C1 C5 C4 C1可变电容器、 C2 103、 C3 104、 C4 104、 C5 502

  6. 安装晶体管、耳机插座、开关 开关 导线 耳机插座 SW GZ D7642 9014 9014 D7642、 T1 9014、 T2 9014 注意：集成电路、晶体管的平面部分朝可变电容和耳机插座

  7. R2 C4 R1 R3 R4 C5 9014 9014 耳机插座 D7642 可变电容 C3 开关 C2 R5 R6 道线 C1 各元件分布

  8. 装入电路板 机盒 装入电池夹 装入磁棒天线 焊接 固定镙丝 胶水胶合 焊接

  9. 微型收音机外观
