  1. 2010 FAA Tech Transfer Conference Atlantic City, NJ Design of HMA for Airfield Pavements Using the Superpave Gyratory Compactor Allen Cooley, Ph.D. Burns Cooley Dennis, Inc.

  2. Acknowledgements • AAPTP Program, Monte Symons • Project Panel • Jeff Rapol, Ray Rollings • H.D. Campbell, Jay Gabrielson • Casimir Bognacki • Others • Randy Ahlrich and Robert James • Ray Brown, Brian Prowell, and Andrea Kvasnak

  3. Marshall is not a Mix Type. It is a Mix Design Method Item P401 or UFGS 32 12 15 Superpave is not a Mix Type. It is a Mix Design Method Highways or EB 59A Both are simply methods for proportioning asphalt binder and aggregates

  4. Comparison of Mix Design Systems SuperpaveMarshall ≠

  5. Approach for Adapting Superpave for Airfields • First, What Are We Defining As a Superpave Mix Design for Airfields? • Designed with Superpave Gyratory Compactor

  6. Experimental Plan • Field and Laboratory Work • 10 Airfields • Conduct Performance Evaluations • Distress Mix Problem, Pavement Design Problem, or Construction Problem? • Obtain Mix Design and QC/QA Data • Obtain Cores From Projects • Obtain Materials from Original Sources

  7. Experimental Plan • Reproduce HMA Using Materials From Original Sources • Compact Mix at 50 Blows • Compact Mix at 75 Blows • Compact Mix at 50 Gyrations • Compact Mix at 75 Gyrations • Compact Mix at 100 Gyrations

  8. Experimental Plan • Distress To Evaluate >> Durability • Durability Problems Most Prevalent on Airfields • How? • Not Comfortable with Durability Tests Available • Use Rut Resistance to “Back Into” Durability • Add As Much Asphalt As Possible Without Rutting

  9. Experimental Plan • Rutting Test • Repeated Load Permanent Deformation Test • Confining Pressure – 40 psi • Deviator Stresses • 100 psi • 200 psi • 350 psi

  10. Test Results • When Comparing the Marshall and Superpave Mix Design Methods, It was Obvious that the Biggest Difference was the Design Compactive Effort • Evaluated By: • Ultimate Density • Comparison of Bulk Specific Gravity • “Durability” Testing

  11. 50 Blow 67% of data Between 40 And 50 gyr 75 Blow 60% of data Between 50 And 60 gyr

  12. Ndesign Values Data Recommended

  13. Gradation • Evaluated Permeability to determine the lower (coarse) limits for gradation requirements • Permeability related to durability • Compared P401, UFGS 32 12 15, and Superpave Requirements

  14. Gradation Requirements

  15. Conclusions/Recommendations • Developed • Material Requirements (excluding binder – AAPTP 04-02) • Gradation Requirements • Design Compactive Efforts and Volumetric Requirements • Moisture Susceptibility (TSRs)

  16. Material Requirements

  17. Compactive Effort and Volumetrics

  18. Compactive Effort and Volumetrics

  19. Deliverables • Three Volumes to Report • Research Results • Guidelines on Mix Design and Mix Selection • Revised P401 for Designing with SGC www.aaptp.us

  20. Thank You! Allen Cooley (601) 856-2332 acooley@bcdgeo.com
