search integrating into the windows 8 search experience
APP-406T

Search: integrating into the Windows 8 search experience

PriyaVaidyanathan

Senior Program Manager

Microsoft Corporation

agenda
Agenda
  • Search in Windows 8
  • 3 steps to implementing the Windows Search contract
  • Search customizations
  • Best practices for building great search experiences

You’ll leave with examples of how to

  • Create great apps that integrate with Windows Search
slide3
Users often search to find the content they care about, be it on the web, local machine, network, or in an app.
search in the system apps
demo

Search in the system & apps

By implementing the search contract, apps are automatically populated in the search list

slide8

Search anatomy

1

2

  • Search box is scoped to the main app on screen
  • Query suggestions provided by the main app on screen
    • Autocompletes to terms for which the app has search results
  • List of installed Metro style apps that have implemented the search contract

3

slide9

Search anatomy

4

  • Result suggestions provided by the main app on screen
    • Must include a thumbnail and title
    • Indicates a strong or exact match result
    • Takes users directly to the details of the result
integrating with search in a sample app
demo

Integrating with search in a sample app

Adding search via Visual Studio

Search activation and query submitted

Providing query suggestions & ich suggestions

search settings events
Search settings & events

Manifest Declaration

Search Pane Events

Search Pane Settings

Search Registration

Search History

(on by default)

Search Activation

Query Submitted

File Access Capability

Local Content Suggestions

Set placeholder text

Suggestions Requested

search activation
Search activation

User

Search Pane

Search App

User selects a Search location

Activate App for Search

Search Activation Event

Query text?

No

Yes

Show Search results view

Load previous state

query submitted
Query submitted

Search App

User

Search Pane

Query Submitted Event

User enters a query and hits Search

Submit query to App

User selects a query suggestion

Query changed?

No

Yes

Show Search results view

Show previous search results view

suggestions requested
Suggestions requested

User

Search Pane

Search App

User types in Search box

Show search history that matches

Suggestions Requested Event

Request suggestions from App

HandleAsync?

Yes

No

Show suggestions from App

Add suggestions to Search Suggestion Collection

Request Deferral

Add suggestions to Search Suggestion Collection

Complete Deferral

slide16

Search contract recap

  • Register for search
    • You can do this easily using visual studio templates
  • Register and respond to these 3 events:
    • Search activation
    • Query submitted
    • Suggestions requested
  • Provide search suggestions
slide17

Tips when responding to search events

  • Don’t put one time start up logic in your activation handler
  • Help the user get back to what they were doing prior to search
  • Search activation when you are snapped will make your app the main app
  • Preserve filters that have been applied if users are switching quickly
slide19

Search placeholder text

  • Search placeholder text is the hint shown in the search box when it is empty
  • Use this to indicate what users can search for in your app
  • This will automatically be cleared when the user starts typing
setting placeholder t ext
Setting placeholder text
  • //Set the cue text via the placeholderText property in the search //pane
  • varwinsearch=Windows.ApplicationModel.Search;
  • winsearch.SearchPane.getForCurrentView().placeholderText=
  • “Places NearMe";
slide21

Separators

  • Separators can be used to group search suggestions
  • Provide a label when using separators so it is clear what the groups are
adding a search separator
Adding a search separator
  • // Code that is called when suggestions requested event is fired
  • function onSuggestionsRequested(e) {
  • varquery = e.queryText.toLowerCase();
  • varsuggestions = e.request.searchSuggestionCollection;
  • //Add query suggestions to the search suggestion collection
  • suggestions.appendSearchSeparator(“Friends”);
  • //Add more query suggestions
  • }
slide24

Should your app integrate with search?

  • Yes!!! If you would be building search in your app
    • Use the search charm
    • You do not need a search box or chrome in your app
  • Probably not, if:
    • your app needs a ‘find in doc’ functionality like a PDF reader
    • you are a game, novelty or utility app
slide25

Search results layout

  • Common ways to represent search results are in a list or grid
    • Results are ordered top to bottom, left to right
  • Use the Listview control to bring the Windows 8 look and feel to your app
  • Avoid putting the most relevant or important content on the right edge.
slide26

Search results layout

  • Give users a way to get back to their prior task in the app
  • Indicate what the user searched for
  • Indicate the number of results found
slide27

Filters

  • Filters are essential to helping users quickly find the content they care about
  • Indicate the number of results available with each filter
  • Give users a way to remove filters or see all results
slide28

Provide suggestions

  • Provide suggestions to help the user find the content they care about easily
  • Use query suggestions to help them complete their search term quickly
  • Use result suggestions to help user quickly get to the most relevant result
slide30

Recap

  • Implementing the search contract makes your app searchable from anywhere in the system!
  • You can design one search experience that works everywhere
  • The search template incorporates a lot of the best practices for great search experiences!
related sessions
Related sessions
  • [APP-741T] Metro style apps using XAML: Make your app shine
  • [APP-210T] Build data-driven collection and list apps using ListView in HTML5
  • [APP-405T] Share: your app powers the Windows 8 share experience
  • [APP-408T] Integrating with the Windows device experience
  • [APP-398T] How to declare your app’s capabilities
further reading and documentation
Further reading and documentation
  • SDK Samples: Adding Search
    • Example of how to implement the search contract
    • JavaScript, C# and C++ code samples
  • Windows Application contracts
  • Search API Reference
