how does it work
How Does It Work?
  • BLM Digitizer Circuit Model
how does it work1
How Does It Work?
  • More Details
what does data look like
What Does Data Look Like ?
  • Data from early Booster tests
data processing on the vme module
Data Processing on the VME Module
  • The module performs the following data processing.
  • 1. Digitizes the results of an analog 20.08 μs BLM charge integration into a 16 Bit Word.
  • 2. Baseline subtraction is performed as soon as the 20.08 μs integrations are digitized.
  • 3. Every 80.32 μs an average of 4 each 20.08 μs integrations produce a 16 Bit Word that is written to a FIFO memory.
data processing on the vme module1
Data Processing on the VME Module
  • 4. 40.16 ms of data is collected at a rate of 12.45 kHz for each Booster cycle, resulting in 500 samples per cycle.
  • 5. A conservative estimate for transferring one 16 Bit Word over VME is 1.0 μs. This leads to a total time of 12 ms to transfer one cycle of data for all 24 BLM channels, from the Digitizer modules to the MVME processor board.
  • (500 samples / channel)*(1 accesses / sample)*

(24 channels)*(1.0 μs / access) = 12 ms

data processing on the vme module2
Data Processing on the VME Module
  • Initial Data Processing Producing 80 us Samples
front end data processing
Front-End Data Processing
  • BLM Data Formats
    • The base 80 us integration samples.
      • Base data for computing the other sums.
    • The full cycle sampled accumulation
      • Data for Snap Shot plots. Used when tuning the Booster.
front end data processing1
Front-End Data Processing
  • BLM Data Formats (cont.)
    • The 1 ms integration samples
      • Data delivered to the BLM data logging application BLMLOG
      • Ref “Booster Loss Monitor Data Logging”, K. Cahill March 11, 2002.
    • The 100 second moving sums
      • Used in Booster performance and BLM Alarms.
      • Ref. http://www-ad.fnal.gov/proton/booster/blms
    • The 7.5 Hz Waveform Buffers
      • IRM process for delivering time stamped data, synchronized across front-ends. Used by B:136 ?
      • Ref. R. Goodwin,”BLM Correlated Data”, Nov. 1, 2002
front end data processing2
Front-End Data Processing
  • Illustration of the Front-End processing
front end data processing3
Front-End Data Processing
  • Illustration of processing continued
front end data processing4
Front-End Data Processing
  • QUESTIONS:
  • What type of BLM summation is used by the following applications?
  • Are there other applications I have missed that currently exist?
  • Are there applications we may want that do not yet exist?
    • BLM2 Data Logger
    • App B88 – BLM / TRIP POINT BAR GRAPH DISPLAY
    • App B36 – BOOSTER BEAM LOSS NON-NORMALIZED BAR GRAPH DISPLAY
    • App B136 – BLM CYCLE PLOT MULTIPLE BLM TIME PLOTS, 87 CHANNELS ON A SPECIFIC EVENT
snap shot plots
Snap Shot Plots
  • Plotting
    • Needs to plot multiple Booster cycles.
    • Needs to approximate slower sampling rates
    • Needs to support Delay from Arm Event
    • Defining a new SNP Class ?
snap shot plots1
Snap Shot Plots
  • Illustration of processing
