  1. MCU-NET1 實驗架設教學

  2. 標準RS-232 一 . 器材準備 JP 標準TTL 標準RS-485 MCU-NET1 CC2530 MCU 燒入線 For Debug Debug RTC Relay

  3. 標準RS-232MOD 二 . 器材組合 JP跳至 標準RS-232MOD 標準RS-232 COMPORT 可搭配CC2530SDK光碟 內的任何UART傳輸相關韌體 除了RS-485類的韌體

  4. 標準RS-485MOD JP跳至 標準RS-485MOD 標準RS-485 COMPORT 需搭配CC2530SDK光碟 內的RS-485標準韌體使用

  5. 標準RS-485 韌體位置 CC2530SDK光碟 內的RS-485標準韌體存放位置

  6. 標準TTL/NETMOD 可搭配CC2530SDK光碟 內的任何UART傳輸相關韌體 除了RS-485類的韌體 (不須跳JP)
