1. Highlights of NAVAIR’s Efforts in Corrosion Control and Prevention
3. 3 Army’s rotary wing fleet minus UH-1 [per COL Ward] and not including introduction of Commanche.
“Commercial” is major passenger carriers only. (FAA did not supply historical fleet information.) Average age of medium and large aircraft of fleet of four largest freight carriers (FedEX, UPS, Emery and DHL) is 24.1 years.Army’s rotary wing fleet minus UH-1 [per COL Ward] and not including introduction of Commanche.
“Commercial” is major passenger carriers only. (FAA did not supply historical fleet information.) Average age of medium and large aircraft of fleet of four largest freight carriers (FedEX, UPS, Emery and DHL) is 24.1 years.
4. While the average age of the aircraft continues to rise, the average age of the maintainer does not.While the average age of the aircraft continues to rise, the average age of the maintainer does not.
5. 5 CORROSION TRENDSCORROSION HOURS PER FLIGHT HOUR
6. 6 INSPECTION TRENDSINSPECTION HOURS PER FLIGHT HOUR
7. 7
9. 9 Aircraft Corrosion Control and Prevention PROGRAM ELEMENTS
10. 10
11. 11 Goal:
Address corrosion as a common Fleet issue and not a aircraft specific issue
Characterization and documentation of corrosion problems, prevention practices required to reduce this readiness degrader.
Ensure corrosion practices are in agreement with manuals.
Comparative analysis of problem areas with trouble-free regions across fleet inventory will enable solutions to be transferred across PMAs. Corrosion Fleet Focus Team
12. 12 Team Focus NAVAIR Fleet
Transition of proven solutions across platforms
Rapid Insertion of Mature Technology
Increased Information Dissemination
Elimination of Duplicate Efforts
13. 13 Team Members
14. 14 Team Approach National Team stood up in November 2001
Review/Identify/Assess/Plan/Act
Review Aircraft Corrosion Control and Prevention Program FY99/FY00 Program Report (AIR-4.3.4)
Engaged TYCOMs and NATEC MTs to ID Fleet Issues
Meet with FST & 6.0 Reps on current status of highlighted issues of previous report and new areas
Review commercial technologies & on-going Team efforts
Develop POA&M and Engage/Initiate Efforts/Tasking
Communication:
Bi-weekly Teleconferences
Twice yearly Off-site meetings
Implementing Web Based Knowledge Management System
Status reports
Presentations
Calendar
Threaded Discussion board
15. 15 FY02 Program Summary Team Approach in Three Areas:
Cross Platform Technology Transition
High Temp Coating
CA1000 Sealant
Magnesium Gearbox Coatings
Rapid Multi-Platform Technology Insertion
Cleaning Pad,
Bristle Disc
Pre-Val
AvDec
MIL-L-87177
Salt Away
Mildew Remover
Core Team Activities
Miscellaneous Corrosion Issues
Training
16. 16 HIGH TEMPERATURE COATINGS
17. 17 CA-1000
18. 18
19. 19 Magnesium Gearbox Coatings Objectives:
Identify better protective coatings than conventional MIL-R-3043 permanent resin
Tailor coatings to specific alloys (AZ91C, ZE41A, etc.); alloy heat treatment is a factor
Status:
Rockhard and Sermetel products are candidates
Some of these coatings have already been incorporated into existing refinishing requirements for H-53 and H-60 programs
Investigating applications for other programs
20. 20 H-53 Magnesium Gearbox
21. 21 FY02 Program Summary Team Approach in Three Areas:
Cross Platform Technology Transition
High Temp Coating
CA1000 Sealant
Magnesium Gearbox Coatings
Rapid Multi-Platform Technology Insertion
Cleaning Pad,
Bristle Disc
Pre-Val
AvDec
MIL-L-87177
Salt Away
Mildew Remover
Core Team Activities
Miscellaneous Corrosion Issues
Training
22. 22 3M Cleaning Pads
23. 23 Radial Bristle Disc (RBD)
24. 24 PreVal™ AEROSOL TOUCH-UP PAINT SYSTEM
25. 25
26. 26 AvDEC Gasket Materials
27. 27 MIL-L-87177
28. 28 Mildew Removal
29. 29 FY02 Program Summary Team Approach in Three Areas:
Cross Platform Technology Transition
High Temp Coating
CA1000 Sealant
Magnesium Gearbox Coatings
Rapid Multi-Platform Technology Insertion
Cleaning Pad,
Bristle Disc
Pre-Val
AvDec
MIL-L-87177
Salt Away
Mildew Remover
Core Team Activities
Miscellaneous Corrosion Issues
Training
30. 30 Low Temperature Application Paint Fleet Issue Identified by AIRLANT and NATEC MTs
COSSI Proposal for approximately $550K
509 Manual requires Painting Performed at Temperatures >60°F
Below 60°F Paint Does Not Cure Properly
Corrosion, Weather Resistance Properties Inadequate
Poor Film Formation
Most O- and I-Level Painting Performed in Geographic Areas with Temperature Below 60°F 30-40% of the Time
Two-Year Development/Test Program
Potential Cost Savings of $1.2M/Yr Due to Repaints and Corrosion Maintenance (4.2 Source)
Joint Program with AF
31. 31
32. 32 FY02 AERMIP EffortCPC Fogging Objective: Develop Naval Aviation Strategy for use of CPCs
These areas include: Sub-structure (cargo bay, cockpit, & nose); stub wings; tail pylon, radomes, rotordomes, etc.
Consolidate independent Navy CPC efforts into a centralized strategic plan
O-level
D-level
Tailored to specific aircraft requirements (Material & Application)
This effort leverages lessons-learned from similar processes developed by the US Coast Guard, industry, & the Air Force
New Programs Initiating (F/A-18, EA-6B, E-2/C-2, etc.)
33. 33
34. 34 Training Is training Adequate?
Is training Consistent?
Are curriculums updated in a timely manner?
If Not, Why?
How can we assist?
35. 35 Team Success & Constraints Immediate Successes:
Elimination of duplicative efforts on PreVal
Validated PreWash lubrication requirement for C-130
Short Term Successes:
Approval of PreVal and Wash Pads for Fleet Usage
Demonstration of Salt Away inability to work for Naval Aviation
Expected Long Term Successes:
Transfer of Platform funded successes to other aircraft
MIL-L-87177
Magnesium Gearbox Coatings
CA-1000
Impediments:
$$$$$$$
No efforts addressing Support Equipment
No efforts addressing Weapons
No efforts addressing avionics
One addressing electrical connectors
No organized team visits to the fleet
Long list of unfunded airframe efforts
36. 36 FY03 Planned Efforts Team Funded
MIL-L-87177
Improved primers and topcoats for touch-up
CA-1000
Wash Cycle Frequency
NATEC Training
Seal Caps
Corrosion Kit Funded by others
AvDec
Mg Gearbox
Sealant Rotary Cutter
Corrosion Preventative Compounds
