developing for microsoft sharepoint 2010 online understanding the boundaries

Required Slide

SESSION CODE: OSP204

Developing for Microsoft SharePoint 2010 Online: Understanding the Boundaries

Chris Mayo

http://blogs.msdn.com/cmayo

Microsoft Corporation

agenda
Agenda
  • SharePoint Online Overview
  • SharePoint 2010 Development Overview
  • Developing for SharePoint Online
    • Sandboxed Solutions
    • SharePoint Client Object Model and Silverlight
  • Developing for SharePoint Online - Dedicated
  • Summary
the power to chose
The Power to Chose

On Premise

SharePoint Online - Standard

SharePoint Online - Dedicated

  • Hosted in MSFT data center
  • Dedicated Hardware
  • Admin outsourced to MSFT
  • Partial and full trust customization*
  • Authenticated via NTLM
  • Designed for 5000+ seats
  • Self-hosted in your data center
  • Dedicated hardware
  • Central admin access
  • Partial and full trust customization
  • Authenticated via AD
  • Available to companies of any size
  • Hosted in MSFT data center
  • Multi-tenant/shared hardware
  • Admin outsourced to MSFT
  • Partial trust customization
  • Authenticated via certs and forms
  • Available for companies of any size
case studies
Case Studies

On Premise

SharePoint Online - Standard

SharePoint Online - Dedicated

availability
Availability
  • SharePoint Online is available today
    • Based on SharePoint 2007
  • SharePoint Online future
    • Updated to SharePoint 2010
    • Preview later this year
    • www.microsoftonline.com
sharepoint 2010 development
SharePoint 2010 Development
  • Development on Windows 7 or Vista x64
  • Visual Studio 2010 Support
    • SharePoint Explorer
    • SharePoint Project and Item Templates
    • Visual Designers for Common Scenarios
    • F5 Debugging
    • Packaging Support (.wsp)
  • Developer Dashboard
  • Sandbox Solutions
  • Client Object Model
    • Silverlight
    • .NET
    • ECMA Script
why sandboxed solutions
Why Sandboxed Solutions?

Developers

Administrators

Business

why sandboxed solutions15
Why Sandboxed Solutions?

Administrators

Developers

Business

why sandboxed solutions16
Why Sandboxed Solutions?

Developers

Administrators

Business

why sandboxed solutions17
Why Sandboxed Solutions?

Developers

Administrators

Business

sandboxed solutions
Sandboxed Solutions
  • Development
    • Scoped to SPSite and below, Partial Trust, subject to CAS
    • Executes in sandboxed execution environment
      • User Code Service (SPUCHostService.exe)
      • Sandbox Worker Process (SPUCWorkerProcess.exe)
      • Sandbox Worker Process Proxy (SPUCWorkerProcessProxy.exe)
  • Deployment
    • Uploaded to Solution Gallery by Site Collection owner
    • No IT Admin required
  • Admin*
    • Solutions consume resource points
    • Solutions are disabled before affect site collection, etc.
  • Required for SPO-S, primary choice for SPO-D
sandboxed solution elements
Sandboxed Solution Elements
  • Scoped to SPSite/Site Collection
    • Web Parts
    • Lists
    • List Templates
    • Custom Actions
    • Workflows
    • Event Receivers
    • Content Types
    • Site Columns
sandbox architecture
Sandbox Architecture

FRONT END

BACK END

Execution Manager(Inside Application Pool)

Host Services (SPUCHostService.exe)

Worker Service

(SPUCWorkerProcess.exe)

IIS(WPW3.EXE)

Untrusted Code

Subset Object Model

Full Object Model

sandbox architecture21
Sandbox Architecture

FRONT END

BACK END

Execution Manager(Inside Application Pool)

Host Services (SPUCHostService.exe)

Worker Service

(SPUCWorkerProcess.exe)

IIS(W3WP.EXE)

Untrusted Code

Subset Object Model

Subset-Model Request

Full Object Model

sandbox architecture22
Sandbox Architecture

FRONT END

BACK END

Execution Manager(Inside Application Pool)

Host Services (SPUCHostService.exe)

Worker Service

(SPUCWorkerProcess.exe)

IIS(W3WP.EXE)

Untrusted Code

Subset Object Model

Full-Model Request

Full Object Model

sandbox architecture23
Sandbox Architecture

FRONT END

BACK END

Execution Manager(Inside Application Pool)

Host Services (SPUCHostService.exe)

Worker Service

(SPUCWorkerProcess.exe)

IIS(W3WP.EXE)

  • while(true)
  • {
  • //Do a Bad Bad Thing!
  • }

Run for

30sec

Untrusted Code

Subset Object Model

Resource Wasting Call

Full Object Model

sandboxed solution monitoring
Sandboxed Solution Monitoring
  • Quotas specify limits for resource consumption per day
    • Summed across solutions deployed to Site Collection
    • i.e.: add up CPU Points for all solutions
  • Solution is self-regulated vs. quotas to protect Site Collection
    • Throttled
    • Deactivated
why client object model
Why Client Object Model?
  • More SharePoint Web services is a recurring request
  • Client Object Model provides complete API
    • Abstraction layer
    • Results returned as recognizable SharePoint objects
  • Consistent developer experience across platforms
    • .NET
    • ECMAScript
    • Silverlight
supported areas
Supported Areas
  • Site Collections and Sites
  • Lists, List Items, Views, and List Schemas
  • Files and Folders
  • Web, List, and List Item Property Bags
  • Web Parts
  • Security
  • Content Types
  • Site Templates and Site Collection Operations
equivalent objects
Equivalent Objects
  • Member names mostly the same from server to client (e. g., SPWeb.QuickLaunchEnabled = Web.QuickLaunchEnabled)
using the client object model
Using the Client Object Model

ECMAScriptControlsand Logic

Browser

Client.svc

Server OM

JSON Response

ECMAScript OM

XML Request

Proxy

XML Request

Proxy

Contentdatabase

JSON Response

Managed OM

Managed Client

Managed Controls and Logic

SharePoint Server

creating silverlight web parts
Creating Silverlight Web Parts
  • Web Parts host Silverlight apps
    • SharePoint ships with Silverlight web part
    • Custom Web Part
  • Custom Web Part
    • Custom properties sent to Silverlight via InitParameters
    • Silverlight access SharePoint via Client OM
    • XAP file deployed to LAYOUTS and loaded at run time
deploying customizations to spo dedicated
Deploying Customizations to SPO - Dedicated
  • No review/deployment process required
    • Customizations in the SharePoint UI
    • Microsoft SharePoint Designer customizations
    • Sandboxed Solutions
    • SharePoint Client Object Model Solutions
  • Require review/deployment by Microsoft Online operations team
    • Full Trust solutions
    • Server side code/file deployments
spo d process for acquisition validation deployment
SPO-D Process for Acquisition, Validation & Deployment

Submitted via TAM in run state

Or DSG in Deployment phase

2

3

1

Submitted via TAM in run state

Or DSG in Deployment phase

4

6

5

7

8

spo d customization process high level timeline
SPO-D Customization Process High Level Timeline

Notify MSO 5 days in advance via a Change Request

Notify MSO 5 days in advance via a Change Request

1

2

3

4

5

6

7

5 days *

16 days *

1 day *

HLD Document submission **

Code Drop

Submission **

Customer activities

* Business days

** Customers must submit HLD and Code Drops along

with updated versions of the Change Request templates

HLD, Change Requests and Code Drop Templates available through Microsoft technical account manager (TAM)

MSO activities

summary
Summary
  • SharePoint 2010+ The Cloud = SharePoint Online
    • SharePoint 2010 benefits
    • Cloud flexibility, scalability and economics
  • SharePoint Online Development
    • All the benefits of SharePoint 2010 Development
    • Sandboxed Solutions provides balance of agility and stability
    • SharePoint Client Object Model and Silverlight for RIA
  • SharePoint Online - Dedicated Development
    • Full trust solutions via MOS Change Process
  • Build for SharePoint 2010, Be Ready for SharePoint Online!
