modeling the change in spectrally resolved outgoing longwave radiation

Modeling the change in spectrally resolved outgoing longwave radiation

Wing-Yee (Marie) Lau

Aug 18, 2010

questions about convolution code
Questions about convolution code
  • The convolution code takes weighted average over a distance of “hw” from the center.

for i=0,lines-1,1 do begin

aindex=where(abs(wn-wn[i]) le hw)

wn_temp=wn(aindex)

rad_temp=rad(aindex)

weight_temp=1.-abs(wn_temp-wn[i])/hw

rad_temp=rad_temp*weight_temp

smooth_rad[i]=total(rad_temp)/total(weight_temp)

endfor

  • For a resolution of 2.8 cm-1, “hw” should be 1.4 cm-1. Was “hw” = 2.8 or 1.4 when convolving the measurement data?
    • I was told to set “hw” = 2.8.
  • The convolution code does not change the number of data points, but the AIRS spectra have a uniform wavenumber step of 1.39052 cm-1. What was done besides convolution?
too large iris gas profiles
Too large IRIS gas profiles
  • All gases are order of magnitude smaller, if in unit of number density per cubic meter
  • If scaled up by a factor of 10, look too large.
  • Check CO2 and methane, of which well accepted values are known for 1970.
iris gas profiles converted to volume mixing ratio
IRIS gas profiles converted to volume mixing ratio
  • Accepted concentration of CO2 in 1970: 325 ppm; Our input: 335 ppm
  • Accepted concentration of methane in 1970: 1.4-1.5 ppm. Our input: 1.68 ppm at ground
  • US standard model atmosphere provides rough estimate at a few altitude levels only, and not for tropics. What was done besides interpolating to 101 levels?
more puzzles of the simulation
More puzzles of the simulation
  • My IRIS and AIRS inputs, in ppmv: http://web.gps.caltech.edu/~mlau/IRIS_AIRS_inputs/
  • Original IRIS profiles from Yibo: http://web.gps.caltech.edu/~mlau/TRP_1_MOD.100
  • Ozone was increased by 8% to make AIRS profile, not physical
  • Methane was increased by 40% to make a -6.5 K brightness temperature difference. The true increase should be ~25%.
  • Does frequency shift contribute to the -8K difference at 1304 cm-1?
simulation using profiles from grigg s paper
Simulation using profiles from Grigg’s paper
  • 16 altitude levels only
  • Source: page 17-19 of http://web.gps.caltech.edu/~mlau/Griggs-07-IRIS-IMG-AIRS.pdf
comments on simulation with profiles from griggs s
Comments on simulation with profiles from Griggs’s
  • Grigg’s 1970 profiles are closer than ours to other available sources. But her 2003 profiles are incorrect.
  • Positive difference in water vapor continuum and shape inverted: they used a much smaller water profile for 2003.
continued1
Continued
  • Fail to simulate the ozone signal: no significant difference in stratospheric temperature and ozone concentration in their 1970 and 2003 profiles.
  • Too few levels at the stratosphere, where ozone signal is sensitive to.
decision
Decision?
  • Set “hw” to 1.4 or 2.8 for convolution?
  • Recalculate all profiles from US standard model of atmosphere, or use Griggs’s 1970 profiles and interpolate to more levels?
  • Keep ozone+8% and methane +40%?
update on searching for inversion
Update on searching for inversion
  • Redoing the search for spectra with ozone band inversion, with the same search method for both AIRS and IRIS
  • Finished searching among IRIS and uploaded to http://web.gps.caltech.edu/~mlau/iris_spec_updated/.
  • Sample plots and statistics:
continued4
Continued
  • Checked every 1 in 10 among AIRS (Apr-Dec 2007, Apr-Dec 2008) for ozone band inversion.
  • Uploaded to http://web.gps.caltech.edu/~mlau/airs_spec/.
  • Sample plots and statistics:
continued5
Continued
  • When searching for CO2 inversion, require the whole CO2 band centered at 670 cm-1 to be inverted, or just the Q branch at 720 cm-1?
slide21

Thank you! I really want to, and I will, finish the exciting jobs at hand, though I’m leaving tomorrow.
