  1. ACCESS's Embedded Module for Information Appliance -Introducing AVE-TCPv6.0- J2-2 ACCESS CO., LTD. Marketing Dept.

  2. ACCESS CO., LTD. Leading provider of embedded software solutions for Internet Appliances Our embedded browser software powers over 70 commercial products worldwide i.e., i-mode phones for NTT DoCoMo; Sega’s Dreamcast and Nitendo64 video game consoles; word processors ; personal digital assistants and car navigation systems Over 10 million commercial software licenses have been shipped from more than 30 major consumer appliance manufacturers

  3. Embedded HTML Browser • 10 million copies shipped in 70 different consumer information appliances: PDAs, InternetTV, STBs, car navigation, smart phones, web phones, vertical Intranet terminals, video game consoles, Internet kiosks, word processing machines, etc. • Specifically designed to meet the resource constrained requirements of information appliances • Comprehensive set of standard modules including a Web browser, Internet mail, PPP driver, TCP/IP module, Java VM, SSL module • Multi-platform and multi-architecture, not dependent on specific OS or CPU

  4. Embedded HTML Browser • Slim GUI system WAVE with only 300KB • Supports HTML3.2, frame and some HTML4.0 features • JavaScript, Cookie, Multi language, Web printer support • UI customizing and application development on PC • Character input method: Handwritten character recognition engine, Kana-Kanji conversion module, Fonts 12/16/24dots • Client Side Extension(CSE) for HTML application development • Plug-in modules such as Macromedia Flash4, H.324, and MPEG4 player • A suite of Software Development Kits-Allows developers UI customizing and application development on PC and porting low-level drivers on the selected hardware

  5. Optimized for the requirements of the wireless world--a world where bandwidth is limited, screen sizes are small, yet performance and broad functionality are necessities • Ｅnables a new generation of wirelessphones, PDAs, and pagers • ROM：300KBRAM：150KB • Based on Compact HTML, a subset of the HTML4.0 standard, including GIF image • CPU, OS and network protocol stacks (CDMA, GSM, W-CDMA, CDMA2000) independent • Easily Customized and Extensible Micro-HTML Browser for Wireless and Portable Internet Devices

  6. Sun Authorized Java Virtual Machine for Embedded/ Consumer Devices • Sun Authorized Virtual Machine with compact implementation optimized for embedded devices • Clean-room Java VM ensured 100% compatibility with EmbeddedJava and Personal Java • ROMizeable module (VM and class libraries) • available as a Stand-alone module or as a Browser plug-in module (PersonalJava) • Embedded Edition (Embedded Java) • Personal Edition (Personal Java) • Wireless Edition (CLDC/MID-P)

  7. Real-time multitasking OS based on uITRON ver4.0 Standard Profile • Based on uITRON and Optimized for next generation mobile devices • Power Management Support: Easy Power SaveTM Function for Low System Power Consumption without application modification • MMSO(Micro More System Observer) OS/task profiling tool • A suite of Software Development Kits for application development on PC

  8. Embedded TCP/IP protocol stack • Proven in a wide variety of commercial embedded products for more than 4 million units • A set of standard modules including TCP, IP, UDP, ICMP and ARP. • Additional stacks in the applications, protocol, i.e. Telnet C/S, FTP C/S, PPP, DHCP, DNS and AVE-PPP/LAN driver layers can be selected for individual applications, RFC-compliant, written in ANSI C for fast and easy porting • RTOS and CPU independent • ROM-enabled, compact modules with high performance • APIs available for user applications • A suite of Software Development Kits for application development on PC • Web server AVE-HTTPD, FAT file system AVE-File available (option)

  9. More Product Lineup • NetFront for DTV: Browser for BS Digital Broadcast • IrFront: Infrared Protocol Stack • Bluetooth Protocol Stack: Optimized with NetFront Browser

  10. Market Requirement to IPv6 • With rapid increase of Internet access, shortage of IP address is going to be a serious problem • Limitless number of IP address with IPv6 enables for any devices to be Internet-ready with own IP address, i.e. cellular phone, PDA, consumer electronics, home network, automobile, etc. • i-mode user reached over 10 M • IMT-2000 standard group 3GPP supports IPv6 • ISP IIJ starts IPv6 ready service • MPT, Sony, Fujitsu and other companies formed IPv6 promotion consortium • ------------> ACCESS started to serve the v6 needs with AVE-TCPv6 protocol stack, ready for embedded devices.

  11. v6.0 • TCP/IP protocol stack AVE-TCP is shipped for over 4 million units for 14 years, optimized for consumer and embedded devices • Dual stack to support IPv4/v6. Ready for either platform by changing configuration • BSD socket like interface, optimized for embedded RTOS • Support protocols:TCP, UDP, IPv4, PCMPv4, ARP, IPv6, NDP, PPP • SH3 (SH7709ASE01) Support

  12. v6.0 • Compact size: ROM 80KB, RAM 110KB (IPv4+v6, x86 base) • High speed: 10 BASE 1024KB/sec v4 sending, 989KB/sec v6 sending • Multiple interface and Forwarding • Multiple IP provision for single interface • Attended 2nd TAHI Interoperability Test Event for AVE-TCPv6’s interoperability

  13. v6.0 • Early Access version on Win32 available • Start shipment on SH-3/μMORE (End/2000) • Engineering service • SDK (to be released 2001/Q1) • AVE-TCP v6.0 for Wireless (2001)
