Pwb519 accessing third party enterprise javabeans servers from powerbuilder 9 0

PWB519 Accessing Third-Party Enterprise JavaBeans Servers from PowerBuilder 9.0

Jim O’NeilPrincipal Technical Support EngineerSybase, Inc. (Concord, MA)[email protected]


Accessing third party ejb servers
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Agenda

  • Overview of the Enterprise JavaBeans (EJB) Model

  • PowerBuilder EJB client implementation

  • Coding a PowerBuilder EJB client application

  • Deploying PowerBuilder NVOs to EJB servers

  • Additional resources


Accessing third party ejb servers1
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Agenda

  • Overview of the Enterprise JavaBeans (EJB) Model

  • PowerBuilder EJB client implementation

  • Coding a PowerBuilder EJB client application

  • Deploying PowerBuilder NVOs to EJB servers

  • Additional resources


Overview of the enterprise javabeans model
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Core Concepts

EJB is Sun’s J2EE transactional, vendor-neutral, enterprise component architecture providing

  • Modeling of business entities and synchronous and asynchronous processes

  • Persistence via explicit code (bean-managed) or via services of the EJB server (container-managed)

  • Vendor neutrality and interoperability

  • XML driven deployment and configuration


Overview of the enterprise javabeans model1
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Core Concepts

EJB types

  • Session beans model processes

    • Stateless EJBs are reusable and ‘single-task’ oriented

    • Stateful EJBs remain associated with a client and are disposed when client is through

  • Entity beans model objects that persist, often in the form of records in a database

  • Message-driven beans respond to asynchronous requests from the Java Message Service (JMS)


Overview of the enterprise javabeans model2
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Representative Enterprise JavaBeans Server and Client Application

Client Application

J2EE Server

JNDI Service

InitialContext

lookup

EJB Home

homeinterface stub

createfindByPrimaryKey

EJB Object

EnterpriseInformation

System

remoteinterface stub

business method

Implementation class

Message-driven bean

return value

ancillary Java classes

onMessage

topic/queue

messages

External messaging

client applications

Java Message Service


Overview of the enterprise javabeans model3
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Java Naming and Directory Interface (JNDI)

  • Provides a standardized way of accessing resources in a distributed environment

  • Protocol and naming service agnostic

    • DNS

    • NDIS

    • LDAP

    • X.500

  • Implemented by the javax.naming package and three other packages below it

  • javax.naming.InitialContext is the entry point to the EJB Server

    • bind – associates a name with an object

    • lookup – finds an object given the name


Overview of the enterprise javabeans model4
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Home interface

  • Provides remote client-view of methods affecting the EJB lifecycle

  • Extends javax.ejb.EJBHome

  • Can include business methods that are not specific to a given EJB instance

  • Lacking for message-driven beans since they have no client-view


Overview of the enterprise javabeans model5
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Component interface

  • Provides remote client-side view of bean’s business methods

  • Extends javax.ejb.EJBObject thus providing methods to obtain access to Home interface and Primary Key classes and to test for equality between EJB instances

  • Lacking for message-driven beans since they have no client-view


Overview of the enterprise javabeans model6
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Implementation class

  • Implements one of the extensions of the javax.ejb.EnterpriseBean class which provide lifecycle notification methods (e.g., ejbPassivate)

    • javax.ejb.EntityBean

    • javax.ejb.SessionBean

    • javax.ejb.MessageDrivenBean

  • Class in which EJB developer codes the business methods defined in the bean’s component interface(s)


Overview of the enterprise javabeans model7
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Primary key class

  • Applicable only to entity beans

  • Uniquely differentiates one instance from the other instances sharing the same EJBHome

  • Class must be a legal value type in RMI-IIOP

    • Implements java.io.Serializable

    • Does not implement java.rmi.remote


Overview of the enterprise javabeans model8
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Exceptions

  • System exceptions are unchecked and propagate to the client as java.rmi.RemoteException

  • Application exceptions are checked and propagate to the client as a descendant of java.lang.Exception

    • EJB-specific exceptions include FinderException, CreateException, RemoveException (all in javax.ejb package)

    • Business method exceptions are at the discretion of the EJB developer


Overview of the enterprise javabeans model9
Overview of the Enterprise JavaBeans Model from PowerBuilder 9.0

Interfaces and Classes

Other interfaces and classes

  • Local interfaces used for access within server context (e.g., intercomponent calls, servlet invocation)

    • javax.ejb.EJBLocalHome

    • javax.ejb.EJBLocalObject

  • Interfaces for serializing EJB references

    • HomeHandle - reference to EJBHome

    • Handle - reference to EJBObject

  • EJBMetaData interface provides mechanism to gather information about the bean

    • Reference to EJBHome object

    • Home, component interface and primary key classes

    • Functions to determine bean type


Accessing third party ejb servers2
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Agenda

  • Overview of the Enterprise JavaBeans (EJB) Model

  • PowerBuilder EJB client implementation

  • Coding a PowerBuilder EJB client application

  • Deploying PowerBuilder NVOs to EJB servers

  • Additional resources


Powerbuilder ejb client implementation
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

Feature overview

  • Uses Java Native Interface (JNI) for interoperability

  • Supports 1.0, 1.1, and 2.0 EJBs

  • Supports client-managed transactions

  • Supports system and application exception handling

  • Supplemented by EJB Proxy Generator

    • PowerBuilder IDE

    • EJB2PB90 command line utility


Powerbuilder ejb client implementation1
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

Implementation overview

  • Built using the PowerBuilder Native Interface (PBNI) which allows developers to

    • Extend core features of PowerBuilder via custom C++ classes, and

    • Access PowerBuilder objects from other languages like C++, VisualBasic, and Delphi

  • Three PBNI classes are exposed in the PBEJBCLIENT90.PBD

    • JavaVM

    • EJBConnection

    • EJBTransaction

  • EJBLocator Java class, which wraps javax.naming.InitialContext, is contained in PBEJBCLIENT90.JAR

  • PowerBuilder proxy objects represent all other Java classes and interfaces required for a given EJB

  • JDK required for development, JRE for runtime – PowerBuilder installs Sun JDK 1.4 by default to ease configuration issues


Powerbuilder ejb client implementation2
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

JavaVM object

  • Loads and initializes Java VM inside of the PowerBuilder process

  • Supported by configurable PowerBuilder ‘JVM Service’ which handles all JDK/JRE needs in PowerBuilder environment

    • JDBC Connectivity

    • EJB Client Functionality

    • JSP Deployment

    • XSL-FO

  • Be aware…

    • Once Java VM is loaded, for whatever reason, by PowerBuilder, you cannot modify its environment, classpath, etc.; use return value of CreateJavaVM to determine if Java VM was actually loaded or already resident

    • Debug option for CreateJavaVM method is not available for JDK 1.4

    • Methods exist for determining the actual class for a returned interface, downcasting classes, determining interfaces implemented by classes, etc.


Powerbuilder ejb client implementation3
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

PowerBuilder JVM Service configuration

  • JDK and JRE Location can be specified in System Options dialog

  • JVM properties and CLASSPATH entries are in the registry

    • Design-time: \\HKLM\Sybase\PowerBuilder\9.0\Java\PBIDEConfig

      • PBJVMConfig

      • PBJVMProps

      • PBSysClasspath

    • Run-time: \\HKLM\Sybase\PowerBuilder\9.0\Java\PBRTConfig

      • PBJVMConfig

      • PBJVMProps


Powerbuilder ejb client implementation4
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

EJBConnection object

  • Analog of the PowerBuilder Connection object

  • Serves as a PowerBuilder façade to the InitialContext class within the PBEJBCLIENT90.JAR file

    • ConnectToServer - sets initialContext

    • DisconnectServer - closes initialContext

    • Lookup - returns EJBHome reference given JNDI name

    • GetEJBTransaction - returns reference enabling client-managed transactions

    • CreateJavaInstance – create a Java class within client Java VM

  • Be aware…

    • Properties array argument to ConnectToServer is the only ‘vendor-specific’ requirement; PowerBuilder doesn’t ‘know’ what EJB server you are using

    • CreateJavaInstance is used to create a Java class on the client – you don’t need an EJB server at all to do this!


Powerbuilder ejb client implementation5
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

EJBTransaction object

  • Populated by GetEJBTransaction method of the EJBConnection object

  • Wraps javax.transaction.UserTransactionand so providesmethods for initiating, coordinating, and completing a transaction from a client application

    • BeginGetStatus

    • Commit SetRollbackOnly

    • Rollback SetTransactionTimeout

  • Be aware…

    • Not all EJB servers support client-managed transactions

    • Best practices have a session bean on the server controlling the transaction


Powerbuilder ejb client implementation6
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

EJBLocator Java class

  • Single Java class residing in PBEJBCLIENT90.JAR:com.sybase.powerbuilder.ejb.EJBLocator

    • Four methods, all wrapped by the EJBConnection PBNI object

    • Required for deployed applications

  • JAR is included in CLASSPATH managed by JVM Service with the assumption that it is located relative to the PBJVM90.DLL


Powerbuilder ejb client implementation7
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

PowerBuilder proxy objects

  • Used to delegate requests to and from the underlying Java classes

  • Inherited from Nonvisualobject or Exception class like other PowerBuilder proxies

  • Generated using javap command in JDK

    • EJB Client Proxy wizard / project in PowerBuilder development environment

    • EJB2PB90 stand-alone utility

  • Includes

    • Public methods defined on its associated Java class

    • Public class variables in PowerBuilder 9.0.1 and later

  • To avoid conflicts with PowerBuilder reserved words, names may be decorated

    • Proxy name prefix “java_”, for example, java_integer

    • Method name postfix ”_j”, for example, and_j

  • Java methods that return arrays will return any in PowerBuilder

  • Proxies are also supported by a PowerBuilder mapping structure that correlates the PowerBuilder proxy name to the underlying Java class name


Powerbuilder ejb client implementation8
PowerBuilder EJB Client Implementation from PowerBuilder 9.0

Architecture Overview

Sample source for a PowerBuilder proxy object

$PBExportHeader$ejbobject.srx

$PBExportComments$Proxy imported from EJB via EJB Proxy generator.

global type EJBObject from Remote

end type

type variables

protected:

string EJBObject_javaname= "javax.ejb.EJBObject"

end variables

forward prototypes

public:

function EJBHome getEJBHome() throws RemoteException alias for

"getEJBHome,()Ljavax/ejb/EJBHome;"

function any getPrimaryKey() throws RemoteException alias for

"getPrimaryKey,()Ljava/lang/Object;"

subroutine remove() throws RemoteException, RemoveException alias for "remove,()V"

function Handle getHandle() throws RemoteException alias for "getHandle,()Ljavax/ejb/Handle;”

function boolean isIdentical( EJBObject EJBObject_1) throws RemoteException alias for

"isIdentical,(Ljavax/ejb/EJBObject;)Z"

end prototypes


Accessing third party ejb servers3
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Agenda

  • Overview of the Enterprise JavaBeans (EJB) Model

  • PowerBuilder EJB client implementation

  • Coding a PowerBuilder EJB client application

  • Deploying PowerBuilder NVOs to EJB servers

  • Additional resources


Coding a powerbuilder ejb client application
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

  • Setting up your environment

    • Adding the EJB client implementation to your target

    • Generating proxies

  • Basic client coding steps

  • Advanced topics


Coding a powerbuilder ejb client application1
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Setting Up Your Environment

Adding the EJB Client implementation to your target

  • Include PBEJBCLIENT90.PBD in your target’s library list


Coding a powerbuilder ejb client application2
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Setting Up Your Environment

Generating proxies

  • Use EJB Client Proxy Wizard

EJB home interface name must be same as remote interface name followed by ‘Home’


Coding a powerbuilder ejb client application3
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Setting Up Your Environment

Generating proxies

  • Use EJB2PB90.EXE, a completely stand-alone utility, and import resulting files into PowerBuilder target

  • Syntax: ejb2pb90 [-classpath pathlist] EJBName [prefix]

  • Output includes

    • Various .srx files – the proxy objects

    • ejbproxies.txt – listing the .srx files produced

    • ejbproxies.err – containing the diagnostic message in the event an error occurs while the proxies are generated

    • $EJBName$_ejb_pb_mapping.srs – the mapping structure


Coding a powerbuilder ejb client application4
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Basic client coding steps

  • Initialize the Java VM

  • Connect to the EJB Server

  • Lookup an EJB

  • Invoke methods on the EJB

  • Disconnect from the EJB Server


Coding a powerbuilder ejb client application5
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Basic Client Coding Steps

Initialize the Java VM

TRY

g_JavaVM = CREATE JavaVM

CHOOSE CASE g_JavaVM.CreateJavaVM(is_ClassPath, false)

CASE 0

// JVM just loaded

CASE 1

// JVM was already loaded, is_ClassPath ignored

CASE -1

// failure, likely due to not finding JVM.DLL

CASE -2

// failure, do to not finding EJBLocator class

END CHOOSE

CATCH (PBXRuntimeError prte)

// catch any exception raised in PBNI extension

END TRY


Coding a powerbuilder ejb client application6
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Basic Client Coding Steps

Connect to the EJB Server

TRY

g_EJBConn = CREATE EJBConnection

// set initial context properties

ls_props[1] = "javax.naming.Context.INITIAL_CONTEXT_FACTORY=" + &

"com.sybase.ejb.InitialContextFactory"

ls_props[2] = "javax.naming.Context.PROVIDER_URL=iiop://localhost:9000"

ls_props[3] = "javax.naming.Context.SECURITY_PRINCIPAL=jagadmin"

ls_props[4] = "javax.naming.Context.SECURITY_CREDENTIALS="

// connect to EJB server

g_EJBConn.connectToServer(ls_props)

CATCH (NamingException ne)

// naming exception may occur when initial context class not found

CATCH (PBXRuntimeError prte)

// catch any exception raised in PBNI extension

END TRY


Coding a powerbuilder ejb client application7
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Basic Client Coding Steps

Lookup an EJB

TRY

g_HelloHome = g_EJBConn.lookup("HelloHome", "PB9/Hello", "pb9.HelloHome")

g_hello = g_helloHome.create()

CATCH (NamingException ne)

// raised if EJB not located

CATCH (CreateException ce)

// raised if problem in instantiating EJB

CATCH (RemoteException re)

// raised whenever there is a unchecked exception on server

CATCH (PBXRuntimeError prte)

// raised whenever there is an exception in the PBNI extension

END TRY


Coding a powerbuilder ejb client application8
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Basic Client Coding Steps

Invoke methods on the EJB

TRY

MessageBox("Hello", g_hello.sayHello()

CATCH (YourCustomException yce)

// handle user-defined exception raised by EJB, for example, an exception

// indicating that an account lacks sufficient funds for withdrawal

CATCH (RemoteException re)

// raised whenever there is a unchecked exception on server

CATCH (PBXRuntimeError prte)

// raised whenever there is an exception in the PBNI extension

END TRY


Coding a powerbuilder ejb client application9
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Basic Client Coding Steps

Disconnect from the EJB server

TRY

g_EJBConn.disconnectServer()

CATCH (NamingException ne)

// naming exception is unlikely here, but could be thrown by underlying

// Java InitialContext object

CATCH (PBXRuntimeError prte)

// raised whenever there is an exception in the PBNI extension

END TRY

As in many distributed processing scenarios, disconnecting a client does NOT

automatically free server resources, such as stateful EJBs that the client was using.


Coding a powerbuilder ejb client application10
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced topics

  • java.lang.Object references

  • Using interfaces and casting

  • Client-managed transactions

  • Creating proxies for stand-alone Java classes


Coding a powerbuilder ejb client application11
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced Topics

java.lang.Object references

  • Many EJB methods will return java.lang.Object references or expect them as parameters

  • PowerBuilder will treat a java.lang.Object reference as a PowerBuilder any variable within the method prototype

  • The mapping structure created when generating proxies is consulted at run-time to map the underlying Java class to an appropriate proxy

global type Hello_ejb_pb_mapping from structure

string item1 = "java.rmi.Remote:Remote"

string item2 = "java.io.Serializable:Serializable"

string item3 = "java.io.IOException:IOException"

string item4 = "java.io.OutputStream:OutputStream"

string item5 = "java.io.FilterOutputStream:FilterOutputStream"

string item6 = "java.io.UnsupportedEncodingException:UnsupportedEncodingException"

string item7 = "java.io.PrintStream:PrintStream"


Coding a powerbuilder ejb client application12
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced Topics

Using interfaces and casting

  • Additional JavaVM object methods extend your capabilities

    • GetActualClass – determines the actual Java class name when provided a PowerBuilder proxy object that represents a Java interface

    • GetSuperClass – determines the Java class that is the ancestor of the Java class or interface represented by the PowerBuilder proxy object

    • GetInterfaces – returns list of Java interfaces implemented by the Java class represented by the given PowerBuilder proxy object

    • DynamicCast – casts a PowerBuilder proxy object to another object – typically used to downcast a Java reference, use cautiously since invalid casts can cause instability


Coding a powerbuilder ejb client application13
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced Topics

Using interfaces and casting – an example

Collection px_Collection

Vector px_Vector

Stack px_Stack

TRY

px_ListMgr = px_ListMgrHome.create()

px_Collection = px_ListMgr.getList(as_listType)

CHOOSE CASE g_JavaVM.GetActualClass(px_Collection)

CASE "java.util.Stack"

px_Stack = g_JavaVM.DynamicCast(px_Collection, "Stack")

DO WHILE TRUE

this.processItem(px_Stack.pop())

LOOP

CASE "java.util.Vector“

px_Vector = g_JavaVM.DynamicCast(px_Collection, “Vector”)

FOR i TO px_Vector.size()

this.processItem(px_Vector.elementAt(i))

NEXT

...


Coding a powerbuilder ejb client application14
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced Topics

Client-managed transactions

  • The EJBTransaction object in the PBNI implementation has a direct correspondence to javax.transaction.UserTransaction

    • Begin - starts a transaction

    • Commit - commits the current transaction

    • SetRollbackOnly - marks the current transaction as doomed

    • SetTransactionTimeout - sets the amount of time a transaction can be in progress before it is rolled back.

    • GetStatus - returns the status of the current transaction

  • Not all EJB servers support this and even if they do, best practices discourage its use


Coding a powerbuilder ejb client application15
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced Topics

Client-managed transactions – an example

EJBConnection conn

EJBTransaction trans

conn = create EJBConnection

TRY

conn.connectToServer(is_props)

trans = conn.getEJBTransaction()

trans.Begin()

// Create a component and call methods to be

// executed within the transaction

trans.Commit()

CATCH (Exception e)

trans.Rollback()

END TRY


Coding a powerbuilder ejb client application16
Coding a PowerBuilder EJB Client Application from PowerBuilder 9.0

Advanced Topics

Creating proxies for stand-alone Java classes

  • You can use the EJB client implementation to call Java classes on the client as well!

  • Create ‘dummy’ home and remote interface Java classes and reference the desired Java class as a method argument or return value

  • Generate proxies for this ‘pseudo’ EJB and the proxies for the referenced classes will be automatically generated

  • Now use the CreateJavaInstance method of the EJBConnection object to create instances of your Java class on the client (you can do this without issuing a ConnectToServer)

Dummy Home interface Java code

Dummy Home interface Java code

public interface DummyHome {}

public interface Dummy

{

public abstract void foo(com.your.JavaClass x);

}


Accessing third party ejb servers4
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Agenda

  • Overview of the Enterprise JavaBeans (EJB) Model

  • PowerBuilder EJB client implementation

  • Coding a PowerBuilder EJB client application

  • Deploying PowerBuilder NVOs to EJB servers

  • Additional resources


Deploying powerbuilder nvos to ejb servers
Deploying PowerBuilder NVOs to EJB Servers from PowerBuilder 9.0

Sunlly Group’s PBridge (http://www.sunlly.com)

  • Since PowerBuilder 7, you can use PowerBuilder NVOs natively in EAServer and have them interoperate with EJB components and Java clients

  • Sunlly PBridge’s offering will allow you to deploy your PowerBuilder components into other application servers such as WebLogic and WebSphere

    • Built on PBNI architecture offered by PowerBuilder 9

    • Currently in beta and supporting

      • BEA WebLogic

      • IBM WebSphere

      • Sun J2EE reference implementation

  • Visit them at TechWave!


Deploying powerbuilder nvos to ejb servers1
Deploying PowerBuilder NVOs to EJB Servers from PowerBuilder 9.0

Sunlly PBridge – Client Deployment Interface


Accessing third party ejb servers5
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Agenda

  • Overview of the Enterprise JavaBeans (EJB) Model

  • PowerBuilder EJB client implementation

  • Coding a PowerBuilder EJB client application

  • Deploying PowerBuilder NVOs to EJB servers

  • Additional resources


Accessing third party ejb servers6
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Additional Resources

InitialContext classes and default URLs for major EJB servers


Accessing third party ejb servers7
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Additional Resources

Learning more about the EJB client feature

  • PowerBuilder Extension Reference in product documentation set

  • EJB specification (http://java.sun.com/products/ejb/docs.html)

  • 3rd party J2EE server web sites

    • BEA Systems WebLogic Server (http://www.bea.com/framework.jsp?CNT=index.htm&FP=/content/products/platform/)

    • Jboss (http://www.jboss.org)

    • IBM WebSphere Application Server (http://www.ibm.com/websphere)

    • Oracle9iAS (http://http://www.oracle.com/ip/deploy/ias/)

  • SAMS Publishing PowerBuilder: Internet and Distributed Application Development (http://www.pb9book.com)

  • Sybase Developer Network (http://sdn.sybase.com)

    • Technical document: “Accessing 3rd Party EJB Servers from PowerBuilder 9” (http://www.sybase.com/detail?id=1024977)

    • CodeXchange…


Sdn presents codexchange
SDN Presents CodeXchange from PowerBuilder 9.0

Share PowerBuilder 9 Code and Tools

  • New SDN feature enables community collaboration

    • Download samples created by Sybase

    • Leverage contributions of others to exploit PBNI (i.e. PBNI CommonDialog, PBNI OLEObject utilities)

    • Contribute your own code or start your own collaborative project with input from other PowerBuilder experts

  • Any SDN member can participate

    • Log in using your MySybase account via SDN

  • Join the collaboration already underway

    • http://powerbuilder.codexchange.sybase.com or via SDN at www.sybase.com/developer

  • SDN & CodeXchange at TechWave

    • Technology Boardwalk

    • Sybase Booth Theater


Accessing third party ejb servers8
Accessing Third-Party EJB Servers from PowerBuilder 9.0

Questions


ad
