clinical trials of predictive medicine new challenges and paradigms

Clinical Trials of Predictive MedicineNew Challenges and Paradigms

Richard Simon, D.Sc.

Chief, Biometric Research Branch

National Cancer Institute

http://brb.nci.nih.gov

biometric research branch website brb nci nih gov
Biometric Research Branch Websitebrb.nci.nih.gov
  • Powerpoint presentations
  • Reprints
  • BRB-ArrayTools software
    • Data archive
  • Web based Sample Size Planning
    • Clinical Trials
    • Development of gene expression based predictive classifiers
why we need prognostic predictive biomarkers
Why We Need Prognostic & Predictive Biomarkers
  • Most cancer patients don’t benefit from the systemic treatments they receive
  • Being able to predict which patients are likely to benefit would
    • Benefit patients
    • Control medical costs
    • Improve the success rate of clinical drug development
slide7
Predictive biomarkers
    • Measured before treatment to identify who will or will not benefit from a particular treatment
      • ER, HER2, KRAS
  • Prognostic biomarkers
    • Measured before treatment to indicate long-term outcome for patients untreated or receiving standard treatment
      • Used to identify who does not require more intensive treatment
        • OncotypeDx
prognostic and predictive biomarkers in oncology
Prognostic and Predictive Biomarkers in Oncology
  • Single gene or protein measurement
    • ER protein expression
    • HER2 amplification
    • KRAS mutation
  • Index or classifier that summarizes expression levels of multiple genes
    • OncotypeDx recurrence score
most prognostic factors are not used
Most Prognostic Factors are not Used
  • They are developed in unfocused studies not designed to address an intended medical use
    • The studies are based on convenience samples of heterogeneous patients for whom tissue is available
  • Although they correlate with a clinical endpoint, they have no demonstrated medical utility
    • They are not “actionable”
types of validation for prognostic and predictive biomarkers
Types of Validation for Prognostic and Predictive Biomarkers
  • Analytical validation
    • Accuracy compared to gold-standard assay
    • Robust and reproducible if there is no gold-standard
  • Clinical validation
    • Does the biomarker predict what it’s supposed to predict for independent data
  • Clinical/Medical utility
    • Does use of the biomarker result in patient benefit
      • Is it actionable?
      • Generally by improving treatment decisions
clinical trials should be science based
Clinical Trials Should Be Science Based
  • Cancers of a primary site are generally composed of a heterogeneous group of diverse molecular diseases
  • The molecular diseases vary fundamentally with regard to the oncogenic mutations that cause them, and in their responsiveness to specific drugs
standard clinical trial approaches
Standard Clinical Trial Approaches
  • Based on assumptions that
    • Qualitative treatment by subset interactions are unlikely
    • “Costs” of over-treatment are less than “costs” of under-treatment
  • Have led to widespread over-treatment of patients with drugs to which few benefit
predictive biomarkers
Predictive Biomarkers
  • In the past often studied as exploratory post-hoc subset analyses of RCTs.
    • Numerous subsets examined
    • Not focused pre-specified hypothesis
    • No control of type I error
slide14

How Can We Develop New Drugs in a Manner More Consistent With Modern Tumor Biology and Obtain Reliable Information About What Regimens Work for What Kind of Tumors?

prospective drug development with a companion diagnostic
Prospective Drug Development With a Companion Diagnostic
  • Develop a completely specified genomic classifier of the patients likely to benefit from a new drug
  • Establish analytical validity of the classifier
  • Use the completely specified classifier to design and analyze a new clinical trial to evaluate effectiveness of the new treatment and how it relates to the classifier
guiding principle
Guiding Principle
  • The data used to develop the classifier must be distinct from the data used to test hypotheses about treatment effect in subsets determined by the classifier
    • Developmental studies are exploratory
    • Studies on which treatment effectiveness claims are to be based should be definitive studies that test a treatment hypothesis in a patient population completely pre-specified by the classifier
targeted design
Targeted Design
  • Restrict entry to the phase III trial based on the binary predictive classifier
slide18

Develop Predictor of Response to New Drug

Using phase II data, develop predictor of response to new drug

Patient Predicted Responsive

Patient Predicted Non-Responsive

Off Study

New Drug

Control

applicability of targeted design
Applicability of Targeted Design
  • Primarily for settings where the classifier is based on a single gene whose protein product is the target of the drug
    • eg trastuzumab
  • With a strong biological basis for the classifier, it may be unacceptable to expose classifier negative patients to the new drug
  • Analytical validation, biological rationale and phase II data provide basis for regulatory approval of the test
evaluating the efficiency of targeted design
Evaluating the Efficiency of Targeted Design
  • Simon R and Maitnourim A. Evaluating the efficiency of targeted designs for randomized clinical trials. Clinical Cancer Research 10:6759-63, 2004; Correction and supplement 12:3229, 2006
  • Maitnourim A and Simon R. On the efficiency of targeted clinical trials. Statistics in Medicine 24:329-339, 2005.
  • reprints and interactive sample size calculations at http://linus.nci.nih.gov
slide21
Relative efficiency of targeted design depends on
    • proportion of patients test positive
    • effectiveness of new drug (compared to control) for test negative patients
  • When less than half of patients are test positive and the drug has little or no benefit for test negative patients, the targeted design requires dramatically fewer randomized patients
trastuzumab herceptin
TrastuzumabHerceptin
  • Metastatic breast cancer
  • 234 randomized patients per arm
  • 90% power for 13.5% improvement in 1-year survival over 67% baseline at 2-sided .05 level
  • If benefit were limited to the 25% assay + patients, overall improvement in survival would have been 3.375%
    • 4025 patients/arm would have been required
biomarker stratified design

Develop Predictor of

Response to New Rx

Predicted Responsive

To New Rx

Predicted Non-responsive to New Rx

New RX

Control

New RX

Control

Biomarker Stratified Design
slide25
Do not use the diagnostic to restrict eligibility, but to structure a prospective analysis plan
  • Having a prospective analysis plan is essential
  • “Stratifying” (balancing) the randomization is useful to ensure that all randomized patients have tissue available but is not a substitute for a prospective analysis plan
  • The purpose of the study is to evaluate the new treatment overall and for the pre-defined subsets; not to modify or refine the classifier
  • The purpose is not to demonstrate that repeating the classifier development process on independent data results in the same classifier
analysis plan b limited confidence in test
Analysis Plan B(Limited confidence in test)
  • Compare the new drug to the control overall for all patients ignoring the classifier.
    • If poverall 0.03 claim effectiveness for the eligible population as a whole
  • Otherwise perform a single subset analysis evaluating the new drug in the classifier + patients
    • If psubset 0.02 claim effectiveness for the classifier + patients.
analysis plan c
Analysis Plan C
  • Test for difference (interaction) between treatment effect in test positive patients and treatment effect in test negative patients
  • If interaction is significant at level int then compare treatments separately for test positive patients and test negative patients
  • Otherwise, compare treatments overall
sample size planning for analysis plan c
Sample Size Planning for Analysis Plan C
  • 88 events in test + patients needed to detect 50% reduction in hazard at 5% two-sided significance level with 90% power
  • If 25% of patients are positive, when there are 88 events in positive patients there will be about 264 events in negative patients
    • 264 events provides 90% power for detecting 33% reduction in hazard at 5% two-sided significance level
simulation results for analysis plan c
Simulation Results for Analysis Plan C
  • Using int=0.10, the interaction test has power 93.7% when there is a 50% reduction in hazard in test positive patients and no treatment effect in test negative patients
  • A significant interaction and significant treatment effect in test positive patients is obtained in 88% of cases under the above conditions
  • If the treatment reduces hazard by 33% uniformly, the interaction test is negative and the overall test is significant in 87% of cases
does the rct need to be significant overall for the t vs c treatment comparison
Does the RCT Need to Be Significant Overall for the T vs C Treatment Comparison?
  • No
  • It is incorrect to require that the overall T vs C comparison be significant to claim that T is better than C for test + patients but not for test – patients
    • That requirement has been traditionally used to protect against data dredging. It is inappropriate for focused trials of a treatment with a companion test.
biomarker adaptive threshold design

Biomarker Adaptive Threshold Design

Wenyu Jiang, Boris Freidlin & Richard Simon

JNCI 99:1036-43, 2007

biomarker adaptive threshold design34
Biomarker Adaptive Threshold Design
  • Randomized trial of T vs C
  • Previously identified a biomarker score B thought to be predictive of patients likely to benefit from T relative to C
  • Eligibility not restricted by biomarker
  • No threshold for biomarker determined
  • Time-to-event data
procedure a
Procedure A
  • Compare T vs C for all patients
    • If results are significant at level .04 claim broad effectiveness of T
    • Otherwise proceed as follows
procedure a36
Procedure A
  • Test T vs C restricted to patients with biomarker B > b
    • Let S(b) be log likelihood ratio statistic
  • Repeat for all values of b
  • Let S* = max{S(b)}
  • Compute null distribution of S* by permuting treatment labels
  • If the data value of S* is significant at 0.01 level, then claim effectiveness of T for a patient subset
  • Compute point and bootstrap interval estimates of the threshold b
slide37
Estimated Power of Broad Eligibility Design (n=386 events) vs Adaptive Design A (n=412 events) 80% power for 30% hazard reduction
generalization of biomarker adaptive threshold design
Generalization of Biomarker Adaptive Threshold Design
  • Have identified K candidate predictive binary classifiers B1 , …, BK thought to be predictive of patients likely to benefit from T relative to C
  • Eligibility not restricted by candidate classifiers
slide39
Compare T vs C for all patients
    • If results are significant at level .04 claim broad effectiveness of T
    • Otherwise proceed as follows
slide40
Test T vs C restricted to patients positive for Bk for k=1,…,K
    • Let S(Bk) be log likelihood ratio statistic for treatment effect in patients positive for Bk (k=1,…,K)
  • Let S* = max{S(Bk)} , k* = argmax{S(Bk)}
  • Compute null distribution of S* by permuting treatment labels
  • If the data value of S* is significant at 0.01 level, then claim effectiveness of T for patients positive for Bk*
adaptive signature design

Adaptive Signature Design

Boris Freidlin and Richard Simon

Clinical Cancer Research 11:7872-8, 2005

adaptive signature design end of trial analysis
Adaptive Signature DesignEnd of Trial Analysis
  • Compare E to C for all patients at significance level 0.04
    • If overall H0 is rejected, then claim effectiveness of E for eligible patients
    • Otherwise
slide43
Otherwise:
    • Using only the first half of patients accrued during the trial, develop a binary classifier that predicts the subset of patients most likely to benefit from the new treatment T compared to control C
    • Compare T to C for patients accrued in second stage who are predicted responsive to T based on classifier
      • Perform test at significance level 0.01
      • If H0 is rejected, claim effectiveness of T for subset defined by classifier
slide44
Treatment effect restricted to subset.10% of patients sensitive, 10 sensitivity genes, 10,000 genes, 400 patients.
cross validated adaptive signature design to be submitted for publication

Cross-Validated Adaptive Signature Design(to be submitted for publication)

Wenyu Jiang, Boris Freidlin, Richard Simon

cross validated adaptive signature design end of trial analysis
Cross-Validated Adaptive Signature DesignEnd of Trial Analysis
  • Compare T to C for all patients at significance level overall
    • If overall H0 is rejected, then claim effectiveness of T for eligible patients
    • Otherwise
otherwise
Otherwise
  • Partition the full data set into K parts
  • Form a training set by omitting one of the K parts. The omitted part is the test set
    • Using the training set, develop a predictive classifier of the subset of patients who benefit preferentially from the new treatment T compared to control C using the methods developed for the ASD
    • Classify the patients in the test set as sensitive (classifier +) or insensitive (classifier -)
  • Repeat this procedure K times, leaving out a different part each time
    • After this is completed, all patients in the full dataset are classified as sensitive or insensitive
slide48
Compare T to C for sensitive patients by computing a test statistic S e.g. the difference in response proportions or log-rank statistic (for survival)
  • Generate the null distribution of S by permuting the treatment labels and repeating the entire K-fold cross-validation procedure
  • Perform test at significance level 0.05 - overall
  • If H0 is rejected, claim effectiveness of T for subset defined by classifier
    • The sensitive subset is determined by developing a classifier using the full dataset
slide49
70% Response to T in Sensitive Patients25% Response to T Otherwise25% Response to C20% Patients Sensitive
does it matter if the randomization in the rct was not stratified by the test
Does It Matter If the Randomization in the RCT Was Not “Stratified” By the Test?
  • No
  • Stratification improves balance of stratification factors in overall comparisons
  • Stratification does not improve comparability of treatment (T) and control (C) groups within test positive patients or within test negative patients.
  • In a fully prospective trial, stratification of the randomization by the test is only useful for ensuring that all patients have adequate test performed
biotechnology has forced biostatistics to focus on prediction
Biotechnology Has Forced Biostatistics to Focus on Prediction
  • This has led to many exciting methodological developments
    • p>>n problems in which number of genes is much greater than the number of cases
  • Statistics has over-focused on inference. Many of the methods and much of the conventional wisdom of statistics are based on inference problems and not applicable to prediction problems
slide52
p>n prediction problems are not multiple comparison problems
    • Feature selection should be optimized for accurate prediction, not for controlling the false discovery rate
  • Standard statistical methods for model building and evaluation are not effective
    • e.g. Fisher’s LDA vs diagonal LDA
    • Model performance on the training set is extremely misleading for p>n problems and should never be reported
slide53
Goodness of fit is not a proper measure of predictive accuracy
  • Statistical significance of regression coefficients or of the model is not a proper measure of predictive accuracy
slide54
Validation of a predictive model means that the model predicts accurately for independent data
  • Validation does not mean that the model is stable or that using the same algorithm on independent data will give a similar model
  • Validation of model prediction does not indicate that the model has medical utility for any intended use
prediction based clinical trials
Prediction Based Clinical Trials
  • Using cross-validation we can evaluate new methods for analysis of clinical trials in terms of their intended use which is informing therapeutic decision making
conclusions
Conclusions
  • New biotechnology and knowledge of tumor biology provide important opportunities to improve therapeutic decision making
  • Treatment of broad populations with regimens that do not benefit most patients is increasingly no longer necessary nor economically sustainable
  • The established molecular heterogeneity of human diseases requires the use new approaches to the development and evaluation of therapeutics
slide57
While developing and applying these new approaches, statisticians should continue to
    • Make sure that they are solving the right problem
    • Focus on the big picture
    • Prepare themselves to be full partners with their collaborators
acknowledgements
Acknowledgements
  • Boris Freidlin
  • Yingdong Zhao
  • Aboubakar Maitournam
  • Wenyu Jiang
