  1. Memory Barriers Dennis Byrnedennisbyrne@apache.org

  2. Defining the Problem Object connection = null; boolean initialized = false; // thread 1 writes twice // thread 2 reads twice connection = new Connection(); if(initialized) initialized = true; connection.use(); NullPointerException ?

  3. Root Cause: Memory Latency • Processors work hard to avoid memory latency • memory operations (reads & writes) are re-ordered • This is not a problem when … • data is local and/or immutable • there is only single processor • People do this also …

  4. Introduction Memory barriers, or fences, are a set of processor instructions used to apply ordering limitations on read and write operations.

  5. Visibility is “kind of” important • The Java Memory Model • Erlang send operators • Retlang and Jetlang Channels • C++ atomics • Scala Actors • Every semaphore, mutex, or atomic operation

  6. Consecutive Volatile Writes on Itanium 2 1 adds r37=592,r36;; ;...0b284149 0421 • st4.rel [r37]=r39 ;...00389560 2380 • adds r36=596,r36;; ;...84112544 4 st1.rel [r36]=r0 ;...09000048 a011 5 mf ;...00000044 0000 6 nop.i 0x0;; ;...00040000 7 mov r12=r33 ;...00600042 0021 8 mov.ret b0=r35,0x2000000001de81e0 The other side of the protocol ….

  7. Consecutive Volatile Reads on Itanium 2 1 adds r37=597,r36;; ;...84112554 2 ld1.acq r38=[r37];; ;...0b30014a a010 3 nop.m 0x0 ;...00000002 00c0 4 sxt1 r38=r38;; ;...00513004 5 cmp4.eq p0,p6=0,r38 ;...1100004c 8639 6 nop.i 0x0 ;...00000002 0003 7 br.cond.dpnt.many 0x2000000001de8220;; One side of the protocol ….

  8. Implicit Memory Barriers mov 0x160(%edi),%edi ;...8bbf6001 0000 mov %ecx,%edi ;...8bf9 add $0x8,%edi ;...83c708 lock cmpxchg %esi,(%edi) ;...f00fb137 mov $0x1,%eax ;...b8010000 00 Atomic CAS operation on x86 lock cmpxchg serializes pending memory operations

  9. Avoiding Memory Barriers Atomic CAS on a VMWare image with one processor: add $0x8,%edi ;...83c708 cmpxchg %esi,(%edi) ;...0fb137 mov $0x1,%eax ;...b8010000 00 Consecutive volatile reads in Java on SPARC: ld [ %l1 + 0x150 ], %i0 ;...f0046150 sethi %hi(0xff3fc000), %l0 ;...213fcff0 ld [ %l0 ], %g0 ;...c0042000 ret ;...81c7e008

  10. Memory Barriers Thanks Dennis Byrne – DRW Trading dennisbyrne@apache.org
