  1. Heat Engines Rev. Robert Sterling and the “Air Engine”

  2. History • R. Stirling minister of church of Scotland • Prolific inventor entire life • Suffered for the injuries of those in congregation

  3. Invention by Need • 1816 patent for air engine • Steam engines inefficient and prone to explosions • Called air engines until 1940’s use of other gases

  4. How does it Work? • Sealed cylinder one side hot one side cold • Working gas is moved from hot side to cold side

  5. Two Piston Type • Space above piston heated continuously • Space above cool piston is continuously cooled

  6. Physics Phun • Hot gas expands on piston producing pressure (P= F/A) • Cold gas moves to cold side contracts • Two power pulses per revolution

  7. Model engine

  8. But is it Efficient? • Mid 1800’s Carnot determined maximum efficiency of heat engines • Temp hot side—Temp cold side Temp of hot side X 100 Equals maximum efficiency

  9. Carnot Cycle

  10. Efficiency • Stirling engines theoretically reach 100% • Practical examples reach 50% • Gasoline engines struggle to reach above 30%

  11. Why don’t I drive a Sterling Engine • Does not start instantly, requires extensive warm up • Identical problem occurs in fuel cells • Low fuel prices work against efficient engine that does not start instantly

  12. Used on SS (Swedish Subs)

  13. APU’s • Auxiliary power units for electrical generation on Yachts • Quiet, smooth power • Expensive

  14. Cryocoolers • Stirling engines are reversible • Heat in power out • Power in heat consumed • Extremely cold temp to 10° K

  15. Micro coolers • Manufactured in large numbers to cool infrared chips • Used to cool night vision devices • May have applications for space use

  16. Future? • Extensive research in Europe for efficiency advances • Application specific designs • Manufacturing methodology’s
