slide1

Presentation of company Koramex a.s. (Czech republic)

Who is Koramex ?

1st.

For railway vehicles

2nd.

Switchgear cabinets

Main field of activity is welding of construction parts

… and complete custom manufacturing

The company with 15 years old tradition

Koramex is looking for new orders to fill free space and production capacity

We´re certified

… it continues

slide2

CERTIFICATE (since 2005)

From SLV HANNOVER

DIN 6700-2 C2 for welding for railways

slide3

CERTIFICATE (since 2008)

From SVV PRAHA

ČSN ISO 9001:2001 quality certificate

and ČSN ISO 3834-2:2006 welding certificate (+ attachment) – since 2004, recertified in 2008

slide4

CERTIFICATE (since 2010)

From SLV HANNOVER

Certificarte level CL2 according to

DIN EN 15085-2

Welding of railway vehicles and vehicle parts

Page 1

slide5

CERTIFICATE (since 2010)

From SLV HANNOVER

Certificarte level CL2 according to

DIN EN 15085-2

Welding of railway vehicles and vehicle parts

Page 2

slide6

ABOUT CERTIFICATES

Since 2004 was our company introduced a certified welding

rolling stock CSN EN 729 (recertified in 2008 CSN EN 3834-2).

Since 2005 the company was certified by SLV Hannover

DIN 6700-2 C2 for welding rolling stock for railways.

2008 :

The company obtained the quality certificate according to CSN EN ISO 9001:2001.

Now we have quality certificate according to CSN EN ISO 9001:2009.

2010 :

Koramex received certificate according to DIN EN 15085 – 2 (CL2).

slide7

Workplaces

We provide metalworking at three workplaces – Sušice, Tedražice and Čejkovy.

Construction activity is performed at the workplace Klatovy.

Čejkovy :

1) production area approx 3200 m2.

2) 20 workers

Sušice :

1) production area approx 1500 m2.

2) 20 workers

Tedražice:

1) production area approx 2000 m2.

2) 60 workers

TEDRAŽICE :

We´ll build a new production hall at the beginning of 2011. It will have area of cca 1300 m2.

This is linked with the purchase of a new machinery, including the second laser CNC cutting machine.

slide8

EQUIPMENTS – for sheet metal proccesing

CNC Laser cutting machine Traumatic L- 3030 (Trumpf)

CNC shear machine (B-Shear)

2 CNC punching machines

Punching sheets up do 4mm, stainless steel sheets up. 2.5 mm

(Euromac)

4 CNC pressbrakes

(Trumpf, Safan, Amada, COT)

slide9

EQUIPMENTS – for sheet metal proccesing

Cutting machine

CNC Scorpion 2500

with a plasma cutter CEBORA 162

to cut up to 16 mm

and oxyacetylene torch HARRIS

the burning materials up to 200 mm

Of exhausting the table is2000 x 4000 mm

Other machine and metalwork using traditional tools - drills, lathes, milling machines, band saws and shears

slide10

EQUIPMENTS - for welding

  • Certified weldingprocessDIN 6700- 2
  • Certified welders
  • Processes of steel, aluminiumand stainlesssteel
  • (TIG , MIG, MAG) according toEN 287 - 1, EN ISO 9606-2
  • Resistance welding process and stud welding
  • according to ČSN EN 1418
  • Certified Welding process according to standard
  • ČSN EN ISO 3834-2
  • Computer controlled weldingmachines
slide11

EQUIPMENTS – for surfacing

Degreasing

device

Electric furnace

KWEN

Powder device NORDSON

Modern finish with powder coating pre-treatment phosphate and degreasing, the largest dimensions of the products 2250 x 1200 x 1000 mm, weight 150 kg.Pickling of stainless steel and aluminum products..

slide12

Our customers

ZAT Controls

ŠKODA Plzeň

Faiveley s.a.

Metrostav

ČD Cargo

Bücheler a.g.

AM-CME, Přeštice

Invelt Energo spol. s r.o., Plzeň

Abroad

In Czech republic

slide13

TRACTION

DRIVERS

(welding constructions)

OUR PRODUCTS – for Škoda Pilsen

Roof unit

FOR

TROlleybus

ROOF UNIT FOR TRAM

DRIVER UNIT FOR METRO

slide14

USING OF OUR PRODUCTS

TRAM

(city riga)

Trolleybus

irisbus

Trolleybus

solaris

slide15

Switchboard

boxes

(welding constructions)

OUR PRODUCTS – for ZAT Controls

Model series of krx

To the switchboard is possible to place 3 fields

Model series of srts

slide16

CONTACTS

HEADOFFICE

MANAGING DIRECTOR

KORAMEX a.s.Pražská 268342 01 Sušicetel.: + 420 376 503 821fax: + 420 376 503 825   koramex@koramex.cz

Dipl.Ing. Petr Makrlíktel.: + 420 376 503 821fax: + 420 376 503 825   petr.makrlik@koramex.cz

workplace

200

workplace

100

workplace

300

Středisko TedražicemetalworkingTedražice 79342 01 Sušicetel.: + 420 376 524 216fax: + 420 376 524 315   tedrazice@koramex.cz

Středisko SušicemetalworkingPražská 268342 01 Sušicetel.: + 420 376 503 821fax: + 420 376 503 825   susice@koramex.cz

Středisko ČejkovymetalworkingČejkovy 85342 01 Sušicetel.: + 420 371 651 320fax: + 420 376 651 332   cejkovy@koramex.cz

slide18

End of our prezentation

Thank you for your attention .

On behalf of our company I would like to thank you for your participation.
