  1. Final Project ReviewAirframe A P09231 MSD II Spring 20083

  2. Team Members • Matt Greco: Project Manager • Shawn O’Neil: Lead Engineer • Will Pisarello: Electrical Systems Engineer • Phil Davenport: Industrial/Process Engineer • Brian Lindquist: Industrial Engineer/Procurement Specialist • Eric Lannan: Airframe Structural engineer

  3. Systems Integration

  4. Structural Analysis of Wing • Balsa Material Properties • Young’s modulus • 1130 – 6000 Mpa • Shear modulus • 100 - 500 MPa • Tensile strength • 0 - 75 MPa • Compressive strength • 3.5 - 27 Mpa • Material properties from Matbase.com. • http://www.matbase.com/material/wood/class4-5-10-years/balsa/properties y 5lb 5lb x 10lb

  5. Flight Testing Discoveries

  6. Uses: - Autonomous system testing with pilot backup - Control ‘hand off’ between pilots a significant distance apart for extended range flights Control Switching ~$50 total per system. Enables onboard control switching between two pilots or a single pilot and an autonomous system

  7. Expense Sheet
