**CSci 4011**INHERENT LIMITATIONS OF COMPUTER PROGAMS**string**pop push ε,ε → $ 0,ε→ 0 1,0→ε ε,$ → ε 1,0→ε The language of P is the set of strings it accepts.**CONTEXT-FREE GRAMMARS**A → 0A1 A → B B → # A 0A1 00A11 00B11 00#11 A derives 00#11 in 4 steps. The language of G is the set of strings derived by S.**VERY INTERESTINGCFGs…**http://java.sun.com/docs/books/jls/third_edition/html/j3TOC.html http://docs.python.org/reference/grammar.html**PARSE TREES**A A A B 0 0 # 1 1 A 0A1 00A11 00B11 00#11**Definition. T is a parse tree for the derivation**S ⇒* w under grammar G = (V,Σ,R,S) if 1. The root of T has label S 2. The leaves of T have labels wi∈ Σ 3. The non-leaf nodes have labels v ∈ V 4. For each node with label v ∈ V and children with labels ri∈ (V∪Σ), (v→r) ∈ R.**<EXPR>**<EXPR> <EXPR> <EXPR> <EXPR> <EXPR> <EXPR> <EXPR> <EXPR> <EXPR> a + a x a a + a x a <EXPR> → <EXPR> + <EXPR> <EXPR> → <EXPR> x <EXPR> <EXPR> → ( <EXPR> ) <EXPR> → a Build a parse tree for a + a x a**COMPILER MODULES**LEXER PARSER SEMANTIC ANALYZER TRANSLATOR/INTERPRETER**Suppose L is generated by a CFG G = (V, Σ, R, S)**Construct P = (Q, Σ, Γ, , q, F) that recognizes L A Language is generated by a CFG It is recognized by a PDA Idea: P will derive w ∈L on its stack.**(1) Place the marker symbol $ and the start variable on the**stack Suppose L is generated by a CFG G = (V, Σ, R, S) Construct P = (Q, Σ, Γ, , q, F) that recognizes L (2) Repeat forever: (a) If v is in the stack, and (v → s) ∈ R, push s on the stack (b) If stack is a string, goto (3) (3) Loop until stack is empty: (a) if top of stack matches input, pop. (b) on (ε,$), accept.**Suppose L is generated by a CFG G = (V, Σ, R, S)**Construct P = (Q, Σ, Γ, , q, F) that recognizes L (qstart) Push S$ and go to qloop (qloop) Repeat the following steps forever: (a) On (ε,v) where (v → s) ∈ R, push s and go to qloop (b) On (,), pop and go to qloop (c) On (ε,$) go to qaccept (else) get stuck!**ε,ε → S$**ε,A → w for rule A → w a,a → ε for terminal a ε,$ → ε**S → aTb**T → Ta | ε ε,ε → $ ε,ε → T ε,S → b ε,ε → T ε,ε → S ε,T → a ε,$ → ε ε,ε → a ε,T → ε a,a → ε b,b → ε**A Language is generated by a CFG** It is recognized by a PDA **A Language is generated by a CFG** It is recognized by a PDA Given PDA P = (Q, Σ, Γ, , q, F) Construct a CFG G = (V, Σ, R, S) such that L(G)=L(P) First, simplify P so that: (1) It has a single accept state, qaccept (2) It empties the stack before accepting (3) Each transition either pushes a symbol or pops a symbol, but not both**SIMPLIFY**ε,ε → $ 0,ε→ 0 q1 q0 1,0→ε ε,ε → 0 ε,ε → ε ε,$ → ε q2 q3 1,0→ε ε,ε → 0 ε,ε → ε q4 ε,0 → ε q5**Idea: for each pair of states p and q in P, the grammar will**have a variable Apq that generates all strings that that can take P from p to q without changing the stack* V = {Apq | p,qQ } S = Aq0qaccept *starting from any stack S in p, P has stack S at q.**ε,ε → $**0,ε→ 0 q1 q0 1,0→ε ε,ε → 0 ε,$ → ε q2 q3 1,0→ε ε,ε → 0 q4 ε,0 → ε q5 none What strings does Aq0q1 generate? {0n1n | n > 0} What strings does Aq1q2 generate? What strings does Aq1q3 generate? none**Apq generates all strings that take P from p to q without**changing the stack Let x be such a string • P’s first move on x must be a push • P’s last move on x must be a pop Consider the stack while reading x. Either: 1. The first repeat comes at the end of x 2. The stack repeats before the end of x**1. The first repeat is at the end of x:**stack height r s a b input string p q Apq→ aArsb**2. The stack repeats before the end of x:**stack height input string p r q Apq→ AprArq**Formally:**V = {Apq | p,qQ } S = Aq0qaccept For each p,q,r,s Q, t Γ and a,b Σε If (r,t) (p,a,ε) and (q, ε) (s,b,t) Then add the rule Apq→ aArsb For each p,q,r Q, add the rule Apq→ AprArq For each p Q, add the rule App→ ε**ε,ε → $**0,ε→ 0 q1 q0 1,0→ε ε,ε → 0 ε,$ → ε q2 q3 1,0→ε ε,ε → 0 q4 ε,0 → ε q5 Aqq→ ε Apq→ AprArq Aq0q3 → εAq1q2ε Aq1q2 → 0Aq1q21 Aq1q2 → 0Aq1q11 none What strings does Aq0q1 generate? {0n1n | n > 0} What strings does Aq1q2 generate? What strings does Aq1q3 generate? none**A Language is generated by a CFG** It is recognized by a PDA
