LABNICS-Digital-Vernier-Caliper-NDVC-100

Digital vernier caliper NDVC-100 is a measuring device that is used for the measurement of the linear dimensions. It consists of a main scale with a fixed jaw and a sliding jaw with an attached vernier. It is made up of carbon steel with a resolution range of 0.1mm/0.01.

labnics14
Download Presentation

LABNICS-Digital-Vernier-Caliper-NDVC-100

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. DIGITAL VERNIER CALIPER NDVC-100

  2. DIGITAL VERNIER CALIPER NDVC-100 Digital vernier caliper NDVC-100 is a measuring device that is used for the measurement of the linear dimensions. It consists of a main scale with a fixed jaw and a sliding jaw with an attached vernier. It is made up of carbon steel with a resolution range of 0.1mm/0.01. FEATURES ⇋ Consists of two steel rules which can slide along with each other ⇋ Outside jaws (upper fixed jaws): used to measure external diameter or width of an object ⇋ Inside jaws (lower sliding jaws): used to measure internal diameter of an object ⇋ Metal strip at the back of the vernier caliper to measure the internal depth of a cylinder. SPECIFICATIONS Product range Material Resolution Blade texture Accuracy Calibration process Battery model Packing 0-150mm Carbon steel 0.1mm/0.01 PA66 high strength plastic cement ±0.1mm/0.01 Magnetic stripe sticker SR44/LR44 1.5v button battery Transparent box packaging (103G)/transparent bag packaging (58G)/paper cards packaging (82G) Silver 24×15×9 cm 54g Color Packaging dimensions Net weight of caliper: APPLICATIONS Vernier caliper NDVC-100 is widely used in scientific laboratories to measure the distance between two opposing sides of a surface and in industries for quality control measurements.

  3. Labnics product catalog Generated on: 18/01/2023 Labnics Equipment Ltd. 272 Bath Street, Glasgow, G2 4JR UK Email: info@labnics.com | Website: www.labnics.com | Phone: +44 755 143 4216
