  1. BIOLOGICAL MICROSCOPE NBM- 100

  2. BIOLOGICAL MICROSCOPE NBM-100 Biological Microscope NBM-100 is an optical instrument that aids in the visualization of microscopic biological entities that are invisible to the naked eye. It is a bright field, LED ergonomic microscope designed to visualize various biological specimens with precise focusing system. It features a coaxial positioning system and a coarse/fine adjustment knob that enables observations of microscopic fields in high resolution. FEATURES ⇋ White LED lamp/halogen lamp illuminator ⇋ Mechanical double layer stage made of platinum with overhang ⇋ Wide field eyepiece ⇋ Dioptre adjustment on the left eyepiece ⇋ Rubber grip around fine and coarse adjust knob ⇋ Tension adjustment of coarse regulation knob ⇋ Upper limit stopper to protect the lens and the sample SPECIFICATIONS Viewing head Eyepiece Objective Horizontal 45° inclined binocular Wide Field Eyepiece WF10×, WF16×(Optional) Achromatic Objective 4×, 10×, 40×（S）100×（S, Oil) ； Quadruple Nosepiece Double layers moving stage 140×140mm; Moving range 75×50mm Coaxial Coarse & Fine Focus Adjustment System, Focusing range 28mm，Fine focusing scale value 0.002mm ABBE Condenser: N.A 1.25 Nosepiece Stage Focusing condenser illumination S-LED lamp with brightness adjustable Plan-concave Mirror Gross weight 6kg

  3. APPLICATIONS Biological Microscope NBM-100 is widely used for microscopic examination of biological specimens, test samples in healthcare and research organizations, industries, agriculture and biotechnological laboratories, food processing and developmental research studies, etc.

  4. Labnics product catalog Generated on: 02/01/2023 Labnics Equipment Ltd. 272 Bath Street, Glasgow, G2 4JR UK Email: info@labnics.com | Website: www.labnics.com | Phone: +44 755 143 4216
