  1. DCS（ADC&RFID) -数据采集解决方案

  2. SCANNER NAMING CONVENTIONS LS-3408-FZ • LS = Laser Scanner • Decodes all 1D barcodes, some can decode PDF417. • DS = Digital Scanner • Imager, not laser. Decodes all 1D and 2D barcodes. • MS = Mini Scan • Fixed Mount, laser and imager models • MT = Mobile Terminal Laser and imager models MK = Micro Kiosk Laser and imager models CS = Consumer Scanner Laser model only CA = Communication Appliance Laser model only SE = Scan Engine Laser and imager models LI = Linear Imager Decodes all 1D barcodes MP= Multi Plane Imager Decodes all 1D/2D barcodes

  3. SCANNER NAMING CONVENTIONS LS-3408-FZ • LS-1203 = Value • LS-2208 = Mid-Range • LS-4208 = Premium • LS-4278 = Premium • DS-670X = Mid-Range • DS-6878 = Premium • LS-7708 = On-Counter, Premium • LS-7808 = In-Counter, Premium • LS-9203 = Hands Free, Value • LS-9208 = Hands Free, Mid-Range • DS-9808 = Handheld/Hands Free, Premium • LS-3008 = Value • LS-3408 = Mid-Range • DS-3408* = Mid-Range • DS-3478* = Proprietary BT, Premium • LS-3578 = Open BT, Premium • DS-3508 = Mid-Range • DS-3578 = Open BT, Premium MS-954 = Single-line Laser, Value MS-12XX = Single-line Laser, Premium MS-22XX = Rastering Laser MS-32XX = Omni-directional Laser MS-44XX = Imager MiniScan General Purpose Scanner Family Clues -3XXX = Rugged -7XXX = Mini-Slot/Presentation -9XXX = Hands Free/Presentation -X478 = Proprietary Bluetooth -X578 = Open Bluetooth Rugged *EOL

  4. SCANNER NAMING CONVENTIONS LS-3408-FZ • Corded or Cordless • 0 = Corded/Wired • 7 = Cordless/Wireless Bluetooth • 9 = Cordless/Wireless Bluetooth & Wi-Fi

  5. SCANNER NAMING CONVENTIONS LS-3408-FZ • Host Type • 0 = Undecoded (scan engines) • 3 = Limited Multi-host (RS-232, KBW, & USB) • 4 = RS-232 (miniscans or discontinued products) • 5 = IBM (discontinued products) • 7 = RS-232 and USB (used for high speed data transfer, such as sending captured images) • 8 = Full Multi-host(RS-232, KBW, USB, IBM, Synapse*)

  6. SCANNER NAMING CONVENTIONS LS-3408-FZ • Laser Descriptor • ER = Extended Range • FZ/FZY = Fuzzy Logic • PR = PDF • SR = Standard Range • WA = Wide Angle • VHD = Very High Density • Imager Descriptor • DC = Document Capture • DL = Driver License parsing • DP/DPM = DPM (Direct Parts Marking) • HD = High Density • R= RFID • SF = Smart Focus • SR = Standard Range • Industry Specific • HC = Health Care

  7. DCS产品组合 General Purpose Rugged Scanners Micro Kiosks RFID Handheld Hands-Free DS9808 Series MT2000 Series DS6878 Series DS457 Series MC9190Z Premium MK4000 DS6700 Series LS7808 DS35X8 Series FX9500 LS7708 DS4208 Series FX7400 LS3408/ LS3578 Series DS9208 Series Mid Range LI4278 MK3100 LS4208 MC3190Z LS2208 Value LS1203 LS3008 MK500 CS3000 Series DS9808-R

  8. 适合你工作方式的产品从生产制造车间到零售店面适合你工作方式的产品从生产制造车间到零售店面 桌面式 固定式 固定式 手持式 手持式 移动式 • 工业 • 仓库&配送 • 供应链 • 生产制造 • 能源 FX9500 MC9190-Z RFID RD5000 NA APAC only • 企业 • 零售库存管理 • 资产管理 • 文件追踪 • 医疗 FX7400 MC3190-Z DS9808-R NA LA only

  9. DCS 2013 Planned Product Releases Q1/13 Q2/13 123 Scan2 v 3.0 Scanner configuration & staging Scanner SDK 1.3 Application development “Thunder” (LI2208) Corded 1D Linear Imager FCS 6/28/13 SMS 4690 4.0 IBM Enterprise Scanner Management MK3100 8” WVGA Micro Kiosk MPA 3.0 Windows CE 7.0 FCS 3/26/13 MP6000 Multi plane imager & scale 2D Full Imaging Based Multi Optic Fully Solid State FCS 6/28/13 MOT Tools 1.0 Post Sale Upgrades Windows SMS 2.0 Enterprise Scanner Management Q4/13 Q3/13 MP6000 CSS Multi plane imager CSS Consumer Side Scanner Scans Paper & Mobile 1D and 2D loyal/coupons FCS 7/31/13 MP6000 DL Parsing FCS 7/31/13 Dual Interval Scale FCS 8/30/13 Remaining POS I/F FCS9/30/13

  10. DS9808, DS457, DS9208, 1D9208投射式扫描器独有特征和关键技术差异 ▪ 2D投射式成像仪扫描器 ▪ 独特的符合人体工学的手持/免提“混血”外观 ▪可读取传统纸质标签和手机屏幕上的条码 ▪ 附加OCR，驾照分析，可升级RFID，长距引擎等功能 ▪ 出色的“刷扫”性能 DS9808 • - 零售 • 政府 • 商业 • 运输和物流 高端 • 零售 • 酒店业 • 面向客户的运输业 • 电子/药品制造 DS457 ▪ 超小型2D投射式成像仪扫描器 ▪ 驾照分析选项 ▪ 可读取传统纸质标签和手机屏幕上的条码 中端 DS9208 • 零售 • 酒店业 • 面向客户的运输业 • 轻工业 –在制品 ▪ 2D投射式成像仪扫描器 ▪ 驾照分析选项 ▪可读取传统纸质标签和手机屏幕上的条码 ▪手持模式 中端 1D9208 ▪ 线性成像仪投射式扫描器 ▪ 替代LS920X ▪ 首度识别率高 ▪ 支持拣选模式 • 零售 • 酒店业 • 图书馆 经济

  11. DS9208 vs. 1D9208

  12. ▪ 适合床边管理、医院药局、和病理实验室的2D无绳蓝牙医疗成像仪扫描器 ▪ 电池可由USB连接直接充电，无需电源适配器 DS6878-HC • 医疗: 治疗点 • 推车计算机（COW/WOW）集成, 实验室工作站 • 医疗: 治疗点 • 推车计算机（COW/WOW）集成, 实验室工作站 DS4208-HC ▪适合病房、医院药局、和病理实验室2D无绳蓝牙医疗成像仪扫描器 ▪ 可消毒的外壳塑料材质可承受多种化学消毒剂的擦拭和清洁 ▪ 为推车计算机（COW/WOW)部署设计 ▪ 超级耐用: 6 ft/1.8m跌落指标 医疗产品 的共同特征 医疗产品线 独有特征和关键技术差异

  13. LS3000系列独有特征和关键技术差异 ▪ 标准聚焦，为读取1D条码而优化 (Code 39 5mil纸质条码读取距离为1.25”-5.25”) ▪ IP53封装: 防尘，可承受在小雨内工作 ▪ 无排线、单电路板结构，消除最常见的接触点故障 ▪ 液态聚合体扫描组件提供终生保固。 • - 库房 • 工业制造 • 零售库房 LS3008 LS3408-FZ & LS3578-FZ • -库房 • 物流运输 • 工业制造 • 零售库房 ▪ 蓝牙无线模式和批处理模式* ▪ IP65封装—绝对防尘并可承受直接水流喷射 ▪标准焦距，“模糊逻辑” 软件为读取不良印刷、磨损、损坏的1D条码提供优化 (读取55 mil纸质条码距离可达84”) ▪蓝牙无线模式和批处理模式* ▪ IP65封装—绝对防尘并可承受直接水流喷射 ▪ 同级最佳的远距离1D条码扫描功能 (100mil反射型条码的识读范围为0.25” /0.64cm 到 45ft./13.7m) • -库房 • 物流运输 • 工业制造 • 零售库房 • - 叉车作业 LS3408-ER & LS3578-ER • ▪ 标准蓝牙技术带来没有线缆羁绊的自由。 • ▪1.2版蓝牙支持自适应调频 • - 室外、无遮挡环境长达300 ft的工作距离 (室内典型值是100 ft) • - 可以直接与任何标准蓝牙设备通信 LS3578 -ER & -FZ 无绳产品特征 *LS3578-ER 和LS3578-FZ 型号支持蓝牙和批处理模式，详情请联络本地Motorola销售代表。

  14. DS35X8-SR DS35X8-HD DS35X8-DP DS3500系列独有特征和关键技术差异 ▪ 标准焦距扫描较大条码。 ▪ 为扫描1D 和 2D条码而优化。 • -库房 • 物流运输 • 工业制造 • 零售库房 • 生产线 • 电子或制药行业 • 小型或密集的1D 和 2D纸质条码标签 ▪ 近焦扫描，为扫描小型、高密1D 和 2D条码而优化 ▪ 意味着可以在生产线上从固定距离扫描小型条码，并可读取 3x3mm条码。 ▪ 适合读取高密1D, 2D 和直接部件标记(DPM)条码，具备IUID解析功能。（ Item Unique IDentification ） ▪ 可读取点阵冲击，激光蚀刻，化学蚀刻、热转印，墨标等方式的DPM条码。 (销售DPM产品，合作伙伴需要DPM认证) • - 自动化生产 • 航空航天 • 工业生产 • 政府 • 库房/运输物流 • 工业制造 • 零售库房 • - 叉车作业 DS35X8-ER ▪ 延展读取距离的成像仪扫描器，可读取30英尺以上距离的1D和2D条码。 ▪ 图像采集和传输功能 ▪增强免提模式, 智能座上运动容错达100 in./sec. (100% UPC) DS3508 有绳产品特征 • ▪ 标准蓝牙技术带来没有线缆羁绊的自由。 • ▪1.2版蓝牙支持自适应调频 • - 室外、无遮挡环境长达300 ft的工作距离 (室内典型值是100 ft) • - 可以直接与任何标准蓝牙设备通信 • ▪ 不支持图像采集和传输 DS3578 无绳产品特征

  15. MK500, MK3000/MK3100, & MK4000独有特征和关键技术差异 ▪ 3.5”屏幕; QVGA触摸屏 ▪ 3个可编程按钮 ▪ Microsoft CE 5.0 操作系统 ▪ XScale 520 MHz 处理器 64MB SDRAM/ 64MB Flash 通过外部Micro SD插槽可扩充闪存至8GB MK500 MK3000/3100 ▪8”WVGA电阻触屏 ▪ 集成耳麦接口 ▪4个功能键 ▪Microsoft CE 5.0 / Embedded Compact 7操作系统 ▪12.1” 彩色SVGA LCD 触屏 ▪ 集成耳麦接口和麦克风 ▪ Microsoft CE 5.0 操作系统 ▪ XScale™ 624 MHz 处理器 128MB SDRAM/64 MB Flash 通过外部Micro SD插槽可扩充闪存至8GB MK4000 ▪ 拥有集成激光和成像仪扫描器的型号，均提供世界级扫描科技。 ▪ 大屏幕，方便用户信息交互 ▪ 利用标准的windows开发工具，节省开发时间 ▪ 支持移动条码:成像仪扫描器可以从手机屏幕扫描条码 ▪无线802.11 a/b/g 或以太网网络选项 (MK500/3000支持PoE) 共同特性

  16. MC3100 Product Features • BT Support and Mini USB ports • Enables connectivity to a multitude of peripherals (mouse, keyboard, printer, etc…) • Micro SD slot • Supports up to 32GB • Physicalkeys • Four physical keys • Standard VESA mounting • Standard mounting system allows the use of third party mounting solutions • Audio capability • Integrated speakers, microphone and headset jack

  17. MK3100 vs MK3000 • New OS – Embedded Compact 7 vs CE 5.0 • New Hardware Architecture (TI, 1GHz) • allows for development of more interactive applications • Ability to play full screen video • Better performance on mobile barcodes • New Wireless capabilities – 802.11n + BT PAGE 55

  18. MP6000 Customer Side Scanner Capacitive buttons through the glass 100% 2D imager scanner 13cm/5” Tall Tower (vertical scan cabinet) 10cm/4” Deepto suitall markets Standardsix-sided scanning Very LargeVerticalWindow Sapphire Horizontal Glass ExpansionPortsfor addingHH Scanner,Sensormatic … Checkpoint EAS in every MP6000

  19. MP6000 Multi Plane Imager Six sided scanning • Omni-directional symbol orientation Blazing swipe speed Cell phone 1D/2D • Omni-directional symbol orientation Difficult symbols with ease • Truncation • Low contrast • Voids in thermal bar codes

  20. MP6000 Multi Plane Imager 2D Full Imaging based multi-optic scanner • Dual camera, 1.2MP B&W CMOS array • NOT a hybrid scanner • Fully Solid State • No lasers, no motors, no moving parts • Increased reliability • Reduced power consumption • Silent operation at idle • 800 MHz Freescale CPU • Supports multi-plane image capture up to 50” per second

  21. MP6000 Multi Plane Imager • Checkpoint EAS in every unit • Interlock via optional cable • High Inductance Sensormatic Coils • Compatible with existing Sensormatic controllers • Low Power Consumption • Up to 50% less than old style laser bi-optics • No Moving Parts • MTBF measured in decades (~ 38 years)

  22. MP6000 Multi Plane Imager • Compatible with existing industry standard checkstand slots • Three scanner lengths: • 13.9” • 15.7” • 19.95” • Standard width is 11.5” • Accessory to match NCR scale models at 12” • Drop in replacement into existing checkstands

  23. MP6000 Multi Plane Imager • Single and Dual Interval range scales • Single range scale have same resolution for entire weight range • Dual range scales change resolution after a certain weight is reached • Scale is available for 39.9 cm (15.7”) and 50.7 cm (19.95”) length scanners • Factory and/or field installation • Field installation not allowed in all countries: check with PM first • Scale Display • Single or dual display option • Price computation scales from Bizerba and Mettler • One quarter after initial FCS

  24. MP6000 Multi Plane Imager • USB or RS-232 auxiliary handheld scanner support via peripheral ports • There are two RS-232 Aux ports and three USB Aux ports • Hand-held scanners are only supported when in USB HID or in Motorola Standard RS232 mode • A total of one auxiliary scanner and a Customer Side Scanner (CSS) are supported via USB and RS232 ports • CSS is USB only • Only Motorola hand-held scanners can be managed via 123Scan2/SMS through the multi-optic host scanner AUX A-B J7 J6 J5 J4 J3 J2 J1

  25. DCS常用销售工具链接 Scan Visor: DCS 方案选择工具 www.motorola.com/scanvisor 方案生成工具 https://solutionbuilder.motorola.com • Motorola解决方案集合(图集) • http://www.motorolasolutionscollective.com

  26. 123Scan2 扫描器配置工具

  27. 123Scan2扫描器配置工具 • 123Scan² 是一款免费、易用、基于XP & Win7 的软件工具，利用它可以快速方便地按照用户需求设置Motorola扫描器。

  28. 123Scan2硬件和软件需求 硬件需求: 赛扬 M 1.73GHz 或奔腾D 820 2.80GHz 或奔腾 M 750 1.8GHz 2GB 内存 80GB 硬盘 USB 接口1.1 或更高版本, 用来连接USB 扫描器 RS-232 接口用来连接串口扫描器 软件和操作系统需求: Microsoft Windows XP SP3 or Windows 7(32 & 64 bit) 安装123Scan²时已加载Microsoft .NET Framework 3.5 最小屏幕分辨率= 1024 X 768

  29. 123Scan2特征与优势 • 1. 便于使用 • 可针对已保有型号扫描器下载最新插件 • 支持新型号扫描器 –通过点击更新按钮 • 可维护一系列配置文件 • 在PC上保存配置文件 • 通过电子邮件分发配置文件 • 2. 生成用户定制方案 • 多种配置选项 • 打印配置条码 • 通过USB & RS232 将配置直接传输到扫描器 • 生成包含所有配置参数的报告 • 6. 跟踪企业部署 • 生成配置分发报告 • 参数报告 • 库存资产报告 (资产信息) • 配置分发活动报告 • 3. 一步手册生成 • 生成条码配置单 • 多个一维条码 / 单个二维条码 • 通过扫描条码完成扫描器的所有配置 • 格式转换- 可保存为Word的Doc格式，以便编辑和分发 • 5.可与常见的Office工具集成使用 • 123Scan2 可与office 工具协同工作 • 可以Word .doc格式保存打印输出 • 可以保存资产信息到MS Access • 可以保持客户服务历史的数据库记录 4. 方便的电子式配置分发 • 通过有源USB hub进行批处理式分发配置 • 支持USB & RS232 接口 • 升级固件和重置升级前配置 • 多个扫描器间克隆配置

  30. Scanner SDK Images and Video Remote Management Data Capture Custom Applications C++/Java/.NET Custom Applications Industry Standard Applications Industry Standard Interfaces APIs Motorola Scanner SDK OPOS JPOS Custom Interfaces APIs CoreScanner API (C++ & C#) Scanner/Driver WMI Provider Image & Video Module Remote Scanner Management Module Barcode Data Module Scanner Communication Interface USB: SNAPI USB: OPOS USB: HID KB RS-232: Nixdorf B

  31. Developer Tools Developer Tools • Sample Applications with Source Code • Scanner Sample Application (C++) - SDK for Windows v1.2 • Scanner Sample Application (C#.NET) - SDK for Windows v1.2 • WMI Management (C#.NET) - SDK for Windows v1.2 • OPOS (C++) - SDK for Windows v1.2 • JPOS (JAVA) - SDK for Windows v1.2

  32. Thank you! • & • Questions?
