  1. Cat Veins

  2. Superior vena cava Brachiocephalic Subclavian Axillary Brachial

  3. Transverse Jugular Internal thoracic (cut) Suprascapular Vertebral Subscapular Facial Maxillary

  4. INTE VEINS Superior Vena Cava Brachiocephalic Heart Internal Jugular External Jugular Subclavian Suprascapular Axillary Brachial

  5. Common Carotid Artery Brachial Vein Suprascapular Vein Axillary Vein Subclavian Vein Brachiocephalic Vein Internal thoracic Artery Vertebral Vein Internal thoracic Vein Superior Vena Cava

  6. Transverse Jugular Facial Maxillary

  7. External Jugular Vein Common Carotid Artery Facial Vein Transverse Jugular Vein Maxillary Vein

  8. Facial Vein Maxillary Vein External Jugular Vein Transverse Jugular Vein

  9. Subclavian Vein External Jugular Vein Internal thoracic Vein Internal Jugular Vein Brachiocephalic Vein Common CarotidArtery SuprascapularArtery Brachial Artery

  10. Internal thoracic v Superior Vena Cava Vertebral veins Inferior Vena Cava Brachiocephalic Azygos Vein

  11. External Jugular V. Suprascapular V. Common Carotid A. Brachiocephalic V. Brachiocephalic V, Internal thoracic Superior Vena Cava Aortic Arch

  12. R. Common Carotid A. L. Common Carotid A. Vertebral Artery Axillary Artery Aortic Arch

  13. Internal thoracic V. Internal Jugular Vein Vertebral Veins Superier Vena Cava Common Carotid Artery Subclavian A. Vertebral A. External Jugular Vein

  14. Right Common Carotid A. Suprascapular A. Axillary A. Brachial A.

  15. Internal thoracic V. Superior vena cava Brachiocephalic V. Transverse jugular V. Verterbral V. Facial V. Subclavian V. Suprascapular V. Maxillary V. Axillary V. External jugular V. Brachial V.

  16. Transverse jugular V. Common Carotid A. Brachiocephalic V. Facial V. External Jugular V. Subclavian V. Internal Mammary A. Axillary A

  17. Common Carotid A Transverse jugular V. Maxillary V. Brachiocephalic Subclavian V. External jugular V. Facial V. Suprascapular V. Brachial.

  18. Superior Vena Cava Suprascapular V. Internal thoracic Vein Subclavian V. Axillary A. and V. Brachial A. and V.

  19. Superior Vena Cava Brachiocephalic V. Subclavian V. Subscapular V. Axillary V. External Jugular V. Suprascapular V.

  20. Superior Vena Cava Brachiocephalic V. Subclavian V. Axillary V. External Jugular V. Brachial V. Suprascapular V. Subscapular V.

  21. Brachiocephalic A Axillary A. Common Carotid A Internal jugular v Aortic Arch L. Subclavian A. Axillary A.

  22. External Jugular V. Subclavian V. Facial V. Subscapular V. Axillary V. Brachial V.

  23. Internal Jugular Vein InternalMammary Vein Brachiocephalic Veins Superier Vena Cava Vertebral Veins Common Carotid Artery Subclavian Artery Vertebral Artery External Jugular Vein Subclavian Vein

  24. Axillary Artery Superior Vena Cava R. Common Carotid Artery Facial vein Internal thoracic Artery Maxillary Vein Subclavian Vein External Jugular Vein

  25. External Jugular V. Subclavian V. Facial V. Subscapular V. Axillary V. Brachial V.

  26. Brachio-cephalic A. Aorta L.Common Carotid A. L.Subclavian A. Vertebral A. Internal Mammary A. Cat Vessels Axillary A. Brachial A. and V.

  27. Superior vena cava Brachiocephalic veins Subclavian vein External jugular veins Subclavian vein Axillary vein Subscapular vein

  28. Liver Diaphragm Heart Superior vena cava Inferior vena cava

  29. Heart Azygous vein Posterior intercostal veins

  30. Gastric artery Splenic artery Hepatic artery Celiac trunk L gonadal v Suprarenal vein Lumbar artery Lumbar vein Renal vein

  31. Left gonadal vein Lumbar artery & vein Middle sacral vein Left renal vein Abdominal aorta Celiac trunk Inferior vena cava Right external iliac artery Right renal vein Superior mesenteric artery

  32. Celiac trunk Suprarenal vein Superior mesenteric artery Left renal vein Right renal vein Left gonadal vein Inferior vena cava Abdominal aorta Lumbar vein & artery Lumbar vein & artery Left external iliac artery Right external iliac artery Left internal iliac artery Right internal iliac artery External iliac vein

  33. Left gonadal vein Left internal illiac artery Renal vein Left external illiac artery Femoral vein Right internal illiac artery Lumbar vein Superior mesenteric Right external illiac artery

  34. Lumbar Artery & Vein Inferior Mesenteric A. Internal Iliac A. Gonadal A. External Iliac A. Femoral Artery & Vein

  35. Right external illiac artery Right internal illiac artery Inferior mesenteric Femoral vein Lumbar artery Lumbar vein Femoral artery Deep femoral artery

  36. Right femoral vein & artery Inferior vena cava Lumbar vein Median sacral artery Left internal iliac artery Lumbar vein and artery Left external iliac artery Left femoral vein & artery

  37. Ovary Gonadal Fallopian tube is called uterine horn in cat. They have no uterus Suprarenal Renal Inferior vena cava Abdominal aorta Lumbar

  38. Lumbar Vein Abdominal Aorta External Iliac Vein Internal Iliac Artery Median Sacral Artery Middle Sacral Vein Femoral Artery Femoral Vein

  39. KIDNEY L. GONADAL POPLITEAL RENAL FEMORAL INTERNAL ILIAC ARTERY L. COMMON ILIAC VEIN LUMBAR DEEP FEMORAL GONADAL MEDIAL SACRAL GREAT SAPHENOUS VEINS

  40. ILIOLUMBAR V. & A. EXTERNAL ILIAC A. & V. FEMORAL V. & A. DEEP FEMORAL V. & A. INFERIOR VENA CAVA GREAT SAPHENOUS V.

  41. Femoral A. and Vein Great Saphenous Vein Deep Femoral A. And V. Popliteal A. And Vein
