  1. NUUO Tribrid Video Recording Solution

  2. NUUO advanced video recording and management total solution …is the combination of Mainconsole & CMS servers system. CMSis responsible for backend high capacity video and information management at the central site. It could manage unlimitedMainconsolesand extend to each camera. CMS Mainconsole is responsible for video recording and data collection service supporting all types of camera including IP , analog , SDI interface. Mainconsole SD-CCTV Camera HD-CCTV Camera IP Camera

  3. NUUO all-inclusive Tribridvideo surveillance solution Mainconsole PC based DVR software + + IP+ channel license Video compression card IP Camera 61 Brands, over 1,300 models well-known IP camera supported SD / HD-CCTV Camera Universal NTSC / PAL standard & high definition camera supported. Tribrid DVR Merging IP , composite analog , SDI interface video source into one mainconsole server to support NVR/DVR/NDVR/Hybrid/Tribrid DVR various customer’s requirements.

  4. NUUO multi-profile transcoding & recording solution …is NOT only a video recording server but stream transcoding & relaying server. Multi-camera with one stream inputs (Up to 64 CH) Multi-stream outputs (Up to 128CH) Mainconsole Transcoding & relaying service Remote Live Viewer IP Camera Multi-profile streaming SD-CCTV Camera Multi-profile recording HD-CCTV Camera Local storage

  5. NUUO client/server based system architecture Mainconsole and CMS systems all are designed based on client/server architecture. It separates data store and query into server/client sides to balance the system loading appropriately and make sure the information security. Mainconsole provides overall video record/playback , alarm management and system configuration service. Remote live viewergives multi-channel real time display/playback and alarm notification service to remote site users. CMSthe central management server collects all the alarm messages and system information from unlimited Mainconsoles and delivers to NCS client application noticing operators. NCS client provides video matrix wall, E-map , alarm notification and video playback service for different site operators. Remote live viewer IP / Analog / SDI Camera Client Server Mainconsole Mainconsole Server SQL Database CMS Alarm Server(Unlimited) Client NCS Client(Unlimited)

  6. Here comes the …Tribrid

  7. What’s Tribrid Solution Coaxial cable HD-CCTV (SDI) Tribrid Coaxial cable SD-CCTV(Composite analog) Hybrid Mixed installation by NUUO 6000S/7000S/8004HD hardware compression with Mainconsole Ethernet cable IP With Tribrid solution, users can deploy their cameras freely depending on the field site demand. Most of area they can use SD cameras and part of important entrance use HD cameras. For the remote site they also can use IP cameras.

  8. How to make it “Tribrid” Step 1 :Running Mainconsole with SCB-8000 series cardfor the HD-CCTV video source input. Step 2 :Mixed installation of SCB-7000S/6000S series card for the composite analog video source input depends on the Max. recording resolution & frame rate you need. Step 3 :Plus IP+ channel license for the 1,100 models well-known brand IP camera input.

  9. What we gain by HD-CCTV • H.264 full HD real time encode • Good efficiency of resolution over bitrate • Near zero latency • Up to 4 channel with 1080p@30fps • Support NTSC , PAL universal standard • Compatible to HD-SDI standard cameras → : : D1(720x480) HD(1920x1080)

  10. Excellent use by HD-CCTV • High definition and real time for gaming table , transaction counter etc… • 1080p/720p @ 30fps Get closed look of transaction Verify the face of card and money • 1080p/720p @ 30fps

  11. WhyHD-CCTV , CCTV , IP

  12. How to deploy the Tribrid solution All-IP Hybrid Tribrid Control Center CMS CMS CMS Mainconsole Mainconsole Mainconsole Transmission WAN / LAN WAN / LAN WAN / LAN Sub-Center Sub-Center HD CCTV Matrix SD CCTV Matrix Camera /Sensor Mainconsole IP Cameras IP Cameras Mainconsole IP Cameras SD Cameras HD Cameras SD Cameras Centralization Real time recording

  13. Coaxial cable recommendation

  14. All-inclusive benefits by Tribrid

  15. NUUO flexibility for you

  16. Mainconsole Tribrid Video Recording Server

  17. Mainconsole4 main purposes • Live view • Data collection • Event / Notification • Recording / Playback

  18. Mainconsole Live view • Insert camera easily and quickly • Auto-listing the compression card input channel in sequence. • Auto-searching and recognize the IP camera under supported models. • Manual place camera label on the E-Map or floor plan. • Multiple stream profile setting for different purposes • Multi-profile of resolution & frame rate can be set for recording , local display , remote live viewing demand by channels. • No need to double connect to the IP camera for different profile , saves bandwidth and ensures stability. Camera searching tool E-Map placement Stream profile management Video quality setting & preview

  19. Mainconsole Live view • Matrix view display for SMB control center • 1,4,6,9 ~ 64 divided screen viewing freely by user. • Triple monitor display in one server. • Support remote live viewer , http web client and smart phone access. • Stream relaying & transcoding to be a powerful media hub • With stream relay service Mainconsole can duplicate image by one stream input. • Monitor 1 camera by 2 viewing zone separately. Stream Duplicate Screen 2 Screen 1 Transcode quality Screen 1 Remote live viewing Screen 2 Local recording

  20. Mainconsole Live view • Remote live viewer • Multiple sites access and up to 128 live channels. • Channel grouping feature. • Multi-profile selection on the screen. Stream profile selection Remote live viewer Grouping x128 CH Mainconsole ………………. x64 CH x64 CH

  21. Mainconsole Data collection • Valuable data marked over video for management benefits • NUUO Metadata Applications integrate the 3th party’s POS register , access control and LPR devices with Mainconsole to collect transaction , attendance and license plate number record on the real time image . • NUUO Metadata Solution provides C31A , C08 converter box for the external devices connectivity. Filtered Metadata RS232 TCP/IP 3rd party Plug-in method Event Access Control Live Video Mainconsole LPR Video Request • Provide AP or DLL • for 3rd party method Recorded Video POS

  22. Mainconsole Data collection • 3rd party integration – Manage video and transaction in one platform • Access control • LPR • POS (TCP based must be fully integrated) • IBM SurePOS 500

  23. Mainconsole Data collection • Valuable data marked over video for management benefits • Mainconsole embed people counting feature to record the enter and exit statistic on the screen. • Support 2 ways detection zones with sensitivity parameter setting. Drawing detection zones and people counting simulation Live view with people counting statistic

  24. Mainconsole Event / notification • NUUO Smart Guard reduces human mistake • With 6 types of event trigger and 10 kinds of notification method Mainconsole provides perfect early warning safeguard . Channels x Events x Notifications

  25. Mainconsole Event / notification • Smart Guard – General Motion Detection • Support 5 general motion by Mainconsole and 1 edge motion from IP cameras. • Support multiple regions merging and subtracting drawing on the detection zones in plan against the rest areas’ interference. • Support 5 detection zones in separate sensitivity for the false alarm reduction. High sensitivity Low sensitivity Avoid the false alarm caused by LCD monitor

  26. Mainconsole Event / notification • Smart Guard – Missing & Foreign Object Detection • Object event trigger snapshot and DO alarm. Digital output Light / sound alarm Snapshot image FTP server

  27. Mainconsole Event / notification • Smart Guard – Camera Error Detection • Camera occlusion and lose focus event trigger E-Map popup alarm Camera occlusion channel showed on the E-Map popup

  28. Mainconsole Event / notification • Smart Guard – System Health Detection • Beside the video event Mainconsole extra provides system self-checking engine for custom resource and network monitoring. System resource checking System health checking Network checking

  29. Mainconsole Recording / playback • Complete recording mode selection • Support Always , Event , Motion , boosting recording. • Support custom encoded video quality considering both quality and resource benefits. • Benefit of boosting record: • Regular recording in normal frame rate. • Event recording in higher frame rate. • Managing high volume of video data efficiently for storage saving. Video quality adjustment comparison Boosting recording: 30 fps when the event trigger Recording mode setting Recording quality setting Normal: 1 fps

  30. Mainconsole Recording / playback • GUI recording schedule setting , easy , quick and clear • Support weekly , daily schedule and 6 kinds of scenario recording setting. • Support GUI time slot dragging setting. • Support setting parameter quickly copy to independent or all cameras. Recording modes applying Time Boost Motion Always Event Day Camera list Copy to all Recording mode Preview

  31. Mainconsole Recording / playback • Auto load balance and backup to enhance efficiency and data safety • Auto load balance feature supports multiple hard drives and enhance the data writing efficiency. • Schedule backup in daily or weekly mode • Backup to any kinds of network drives, including NAS, SAN, iSCSI, DAS • Backup video and audio • Backup with playback Auto Load Balance ……… HDD1 : 80Mbps HDD3 : 50Mbps HDD2 : 50Mbps Network Drive Backup video and audio Mainconsole

  32. Mainconsole Recording / playback • GUI playback selection , easy , quick and clear • Support calendar by year , month , week , day selection. • Support GUI time slot dragging selection. Day selection Multiple channels playback Multiple cameras time slot selection Playback zoom + - Playback speed + -

  33. Mainconsole Recording / playback • Instant playback , the least time to watch • Support right click extender on the screen to open the latest 1 , 3 , 5 minutes playback right away without open playback interface. Detect motion event and display the message on screen Click instant playback to check the event content by a shortcut video clip right away

  34. Mainconsole Recording / playback • Smart search by event • Like Smart Guard video analysis , Smart Search can find out the event when real time playback the video. Playback video

  35. Mainconsole Recording / playback • Enhance browse • Once the recorded video’s visibility is not good enough , enhance browse feature can adjust the playback image following below filter : High brightness Low brightness

  36. Mainconsole Benefits of management • Windows Active Directory supported • Improve centralized management capabilities. • Synchronize users and update data from exist AD server of client side. • User permission and privilege management • Permission manages device access authority. • Privilege manages system function operation authority. Users and groups ADServer Mainconsole

  37. Mainconsole Benefits of management • Personal privacy protection • Mask particular areas by black block from fixed view. • Both live view & recorded video can be protected. (Bank ATM) Mask password insert (Access control) Mask the password insert (Parking lot) Mask the license plate

  38. Mainconsole System block and features summary H.264 LPR Mega-Pixels POS Panomorph PTZ Access Control Stream profile Transcoding Remote Live Viewer Boosting Record Http client Auto Load Balance PTZ Smart Guard Smart Search E-Map CMS Privacy Mask Windows AD Auto backup Smartphone

  39. NUUO CMS Central Management System

  40. NUUO CMS4 main purposes • Centralized management • Intuitive E-Map • Alarm management • Matrix – video wall

  41. NUUO CMS Centralized management • Enterprise-Scale Surveillance System • Authentic client-server architecture • Manage unlimited NUUO Tribrid and NVRmini recording servers with numerous cameras , I/O devices , LPR and POS information • Support unlimited matrix consoles • Advanced GUI alarm management • Remote desktop control all remote recording servers • Support OS : Windows 7 32/64bit , Window Server 2008 64bits

  42. NUUO CMS Centralized management • Client-server work flow • NUUO recording servers push events to CMS server • CMS server notify events to assigned NCS clients • NCS client query alarm from device on map by hour , day , custom period • NCS client request live or recorded video from NUUO recording servers Multiple recording servers CMSServer Multiple NCS Clients

  43. NUUO CMS Centralized management • Authentic structure • Remote desktop viewer support complete configuration of NUUO recording serves • Auto reconnection & login feature ensure whole system communication recovery after network unexpected disconnection CMS Server SQL Server Auto reconnect NCS Client NCS Matrix Mainconsole

  44. NUUO CMS Intuitive E-Map • Intuitive operation • Supports unlimited layers of E-Map • Real-time indication of devices’ status • Instant alarm notification of status , data mining and report • Camera coverage display Camera coverage and device status indication. Instant remote playback Multiple layers E-Map navigation of camera location. Real-time alarm notification beside the E-map with snapshot photos. Unlimited devices tree management beside the E-Map.

  45. NUUO CMS Alarm management • High capacity and instant response • Alarm note and guide to indicate necessary actions • Detailed alarm overview • 45 types , 6 video analytic events alarm priorities management • Alarm popup on NCS client and matrix • Backup alarm recording on NCS clients Alarm Popup Alarm Detail Alarm Processing

  46. NUUO CMS Alarm management • Powerful alarm search and report • Custom filter to search interested alarm records by device , event , priority etc… • Through alarm management to process event and print detailed report directly. Multiple sources and event types selection Priority and schedule search. Detailed alarm report Multiple custom searching filter

  47. NUUO CMS Matrix – video wall • Flexible video matrix • Flexible display layout , stream profile and auto scan • Supports unlimited display matrices for remote live view with PTZ and joystick control • Matrix can popup alarmed cameras instantly upon an unusual event on any matrix monitor specified Multiple monitors video wall NCS matrix client layout setting

  48. NUUO CMS Matrix – video wall • Live view and 2-way audio • Optimized 16:9 layouts to support wide screen • 2-way interactive audio communication • Matrix Profile View • Group camera in a view profile • Automated alarm handling with different alarm flag • User login with different view profile Audio Stream Mainconsole Remote live viewer NCS client Door/Gate Office

  49. NUUO CMS Benefits of management • Graphic user interface and E-Map • Intuitive operation , easy and clear • Alarm popup notification , quick and safe • Flexible video matrix • Unlimited NCS client to expand video walls for different purposes , save cost • Multiple clients in one System • Unlimited NCS client cover local and remote surveillance need • Enhance the security operation efficiency • Effectivealarm management • Quick overview of critical alarms • Advanced search filter , save time and precise • Windows Active Directory supported • Improve centralized management capabilities • Synchronize users and update data from exist AD server of client side

  50. System Comparison
