Secure In-VM Monitoring Using Hardware Virtualization

1. Author: Monirul Sharif, Wenke Lee, Weidong Cui, Andrea Lanzi Reportor: Chun-Chih Wu Advisor: Hsing-Kuo Pao Select: CCS09’ Secure In-VM Monitoring Using Hardware Virtualization

2. Outline • Introduction • Secure In-VM Monitoring • Implementation • Experimental Evaluation • Conclusion

3. Introduction • Malicious programs compromise the kernel of an operating system. • Many security approaches require the ability to monitor frequently executing events. • Secure In-VM Monitoring (SIM), a general-purpose framework based on hardware virtualization features.

4. contributions: • hardware virtualization and memory protection features. • implemented a prototype of the SIM framework based on KVM and Windows guest OS. • systematic security analysis of SIM against a number of possible threats, and show that SIM provides no less security guarantees than what can be achieved by out-of-VM monitors.

5. In-VM monitoring A Adversary program DP Program data CP Program code K Hook DK Hook data H Handler CM Monitor code DM Monitor data R Response

6. Out-of-VM monitoring A Adversary program DP Program data CP Program code K Hook DK Hook data H Handler CM Monitor code DM Monitor data R Response

7. performance requirements (P1) Fast invocation: • not involve any privilege level changes. (P2) Data read/write at native speed: • without any hypervisorintervention

8. security requirements: • (S1) Isolation of the monitor’s code (CM) and data (DM) • (S2) Designated point for switching into CM • (S3) A handler (hi) is called if and only if the corresponding hook (ki) executes • (S4) The behavior of Monitor is not maliciously alterable

9. Secure In-VM Monitoring

10. The SIM address space SIM Data/Code • The monitor itself • Visible only within SIM address space Invocation checker • Verifies call chain is legit • Visible only in SIM space Entry/exit gates • Visible in both • Writable only in SIM space • Tiny, well crafted Kernel code/data • Not executable in SIM space(can't accidentally run insecure code)

11. Entry/exit gates • Entry: • Disable interrupts (Untrusted VM) • Save CPU state to the stack • Switch address space • Re-disable interrupts (SIM VM) • Switch stack to a SIM-restricted one • Run invocation checker • Exit: • Restore stack, page table, CPU state • Re-enable interrupts • Jump to return point

12. security requirements • Isolation of the monitor’s code and data • hypervisor to not allow the monitor code and data to be mappable to any untrusted address space in the guest VM. • Designated point for switching into CM : • only method to enter the trusted address space from the untrusted one is via the entry gates. • A handler is called if and only if the corresponding hook executes • each hook invokes a corresponding entry gate, which eventually calls a corresponding handler, and each invoker of the entry gate is checked by the invocation checking routine • The behavior of Monitor is not maliciously alterable: • not allow any code from the untrusted domain to be executable in the trusted address space, not allow the monitor to call into the untrusted kernel

13. Implementation • Host: Linux distribution • guest OS : Windows XP SP2 • Initialization • reserve virtual address ranges in the system address space for use in entry and exit gate creation • creation of the SIM virtual address space by the hypervisor component • loading a security monitor application into the SIM address space • relevant routines to perform switching into the SIM address space

14. Experimental Evaluation

15. System call tracing macrobenchmarks

16. Conclusion • a general-purpose SIM framework • provides the same security guarantees of out-of-VM monitoring low performance overhead of in-VM monitoring. • the SIM framework reduce monitoring overhead by 11 times if only monitor invocation time is considered. • SIM introduces an overhead of to 13.7% • out-of-VM approach compared 690.5%. • SIM overall overhead below 10% • out-of-VM approach overhead : 128%.

17. Thank You
