low temperature primary thermometry development at nrc

Low-temperature primary thermometry development at NRC

Dr. Patrick M.C. Rourke

Measurement Science and Standards (MSS)

National Research Council Canada (NRC)

CAP Congress, Sudbury, 19 June 2014

thermometry
Thermometry
  • Primary thermometer
    • Directly measure “real” thermodynamic temperature T
    • Complicated, large, difficult to use  not many in existence
  • Secondary thermometer
    • Needs calibration in order to set scale
    • Almost all thermometers are secondary
  • International Temperature Scale of 1990 (ITS-90)
    • Used for secondary thermometer calibrations worldwide between 0.65 K and 1357.77 K
    • Based on best thermodynamic data from primary thermometers available up to 1990
    • Newer measurements suggest the scale should be improved
its 90 scale deviates from thermodynamic temperature
ITS-90 scale deviates from thermodynamic temperature

Adapted from CCT-WG4 report (2008), Fischer et al., Int. J. Thermophys. 32, 12 (2011),

Astrovet al., Metrologia 32, 393 (1995/96) and Gaiseret al., Int. J. Thermophys. 31, 1428 (2010)

refractive index gas thermometry rigt in principal
Refractive index gas thermometry (RIGT) in principal
  • Microwave resonances in a gas-filled conducting cavity
    • Fixed temperature & gas pressure
  • Resonance frequency f gas refractive index n
    • c0: speed of light in vacuum
    • ξ: electromagnetic eigenvalue for microwave resonance
    • a: radius of spherical cavity
    • Thermal expansion coefficient αL and isothermal compressibility κT important
  • Calculate thermodynamic temperature T from n using virial equations
    • Helium gas: quantum mechanics
  • Similarities to other techniques
    • Acoustic gas thermometry (AGT)
    • Dielectric constant gas thermometry (DCGT)
    • Resolve differences between them?
rigt in practice
RIGT in practice
  • Quasi-spherical resonator
    • Controllably lift resonance degeneracy
  • Finite electrical conductivity
    • microwaves penetrate into skin layer
    •  resonances broadened & shifted
  • Eigenvalue corrections
    • Shape effects
    • Disturbances due to waveguides
experimental details
Experimental details
  • Motivation: RIGT to measure T - T90: 5 K – 300 K
    • Initially, characterize resonator in vacuum
    • Microwave resonances  resonator size, shape, conductivity
  • Prototype copper resonator
  • Copper pressure vessel
    • Resistive thermometers (ITS-90) on copper coupling rod
  • Two-stage pulse-tube cryocooler
    • Home-made thermal control system
microwave fitting
Microwave fitting
  • Measure microwave resonances using 2-port Portable Network Analyzer
  • Complex 3-Lozentzian + polynomial background fitting routine
    • Peak frequencies and half-widths
  • Several microwave modes measured
    • Optimized spectral fitting background terms, 1st- & 2nd-order shape corrections, and waveguide corrections
    • Room temperature results agree with those done at NIST May et al., Rev. Sci. Instrum. 75, 3307 (2004)
electrical conductivity
Electrical conductivity
  • Temperature dependence of resonator conductivity (from peak width)
    • Stable, fixed temperatures over entire temperature range
    • Agrees with literature within literature curve’s 15% uncertainty Simon et al., NIST Monograph 177, 1992
    • Free parameter σ(T = 0) ≡ 1/ρ0 set to present experimental data at 5 K
thermal expansion coefficient l
Thermal expansion coefficient αL
  • Experimental data from 3 microwave modes
    • Good consistency
  • Literature curve – no free parameters!
    • Simon et al., NIST Monograph 177, 1992
    • NIST Cryogenic Materials Properties Database (2010 revision)
  • Excellent agreement with literature values over entire temperature range
thermal expansion coefficient l1
Thermal expansion coefficient αL
  • Present data is within 1st. dev. of literature curve at all temperatures measured
conclusions future directions
Conclusions & future directions

Conclusions

  • International Temperature Scale of 1990 deviates from thermodynamic temperature
    • More measurements needed to resolve issues before replacement scale created
    • NRC developing microwave RIGT for Canadian thermodynamic temperature measurement capability
  • Microwave resonances measured in quasi-spherical copper resonator
    • Vacuum, 5 K – 300 K
  • Comparison to literature properties of copper measured with other methods
    • Excellent agreement over wide temperature range
    • Increased confidence in our microwave implementation

Next steps

  • Measure triaxial ellipsoid resonator
    •  Better shape, reduced background effects
  • Gas in resonator
    •  Refractive Index Gas Thermometry
we re looking for a few good physicists do you have what it takes
We’re looking for a few good physicists: do you have what it takes?

THE PROJECT

  • Electrical resistivity and Seebeck voltage of platinum-group metals (and other metals and alloys) – considerable interest to thermometry
    • Solid-state theoryand experimental measurements to understand the temperature dependencies of these properties
    • Electronic band structure, electron-phonon scattering, electron-electron (s-d) scattering, oxidation, recrystallization, and scattering from vacancies and dislocations
  • Suitability of various phase transformations as reference temperatures
    • Typically liquid/solid and solid/liquid transformations of pure elements or eutectics
    • Various metal-carbon eutectics and peritectics are of current interest at high temperatures

KEY SPECIFICATIONS

  • Ph.D. in Physics (experimental solid state / condensed matter physics preferred)
  • Ability to design, construct, and operate experimental equipment with a minimum of technical assistance
  • Innovative “hands on” approachtowards the solution and attainment of high accuracy in a variety of measurement problems
  • Attention to detailcommensurate with the operation of a primary standards facility
  • Ability to work effectively within a small group devoted to the research, development, and dissemination of temperature standards

Get in touch for more information: patrick.rourke@nrc-cnrc.gc.ca

slide13

Thank you

Dr. Patrick Rourke

Measurement Science and Standards

patrick.rourke@nrc-cnrc.gc.ca

www.nrc-cnrc.gc.ca
