  1. Composing Features by Managing Inconsistent Requirements Robin Laney, Thein Than Tun, Michael Jackson and Bashar Nuseibeh (Department of Computing, Open University) {r.c.laney, t.t.tun, m.jackson, b.nuseibeh}@open.ac.uk ICFI 2007, Grenoble, France.

  2. Outline • Motivation (3min) • Overview (5min) • Specifying Features (5min) • Composing Features (5min) • Resolving Inconsistency (5min) • Concluding Remarks (2)

  3. Motivation

  4. Context • Approaches to system development involve • decomposing requirements into features • solving sub-problems of individual features • recomposing the solutions • What if feature solutions are inconsistent? • Static resolution can be over-restrictive

  5. Smart Home • Feature-rich • Developed by disparate developers • Feature interactions in the environment • Dynamic conflict resolution approach is needed

  6. Window sash Window frame An Illustrative Example • Control of a motorized awning window in smart home applications • Consider two requirements: • “Keep the awning window shut at night.” • “If it is hot indoors (i.e. hotter than the required temperature) and cold outside (i.e. colder than the temperature indoors), open the awning window.” • Resolving them statically is not very smart!

  7. Overview

  8. Ingredients of Proposed Solution • Problem Frames approach (PF) to organize descriptions of features • Event Calculus (EC) to formalize requirement and domain properties, and systematically derive specifications • Composition Frames to recompose feature solutions and resolve conflicts • Introduce the Prohibit predicate into EC which assists in dynamic composition

  9. Problem Diagram: Security Feature • Three Descriptions • Requirement (R) • Problem World Domains (W) • Specification (S) • Argument for adequacy of the solution • W,S|─R

  10. Event Calculus • Predicate logic system • An event denotes an action that happens at a time • Happens(e1, t1) -- the event e1 happens at time point t1 • A fluent denotes a state of the system • HoldsAt(f1, t1) -- the fluent f1 holds at time point t1 • Some Standard Predicates • Initiates(e1, f1, t1) -- the fluent f1 starts to hold after the event e1 at t1 • Terminates(e1, f1, t1) -- the fluent f1 ceases to hold after the event e1 at t1 • …

  11. “Keep the awning window shut at night.” HoldsAt(IsIn(t,NBegin,NEnd), t) →HoldsAt(WindowShut, t) Formalization of Requirement

  12. If the window is tilted out, it starts tilting out (D1) until the window is fully open (D2) or the window is tilted in (D7). … Initiates(tiltOut, TiltingOut, t) (D1) Trajectory(TiltingOut, t, WindowOpen, suffopentime) (D2) Terminates(tiltIn, TiltingOut, t) (D7) Formalization of Domain Description

  13. Specifying Features

  14. Deriving Specifications Requirements Abductive Refinement Specification HoldsAt(…) Domain Descriptions Happens(…), Prohibits(…) EC Meta-rules Prohibit Predicate Initiates(…), Terminates(…), Trajectory(…)

  15. HoldsAt(β, τ) ← Initially(β) ^ ¬Clipped(0, β, τ) β … 0 τ Deriving Security Feature specification • (State the requirement) HoldsAt(IsIn(t,NBegin,NEnd), t) →HoldsAt(WindowShut, t) • (Refine the conclusion by applying EC1) Initially(WindowShut) ^ ¬Clipped(0,WindowShut, t)

  16. Clipped(τ1, β, τ2) ↔ ∃α, τ [ Happens(α, τ) ^ τ1 < τ < τ2^ Terminates(α, β, τ)] Terminates(α, β, τ) β Terminates(tiltOut, WindowShut, t) (D6) … 0 τ Derivation (cont…) • (Apply DEF1 to the second sub-clause) Initially(WindowShut) ^ ¬∃a1, t1 • Happens(a1, t1) ^ Terminates(a1, WindowShut, t1) ^ 0 < t1 < t • (Unify the Terminate sub-clause with D6) Initially(WindowShut) ^ ¬∃t1 • Happens(tiltOut, t1)^ Terminates(tiltOut, WindowShut, t1) ^ 0 < t1 < t

  17. Prohibit(α, τ1, τ2) ≡ ¬∃α,τ • Happens(α, τ) ^ τ1 < τ < τ2 Prohibit(α, 0, τ) β … 0 τ Derivation (cont…) • (Terminate sub-clause is an axiom) Initially(WindowShut) ^ ¬∃t1 • Happens(tiltOut, t1) ^ 0 < t1 < t • (Introduce the Prohibit predicate for partial spec) HoldsAt(IsIn(t,NBegin,NEnd), t) → Initially(WindowShut) ^ Prohibit(tiltOut, 0, t)

  18. ComposingFeatures

  19. Composing Features • Four weakened conjunction operators • Option 1: SR^{any} TR – No control • Option 2: SR^{control} TR – Exclusion • Option 3: SR^{SR} TR – Exclusion with priority • Option 4: SR^{important,SR} TR – Exclusion with fine grain priority

  20. Composition Frame a:TiP! {NBegin, NEnd} a’:CC! {NBegin, NEnd} e:TeP! {NiceTemp} e’:CC! {NiceTemp} f:OTS! {OutTemp} f’:CC! {OutTemp} g:ITS! {InTemp} g’:CC! {InTemp} b:CC! {tiltIn, tiltOut} b’:SF! {tiltIn, tiltOut, Prohibit(...)} b”:CCF! {tiltIn, tiltOut, Prohibit(...)} c:W! {WindowShut, WindowOpen}

  21. Composition Frame merge

  22. Specifying Composition Controller • SR ^{any} TR – any emergent behaviour is OK • a:e → a’:e (1) • e:e → e’:e (2) • f:e → f’:e (3) • g:e → g’:e (4) • b’:e → b:e (5) • b”:e → b:e (6)

  23. Prohibit From To By P tiltOut 20:00 07:00 SF … … … … Specifying Composition Controller • SR ^{control} TR – give SR and TR exclusive control • b’:prohibit (e, t1, t2) → insert((e, t1, t2, ‘SF’), P) (5.a) • b’:e [∀t1, t2, m • t1 ≤ t ≤ t2 ^ m≠‘SF’ ^ (e, t1, t2, m) ∉ P] → b:e (5.b) • b’:e [∃t1, t2, m • t1 ≤ t ≤ t2 ^ m≠‘SF’ ^ (e, t1, t2, m) ∈ P ] → ignore (5.c) • b’:e [∀t1, t2, m • t1 ≤ t ≤ t2 ^ m=‘SF’ ^ (e, t1, t2, m) ∈ P] → error (5.d)

  24. ConcludingRemarks

  25. Concluding Remarks • Feature interactions caused by inconsistent requirements • Interactions manifest in the environment • Problem Frames and Event Calculus as complementary techniques • Feature specifications are derived systematically, highlighting possible interactions in Prohibit predicate • Features can be developed independently • Inconsistency resolved at runtime

  26. Questions?

  27. References

  28. Selected References • D. Bjørner. Towards posit & prove calculi for requirements engineering and software design, volume 2635 of LNCS, pages 58–82. Springer, 2004. • M. Jackson. Problem Frames. ACM Press & Addison Wesley, 2001. • P. Zave. Feature interactions and formal specifications in telecommunications. IEEE Computer, 26(8):20–30, 1993. • R. Laney, L. Barroca, M. Jackson, and B. Nuseibeh. Composing requirements using problem frames. In RE’04, pages 122–131. IEEE Computer Society, 2004.

  29. Department of ComputingThe Open UniversityWalton HallMilton KeynesMK7 6AAUK http://mcs.open.ac.uk/pass-external/
