Presentation Transcript
slide1

BRIGHT NEW WORLD

NORBERT KROO

HUNGARIAN ACADEMY OF SCIENCES

DUBNA, 25.09.2008

the lycurgus cup glass british museum 4 th century a d
The Lycurgus Cup (glass; British Museum; 4thCentury A. D.)

When illuminated from outside, it appears green. However, when

illuminated from within the cup, it glows red. Red color is due to very small amounts of gold powder (about 40 parts per million)

Surface plasmon oscillations

Mesoscopic:~1011 electrons

slide3

SURFACE PLASMON POLARITONS are a

„NEW TYPE OF LIGHT”, they are

1.BOUND TO THE (METAL) SURFACE,

2.HAVESPECIFIC DISPERSION PROPERTIES,

3.THE DIFFRACTION LIMIT DOES NOT APPLY,

4. MAY BE GUIDED,

5.REPRESENT VERY HIGH ELECTRIC FIELDS,

6.MAY BE LOCALIZED (e.g. to nanospheres or nanoshells)

7.MAY HAVE A BANDGAP,

8.MAY BE THE SUBJECT OF NONLINEAR PROCESSES

9. SHOW NON-CLASSICAL PROPERTIES

A POTENTIAL BASIS OF FUTURE NANOOPTICS

slide4

1

ELECTRIC FIELD OF SURFACE PLASMONS

From Maxwell’s equations

slide5

2

Excitation of SPO-s !!!?

slide6

LASER PULSE EXCITED SURFACE PLASMON NEAR FIELD STM

3

SPO



thermal

TYPICAL RESPONSE SIGNALS AND THEIR PART USED FOR IMAGING

slide7

Ag SURFACE, W tip

200x200nm

Topographic, SPO and thermal images

23870

slide8

4

SURFACE PLASMON LIGHT GUIDE

38590+92

4000x4000nm

Gold images

Cut from

5000x5000nm images

slide9

5

GIANT ELECTRIC FIELDS!

slide10

6

100x100nm

Gold

Topography and

SPO near field

STM images

34300+02 Au

Cut from 200x200nm

images

what is the origin of the color of the lycurgus cup answer surfac e plasmons
WHAT IS THE ORIGIN OF THE COLOR OF THE LYCURGUS CUP? ANSWER: ``SURFACE PLASMONS’’
  • An SPO is a natural oscillation of the electron gas inside a goldnanosphere.
  • SPO frequency depends on the dielectricfunction of the gold, and the shape of the nanoparticle.
  • For a sphere the plasma frequency is about 0.58 times the bulk plasma frequency (being in the UV; the SPO frequency is in the visible) (~520nm)

Ionic background

(not to scale)

electron sphere

Electron cloud oscillates with frequency of the SPO-s; ions provide restoring force.

slide13

7

SURFACE PLASMON ENERGY, OR MOMENTUM „GAPS”

Donor (chromophore), Acceptor (fluorophore)

slide14

8

1.ARRANGEMENT FOR ANGULAR, LASER POWER AND TIME DEPENDENCE MEASUREMENTS (A)

808nm SEMICONDUCTOR LASER

B:Similar arrangement, but simpler electronics for angular and spectral property studies of pulsed (790nm, 120fs) laser excited SPO emitted light

slide18

9

Ag SURFACE, W tip

200x200nm

23870
