ActiveX Xploitation In 2009

1. ActiveX Xploitation In 2009

2. Who The Hell Am I ? • Hi, My Name Is Paul Craig. • Principal Security Consultant . Security-Assessment.com • “I hack things.” • Google Me (I have hacked lots of things)

3. Agenda • What Is ActiveX & How Does it Work • ActiveX Vulnerabilities • Finding ActiveX Vulnerabilities • Why Everything Is Different With IE 8 • Shell Poppin’

4. What Is ActiveX? • ActiveX Is part of COM • Component Object Model • Includes: OLE, OLE Automation, ActiveX, COM+, DCOM • COM is a language neutral method of implementing objects. • Objects can be easily reused by other applications. • 1996 Microsoft renamed Internet OLE controls to ‘ActiveX’. • ActiveX was designed as the internet component of COM. • Widely used throughout the Windows environment. • Become the most popular component of COM.

5. COM objects are referenced by a ClassIDor ProgID • “CLSID is a 128 bit unique-id for a software application” Eg: CLSID = {AE7AB96B-FF5E-4dce-801E-14DF2C4CD681} • Programmatic Identifier is a human readable name: • WMP11.AssocFile • Control’s must be registered before use (Regsvr32.exe control.dll). • ActiveX controls can be loaded by IE • <object classid="clsid:22D6F312-B0F6-11D0-94AB-0080C74C7E95"> • IE uses the CoCreateInstance() method of COM. • Creates a single uninitialized object of the class associated with a specified CLSID.

6. Interfaces and Methods • COM is based on Object Oriented Programming • COM Objects expose interfaces. • Interfaces expose methods. • Methods = Functions of procedural programming. • Object.Interface.Method() MSNETOBJ.IRMGetLicense.GetLicenseFromURL(‘http://www...’)

7. COM Objects Are Not Typical DLL Libraries • Standard DLL ‘Exported Functions’ Not Present in COM. • Available Methods are exposed through DllRegisterServer • Abstracted from native operations.

8. All CLSIDs on Windows can be found at • HKEY_CLASSES_ROOT\CLSID • Which is an alias to HKEY_LOCAL_MACHINE\Software\Classes\CLSID • ActiveX Controls Have Opt-In Security Categories For IE. • Safe For Initialisation. • Safe For Scripting. • Category Membership Found At: • HKEY_CLASSES_ROOT\CLSID\{CLSID}\Implemented Categories • 7DD95801-9882-11CF-9FA9-00AA06C42C4 = SFI • 7DD95802-9882-11CF-9FA9-00AA06C42C4 = SFS • Not supported under Windows CE.

9. ActiveX Security Measures • Safe For Initialization • Allows a control to be initialised with persistent data. • Persistent data is supplied when the control is initialised. • Input supplied using an IPersist interface. • <object ...><param name=play value=test.wmv></object> • Safe For Scripting • Allows a control to be initialised and scripted with dynamic data. • Scripted using JavaScript/VBScript • Control can be accessed, methods called freely at run time. • Input supplied using an IDispatch interface.

10. IObjectSaftey Interface. • Control identifies its own security level • “I am not safe to script!” • COM subsystem validates the IObjectSaftey interface prior to loading the control. • Object.IObjectSaftey.GetInterfaceSafteyOption • INTERFACESAFE_FOR_UNTRUSTED_DATA = SFS • INTERFACESAFE_FOR_UNTRUSTED_CALLER = SFI • SetInterfaceSafteyOption also supported. • Only security method supported by Windows CE.

11. Internet Explorer v6 Backward Compatibility Supported • HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Internet Explorer\ActiveX Compatibility\{CLS-ID}\Compatibility Flags • COMPAT_SAFEFOR_LOADING = 0x00800000 • “This compatibility flag can be used to disable the Internet Explorer 7 IObjectSaftey check and revert back to Microsoft Internet Explorer 6 behaviour” • ActiveX Kill Bit • HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Internet Explorer\ActiveX Compatibility\{CLS-ID}\Compatibility Flags • 0x00000400 = EVIL_BIT (Kill bit) • Kill’d CLS-ID’s cannot be loaded by IE. • Updated Kill Bit lists distributed through Windows Update.

12. Querying An ActiveX Control • Using OLEView we can query an ActiveX through its TypeLib • Type libraries describe the contents of a COM component. • Exposed interfaces, methods, properties and constants. • Method type definition • TypeLib’sare either embedded with an ActiveX control. • An additional .TLB file. • Or not present at all. 

13. OleView Example

14. ActiveX exploitation has grown with popularity • 50 remote command execution bugs in ActiveX in 2006. • 1 in 2001 • Over 110 ActiveX exploits on MilW0rm.com • Popular attack path for browser exploitation. • ActiveX controls run in same context as Internet Explorer. • Hacking clients is the new ‘in-thing’.

15. Why Is ActiveX So Insecure? • Compiler security disabled: SafeSEH turned off, /GS Disabled • (most) ActiveX controls use the default Windows heap allocator. • Controls not sandboxed, can manipulate COM/IE functionality. • ActiveX security controls are purely opt-in • Developers mark controls SFS & SFI when not required. • Many controls were never designed to be scripted by IE. • “There were only 7 days Internet Explorer was safe to use in the entire year of 2004.” • ActiveX Controls are shipped with commercial software. • Users are not informed about control installation.

16. ActiveX Bugs Can be Classified into Three Groups: • Insecure Method Functionality • Insecure Object Instantiation • Insecure Scripting • #1 - Insecure Method Functionality. • Legitimately using the method of a control, to do something malicious. • SFI or SFS exploitable. • Friendly Technologies Dialler – Execute Arbitrary Commands

17. PBEmail Arbitrary File Overwrite (SFS + SFI) • WebLaunchArbitrary Command Execution (SFS + SFI) • Synactis All In The Box – Null Byte File Overwrite (SFS + SFI)

18. #2 - Insecure Object Instantiation • An ActiveX instantiated with malicious persistent input. • Control only marked Safe For Initialization. • User Supplied Persistent Values used as Control Parameters. • Common application development vulnerabilities. • Stack/Heap overflows. • Integer overflows • Format String vulnerabilities • Malformed input causing an application exception. • Long string supplied to a method. • Long string assigned to a control property. • Large numeric passed to a method.

19. #3 – Insecure Scripting • Control marked Safe For Scripting. • An ActiveX method scripted with malicious input. • JavaScript/VBScript used to interact with the control. • Vulnerable to common application development vulnerabilities.

20. Finding ActiveX Vulnerabilities. • Query ActiveX’s installed on the system • Lookup the UUID (GUID) value in the co-class. • Search the registry for the GUID, is it SFS? • It may still be SFS without an Implemented Security Category. • Axenum (Part of AXFuzz) to enumerate IObjectSafteySettings

21. Fuzz the fuck out of it! • I Use COMBust, simple, effective, no false-positives. • combust -c {GUID} • Overwritten function pointer.

22. Easy Exploitation: Heap Spraying. • Method pioneered by Skylined, ZenParse, Alex Sotoriv • Used since 2004, still works. • Use JavaScript to allocate (lots) of memory on the heap. • Control the structure of the heap from JavaScript • Overwrite a function pointer/SEH/Return address • Jump to the JavaScript allocated heap, execute shell-code. • Develop stack and heap overflows fast!

23. Empty Heap • Windows Address Space Layout Randomization • Heap is somewhere • We don’t know where, 32 possible locations. • If you can point EIP Somewhere • Where would you point?

24. JavaScript allocates lots of (NOP slide + Shellcode) • Under certain circumstances Jscript.dll uses the common Windows heap allocator. • Use JavaScript to allocate ‘heaps of heaps.’ • 0x0C0C0C0C will be one of those heaps • Get EIP here • You win.

25. “Heap Fung Shui” – HeapLib.js • Automated JavaScript Heap Manipulation : HeapLib.js • Supports IE 5-7, Object oriented JavaScript API • Supports: • Heap logging and debugging • Allocation and freeing of blocks with arbitrary sizes • High level heap manipulation (very easy) • Control the heap. • Takes only minutes to create an ActiveX exploit, and pop shell. • Very easy, allows for lazy exploitation. • Heap spraying lacks hacker finesse. • “Allocate Spray 0x0c0c0c0c everywhere, until somthing goes there”

26. Why Does Heap Spraying Work? • The heap (data pages) are executable in the IE 7 process. • DEP is *NOT* enabled for IE 5-7 • Certain JavaScript strings are stored on the shared Windows heap. • var test = “aaa” ; is not on the OS heap. • var test = test.substring(0, test.length); is on the OS heap. • (Most) ActiveX controls use the generic Windows heap allocator. • ActiveX heap overflow will overflow into the IE/COM heap. • COM is written in Visual C++ • Makes use of (thousands) of function pointers. • Heap overflows often lead to function pointer overwrites.

27. COM makes use of (LOTS) of function pointers • Function pointers are kept on the heap. • You blindly overflow these function pointers with the location of your heap spray. • 0xc0c0c0c0 • 0xC0 = ADD al, 90 (NOP like instruction) • Instruction can be executed, read, jumped to! • JavaScript allocates (lots) of memory so that 0xC0.... exists. • Many COM function pointers are overflowed with c0c0c0c0. • Overwritten function pointer is called by COM. • 0xc0c0c0c0 is executed.. You pop shell.

28. It All Changes With IE 8 • Internet Explorer 7 Opt-Out of DEP Due to Plug-in Compatibility • Flash, Java do not support DEP. • Internet Explorer 8 is DEP opt-in by default. • Flash, Java now support DEP! • DEP disables code execution from the heap. • New jscript.dll which has a “Not Executable” marked heap. • “Ahem, that will not work in IE 8” • Anyone Can Install ActiveX’s in IE8 (Not just administrators!) • Unsafe methods will still exploitable. • “Click this control to active it” removed.

29. SiteLock Interface • New method in IObjectSaftey to protect controls from being loaded from arbitrary websites. • Controls implement their own per-site control with SiteLock. • Users can allow the control for a specific Web site, all Web sites or disallow the control.

30. Shell Poppin’ All Hail The Demo God • Demo: • Find an ActiveX vulnerability • Exploit it through Heap Spraying • Pop shell • Easy.
