slide2

How measuring an earthquake ?

 inertial pendulum (same idea since 130 years !)

Seismometer

Seismogram

Seismograph

@ 10 km: M = 3  2 µm

M = 5  0.2 mm

slide3

Bifilar (Zöllner)

Different design of seismometers

Leaf spring

LaCoste

Spring

Inverted pendulum

Garden gate

slide5

First modern seismographs (1)

  • XVIII & XIX : First Italian seismoscopes
  • 1875 : Filippo Cecchi: Seismograph (very low sensitivity : 3 X)
  • 1887 : First known recording of F. Cecchi
slide6

Pen writing on a black-smoked glass

First modern seismographs (2)

  • XVIII & XIX : First Italian seismoscopes
  • 1875 : Filippo Cecchi: Seismograph (very low sensitivity)
  • 1887 : First known recording of F. Cecchi
  • 1880 : James Ewing : first recording and evaluating the ground movements

Ewing (1883):

“ (1) The very gradual beginning and ending of the disturbance. In none of the observations did the maximum motion occur until after several complete oscillations had taken place.

(2) The irregularity of the motion. The successive undulations are widely different both in extent and in periodic time.

(3) The large number of undulations in a single earthquake, and the continuous character of the shock.”’

For the first time, also, seismologists could design their instruments with some knowledge of the phenomena the instruments were to record.

slide7

First modern seismographs (3)

  • XVIII & XIX : First Italian seismoscopes
  • 1875 : Filippo Cecchi: Seismograph (very low sensitivity)
  • 1887 : First known recording of F. Cecchi
  • 1880 : James Ewing : first recording and evaluating the ground movements
  • 1889 : Ernst von Rebeur-Paschwitz : first teleseism (Japan) recorded in Postdam. Magnification: ~ 100 X
  • Ca 1900 : first network of seismograph build by J. Ewing, first seismogram bank, application of elastic waves theory to the seismic movements (P, S waves, Earth’s core)
slide8

18 February 1898 : request of Ernest Solvay to the Minister Schollaert

“Les travaux scientifiques (…) nécessitent, M. le Ministre,une installation souterraine dans un lieu tranquille et protégé, à l’abri des trépidations du sol, et en même temps où l’heure puisse être connue avec une grande précision”

“The ROB was the only quiet location in Belgium where accurate time could be provided”

slide9

The « Ernest Solvay » stationFirst recording in March 1899

The von Rebeur-Ehlert triple pendulum

(museum ORB)

Eugène Lagrange (1855-1936),

Professor of physics at the RMS,

Corresponding Astronomer at the ROB.

slide10

Kafkaian tribulations in 1900 …

il fallait rechercher « un luminaire bien constant, suffisamment intense, d’une fixité aussi grande que possible, dégageant peu de chaleur ou disposé de manière à ce que la chaleur ne put nuire, et pouvant, au minimum, fonctionner quatre jours sans surveillance ».

In spite of the authorization from the minister, and payment of the electricity, E. Lagrange and E. Solvay had to wait for 10 months and to exchange 2 dozens of letters with E. Goedseels, « Commissaire du gouvernement administrateur-inspecteur de l’ORB », to obtain…. Light!

slide12

The bulletins (annales de l’ORB >1903)

The donation of the Ernest Solvay station to the Belgian State became officially effective on 01 January 1904.

(Royal Decree given in Laeken on Novembre 28, 1903

(Moniteur 9/12/1903)

slide15

W

N-S

Alaska (MS = 7.9)

t

The early years 1899-1911 (1)

  • 21 March 1899: first earthquake recorded in Belgium using the von Rebeur-Ehlert pendulum (?)
  • 4 September 1899 : First earthquake officially recorded
  • 1901 : Lagrange commissioned by J. de Trooz to the permanent seismic commission funded in 1899 and sit in Strasbourg in April 1901. During this meeting E. Lagrange was member of the commission which created the International Association of Seismology (Association Internationale de Sismologie).
  • 1st January 1904 : E. Solvay donates the station to Belgium ; Oscar Somville (1880-1980) is the first head of the seismology service
slide16

The early years 1899-1911 (2)

  • June 1906 : installation of 2 horizontal “Bosch-Omori” seismometers (recording on smoked paper drums), magnification ~ 10 X
slide17

The early years 1899-1911 (3)

  • 1909 : von Rebeur-Ehlert declared obsolete
  • 1909 : Horizontal Wiechert pendulum (1000 kg)
  • 1910 : Vertical Wiechert pendulum (1300 kg)
  • 1911 : Bosch-Omori declared obsolete
slide18

Sketch of the Wiechert seismometers

© EOST

Horizontal components

Vertical component

Magnification: ~200 X

slide19

The early years 1899-1911 (4)

  • 1911 : Galitzin horizontal pendulums

Bifilar

slide21

The timing

  • 1909 : Clock synchronized with the Time Office (daily, ~ 1 s)
  • 1912 : Continuous synchronization (~ 0.1 s)
  • 60ies: RTB and Neuchâtel (CH) 75 kHz synchronization, quartz clocks
  • 1984 : DCF 77 kHz receivers (~ 0.01 s)
  • 1998 : GPS receivers (< 0.001 s)
slide22

The other early historical stations : Frameries

  • En 1902, installation of a network to study grisouto-sismic correlation and improve meteorological studies.
  • Stations provided with von Rebeur-Ehlert pendulums, installed by the Société belge de géologie, d’hydrologie et de paléontologie, managed by E. Lagrange.
  • Frameries (mid-1903) : Agrappe coal mine, Fosse Grand-Trait, 850 m depth, very high risk of firedamp explosion.
slide23

The other early historical stations: Quenast

  • Quenast (fin 1902): porphyry quarry as comparison station outside the coal basin. Uccle could have fulfill this requirement, but « il a paru préférable d’installer une station nouvelle sur un sol considéré comme un des plus stables». On the other hand, Lagrange wrote: « A sensibilité égale, les déplacements pendulaires en général sont beaucoup moins considérables à Quenast qu’à Uccle; l’agitation sismique due au vent est infiniment moindre à Quenast (…)»

« On voit les conduits métalliques peu gracieux, mais nécessaires, que l’aérage de la station nous a amené à installer, pour en assécher autant que possible l’atmosphère intérieure. Si l’œil n’est pas satisfait, le but à atteindre nous forçait à y avoir recours; la buée qui se déposait sur les glaces de l’enregistreur empêchait toute image nette des points lumineux. Que l’esthétique nous pardonne! »

slide24

Planed stations (beginning of the XXth century)

  • The time series from Quenast and Frameries were not usable because of the lack of accurate timing, but a correlation between microseismic noise and the weather were observed
  • Coal mines in Liège
  • Colfontaine
  • Coastline (“Mistpoeffers” or « Barisal guns », )
  • Bosch seismometers given to the Ministry of Colonies and sent to Elisabethville (…)
slide25

The difficulties

« La phase d’installation a réclamé beaucoup de temps, énormément de peines et a eu à surmonter maintes difficultés inattendues qui, toutefois s’aplanissent de jour en jour. A Quenast c’était l’humidité, tellement forte et persistante, qu’il a fallu changer d’emplacement et reconstruire de fond en comble les locaux de la station.

A Frameries, dans les profondeurs de la mine grisouteuse, ce furent les recherches relatives à la suppression du danger de l’éclairage électrique (par accumulateurs, à remplacer journellement) qui ont été le principal obstacle à la mise en train et au bon fonctionnement des appareils »

Given the problems, this first attempt to establish a seismic network was stopped …

slide26

Dourbes-IRM (since 1958)

  • Warmifontaine (1964-1970), stopped due to the costs requested by the slate quarry to replace the photographic paper
  • Luxembourg (1967-1972), moved to Walferdange

Other historical stations after 1958

  • La Gileppe (1968-1970), moved to Membach
slide27

Thierry Camelbeeck

1918-2056

The « cabin » (1962-1984)

6 channels paper-ink drum recorders + analogue recordings on magnetic tapes

slide28

Thierry Camelbeeck

1918-2056

The earthquake of Liège

8 Novembre 1983 at 0h 49m (TU)MS = 4.7

Commune of St Nicolas

CHEMINEYS

161 calls

813 interventions (fire brigade)

FACADES

211 calls for shoring up

356 shoring up by official services

HABITABILITY

93 houses declared as uninhabitable

DEMOLITION

15 completely destroyed

 Cost : ~ 250 106 EUR

slide29

After 1985

© C. Fleischer, BNS

slide32

Precision in localizing earthquakes

Magnitude:

Catalogue is complete after

1926 (M>4)

1960 (M>3)

1985 (M>1.8)

Camelbeeck, 1992

slide33

Belgian seismologists

Oscar Somville

1880-1980

Eugène Lagrange

1855-1936

Charles Charlier

1897-1953

Jean-Marie (as Théo) Van Gils

1918-1989

slide34

Thierry Camelbeeck

1918-2056

Heritage: Protection of historical seismograms

Euroseismos project

Belgian Science Policy :

Digitalization of the scientific and cultural

heritage in the Federal Scientific Institutes

slide35

Why studying seismology in Belgium?

  • The seismic network
    • Monitoring of the seismic activity in our regions:
    • localization, magnitude, … (including the smallest events)
    • seismic alert with the authorities :
    • localization and impact of the earthquake provided to the Crisis Centrum
    • Scientific studies on the seismicity in North-western Europe
  • Prevention (seismic hazard)
    • Instrumental data :
    • Quality of the archives
    • Historical data :
    • Study of destructive earthquakes since the Middle-age and historical criticism
    • Geological and paleoseismological data
slide36
