    1. Xray Rounds: Carpal Instabilities Heather Patterson PGY 2 September 7, 2006

    2. Objectives • Anatomy • Bones • Ligaments • Exam • Bones • Ligaments • Mayfield Classification of Carpal Injuries • Cases

    3. Anatomy: Bones • PA: • 3 smooth arcs • Proximal and distal surfaces of the scapoid, lunate, triquetrum • Proximal articular surface of the capitate and hamate NOTE: improper positioning can cause overlap patterns

    4. Anatomy: Bones • Lateral: • 4 C’s • Axis of the radius, lunate and capitate is collinear

    5. Anatomy: Liagments • Extrinsic: • Volar: • 2 arcades • V shaped • Proximal & distal • Space of Poirier • Dorsal: • Less strong than volar groups • Space of Poirer: • Between radiocapitate and radiotriquetral ligaments

    6. Anatomy: Liagments • Intrinsic: • Attach carpals • 2 key ligaments: • Scapholunate • Lunotriquetral

    7. Anatomy: Bones • Lateral: • Scapholunate angle • 30-60 degrees • If <30 indicates lunotriquetral ligamentous injury • >60 indicates scapholunate ligamentous injury

    8. Anatomy: Bones • Lateral: • Capitolunate angle • 10-20 degrees • Requires a true lateral to be acurate • ↑ angle • Consider carpal ligamentous injury

    9. Clinical • Scaphoid • Lister’s Tubercle • Scapholunate joint • Lunate and capitate • Triquetrum and TFCC • Scaphotrapezium joint • Pisiform • Hook of Hamate

    10. Clinical • Scaphoid • snuffbox • Lister’s Tubercle • Prominence on radius, EPL wraps around this • Scapholunate joint • Immediately distal to Lister’s tubercle • Lunate and capitate • Immediately ulnar to scapholunate joint • Triquetrum and TFCC • Immediately distal to ulnar styloid • Scaphotrapezium joint • Base of thenar eminence • Pisiform • Base of hypothenar eminence • Hook of Hamate • Soft tissue distal and radial to pisiform

    11. Clinical: Watson Shift Test • Place thumb on volar aspect of scaphoid tuberosity and apply pressure while bringing wrist from ulnar to radial deviation • Sensitivity: ~60-67%’ • Specificity: poor • Wolfe et al (1997) demontrated a 36% false positive rate with 25 healthy volunteers

    12. Clinical: Lunotriquetral instability • Kleinman shear test • Reagan shuck test Linscheid compression test

    13. Mayfield Classification

    14. Stage I: Scapholunate Dissociation • Disruption of scapholunate ligament • Isolated scaphoid subluxation +/- rotation • Xray: • >3mm space between scaphoid and lunate “Terry Thomas” sign • +/- signet ring sign • Scapholunate angle >60 degrees

    15. Stage II: Capitate Dislocation • Disruption of radiocapitate ligament and opening of Space of Poirier • May be associated with scaphoid fracture • Xray: • PA: overlap of carpal rows • Lateral: • volar tilt of lunate but maintains articulation with radius • dorsal dislocation of capitate

    16. Stage III: Lunotriquetral Dissociation • Failure of radiotriquetral ligament • Perilunate dislocation with triquetral dislocation • May be associated with volar triquetral fracture • Xray: • Perilunate dislocation • PA – overlap of triquetrum on lunate or hamate

    17. Stage IV: Lunate Dislocation • Disruption of dorsal radiocarpal ligament • Disruption of all intercarpal joints and most major carpal ligaments • Associated #: • Xray: • PA: Lunate appears triangular, “piece of pie” • Lateral: • “Spilled teacup” sign • Capitate and all carpals lie posterior to lunate on lateral

    18. Cases

    19. Cases

    20. Cases

    21. Cases

    22. Cases

    23. Cases

    24. Cases

    25. Cases

    26. Cases

    27. Cases

    28. Cases
