  1. CORONARY ANGIOCARDIAC CATH& Ablation ProceduresLecture # 3 ACardiac Anatomy & Circulation& Pathology Review # 3B RT 255 (rev 2010) Dawn Charman, M.Ed,R.T Reference: Frank. Merrill's Atlas of Radiographic Positioning and Procedures, 11th Ed. Mosby

  2. What is cardiac cath? • Procedure which involves placement of a catheter into RT or LT side of heart. • Invasive • Coronary angiography is often included together with cardiac cath • Diagnostic procedure and/or • a therapeutic procedure • Adults & Children Check out procedure Video: http://www.youtube.com/watch?v=kY5gKdFWT3k&feature=related

  3. This procedures provides the doctor with a "road map" of the arteries in the heart To find any areas of blockage in the arteries that supply the heart with blood. May also look at the valves, chambers & heart muscle Can help in making decisions about the treatment of heart disease. It is a usually performed by a cardiologist with assistance by RT,(CIT), nursing & support staff* Cardiac Catheterizationalso known as a heart cath or coronary angiogram

  4. Who performs the procedure? • The Interventional Radiologist / Cardiologist • who specializes in the Angioplasty procedure. • CIT Technologist • Nursing • Other support staff

  5. Cardiac cath requires special equipment: • Angio supplies & equipment • Fluoro Imaging (w/ Cine – Digital) • & Ancillary equipment * Type of catheter used will be dependant on the type Of Procedure performed

  6. Done in a “Cath Lab” • Cath lab includes • a special table, • x-ray tube &monitor, • supplies (catheter, guidewire) • automatic injector pressure • Cardiac monitors • Vitals monitors B/P , pulse ox, Improvements in digital storage & resolution has largely replaced cine Study can be stored on CD-R or DVD’s for review

  7. Cardiac catheterization • The oxygen concentration can be measured across the valves and walls (septa) of the heart • Pressures within each chamber of the heart and across the valves can be measured. • The technique can even be performed in small, newborn infants. • The catheter also serves the purpose of monitoring blood pressures in these different locations inside the heart. • The angiogram procedure takes several hours, depending on the complexity of the procedure.

  8. Basic info about procedure • IV sites in either arm, groin, or neck. • Flexible catheter inserted to IV through the blood vessel. • Then, cathether is threaded thorough the blood vessel to the heart. • Pressure measured at this point. • Iodinated contrast injected through catheter once it reaches the heart. • Fluoroscopy guides the cardiologist with the catheter location.

  9. Normal Rt & Lt Coronary Arteries

  10. What Method is this? 12

  11. Catherization: Selinger Technique * *Modified Seldinger only punctures one side of vessel – this Percutaneous method can be used for arteries or veins - describes the method of catheter introduction that is not a direct stick 13

  12. Seldinger Technique

  13. What is this?When is it used inCardiac Cath? • used to inject a large amount (25 to 50 mL) of contrast material into either the right or left ventricle the aortic root, or the pulmonary vessels. • Because the coronary arteries are of small caliber and of low flow rate, administration of contrast medium into these structures generally does not require a high-pressure injector. 15

  14. CARDIAC CATHETERS • May be inserted in an artery or vein • information is collected on the valves, chambers, and arteries, as well as the structure and function of the heart • A cardiac cath can show a cardiologist the precise location of a blockage or defect • The advantages of catheterization are as follows: 1. The risk of extravasation is reduced. 2. Most body parts can be reached for selective injection. 3. The patient can be positioned as needed. 4. The catheter can be safely left in the body while radiographs are being examined. • A:Judkins RT B:Judkins LT C: Pigtail Cardiac cath video: http://www.youtube.com/watch?v=yzxSrLa1d0g

  15. Catheter can be introduced through femoral, brachial or carotid artery to the knob of the aorta for coronary arteries It may be advanced to the left heart to look at the LT ventricle • Radial, Subclavian & jugular may also be used depending on Physician choice and Pt condition • Seldinger Tech is a percutaneous method for the femoral approach

  16. Guidewires & Needles

  17. Percutaneous Transluminal Coronary Angioplasty (PTCA) • Otherwise known as: • Balloon Angioplasty • Angioplasty • PTCA • Balloon Angioplasty is a technique used to dilate an area of arterial blockage with the help of a balloon catheter. • It is a way of opening a blocked blood vessel.

  18. Balloon Angioplasty • A small area of the groin or arm is shaved and cleaned where the catheter is inserted. • Medication is used to anesthetize the area so a small incision can be made where the catheter will be inserted. • A catheter with a deflated balloon on the tip is inserted through the artery in the groin or arm. • X-ray is used to guide the catheter up into the heart. • One Possible Complication: • Plaque material or blood clots dislodging and floating downstream, leading past the treated area

  19. Balloon angioplasty and a stent are used to open up the stenotic left brachiocephalic vein. Excellent blood flow was restored in subsequent images.

  20. Equipment Used During a Procedure: • Balloon Catheter • Metal mesh stent • Pump for balloon • Usually a metal stent is placed in the opened artery to make sure restenosis does not reoccur • Following the procedure, the balloon is deflated and additional x-rays are taken to determine how much blood flow has increased.

  21. Prevention of Restenosis • Lifestyle Change • Healthy diet • adequate exercise • No Smoking • Medicine coated stents Although Balloon Angioplasty is a valuable tool it is not a cure for Artherosclerosis. It is only a treatment, Patients should try to lead a healthy life which will be the best treatment for their arteries.

  22. Coronary Artery Bypass Graft Surgery • is a surgical procedure to treat severe coronary artery disease (heart disease). • Part of a vein or artery (called a graft) from another part of the body is used to bypass a blockage in one or more of the coronary arteries. • The type of graft used, • a vein* from the leg, • or an artery from the chest, • depends on the number • and location of the blockage.

  23. Stent Placement http://images.google.com/imgres?imgurl=http://www.nhlbi.nih.gov/health/dci/images/stent_restenosis.gif&imgrefurl=http://www.nhlbi.nih.gov/health/dci/Diseases/stents/stents_all.html&usg=__xDlbsaX9JhuYbpVojLcz19apr-I=&h=513&w=450&sz=59&hl=en&start=20&tbnid=vWwqaG-RNW7M-M:&tbnh=131&tbnw=115&prev=/images%3Fq%3Dabdominal%2Bstents%26gbv%3D2%26hl%3Den 25

  24. AAA 26
