Presentation Transcript
agenda
Agenda
  • Purpose:
    • Content of Release 3
    • Operational acceptance testing and results
    • Readiness to promote Release 10.1 candidate.5 to Release 3 Operations.
  • Agenda
    • Release 3 Overview Dave Warren
    • Acceptance Testing Mike Miller
    • Acceptance Testing Open IDRs Mike Miller
    • 10.1 Delivery Plan Mike Miller
    • Customers Ready for Transition Ame Fox
    • Summary and Recommendation Mike Miller
    • Follow-on Activities Mike Miller

SNAS Release 3 DRR – March 2, 2010

release 3 overview 1 of 3
Release 3 Overview (1 of 3)
  • Release 3 software resolves:
    • 12 Wishlist items: 8 general, 4 from JSC
    • 23 Discrepancy Reports (DR) from Operational Releases 1 and 2
    • 14 Interim DRs (IDR) uncovered during acceptance testing
    • 83 Bugs opened during development, system or user testing

Note: Release 3 Content slides at end of presentation

SNAS Release 3 DRR – March 2, 2010

release 3 overview 2 of 3
Release 3 Overview (2 of 3)
  • Functionality Added
    • Streamlined MOC Client Menu
      • Reduced duplication on Main Control menu and submenu options, especially in generating reports and queries
    • Enhanced Recurrent Scheduling
    • Added DAS scheduling to Graphical Timeline
      • Added RAR, RAMR, and DASMAR objects and functionality similar to SAR, RR and USM
    • Localization of individual client.prop properties
      • Alternative way of pointing to local, user specified properties instead of central, system-wide client properties
    • Improved O&M Client control
      • Send messages to specific Users
      • Tracking mission changes through review history
      • Notifying Users when Mission changes submission fail

SNAS Release 3 DRR – March 2, 2010

release 3 overview 3 of 3
Release 3 Overview (3 of 3)
    • Enhanced EPS TCP/IP capability
      • Message causes exception
      • Fixed UPD configuration inhibiting displays in the GUI
      • Client did not listen after disconnect/reconnect
      • Handles SARs with zero keywords for SSCs
    • Upgraded COTS on system servers
      • Linux OS, Oracle driver, JDK and JRE, and Eclipse development tool
      • Clients will require JRE update to 1.6.0_15
  • Documentation
    • MOC Client Users Guide updated to reflect changes
    • SNAS/EPS ICD reflecting new message changes

SNAS Release 3 DRR – March 2, 2010

acceptance testing
Acceptance Testing

Acceptance Test Plan

Sixteen test scripts developed by SNAS from their System Testing

Test cases were developed for specific Wishlist items, DRs and Bugs, and addressed functional regression testing

Testers

WSC Tech Ops

HST and JSC personnel

Beta testers from SN community (FGST and Swift)

Environment

ANCC

DAS HMD

Results

For Candidate.4 baseline, 15 of 16 test cases were passed

Remaining High Availability test case to be performed on WSC OPS servers when servers return to redundant SN configuration

SNAS Release 3 DRR – March 2, 2010

acceptance testing open idrs 1 of 2
Acceptance Testing Open IDRs (1 of 2)

Open IDRs will be converted to Release 3 (10.1) DRs

No significant impacts to Customer Operations

MOC/WSC workarounds documented (customer perspective)

Open IDRs turned into OPS DRs, and will be addressed in the next release

27478 Directory Warning for TCP/IP Node

27463 TCP/IP Node stopped receiving SRMs when sFTP node forward flag set to false

27460 Unexpected Decline of RR though SA time available in TUT

27455 Events marked Completed prior to execution time

27444 Bulk Modify time slip processes events incompletely

27396 IP GUI doesn't show all IPs

27356 Shift Change Does not always take effect

SNAS Release 3 DRR – March 2, 2010

acceptance testing open idrs 2 of 2
Acceptance Testing Open IDRs (2 of 2)

27478 Directory Warning for TCP/IP Node

Opened by JSC, an annoyance

27463 TCP/IP Node stopped receiving SRMs when sFTP node forward flag set to false

Opened by JSC, configuring both TCP/IP and SFTP nodes for the same messages causes duplicate messages, turning one off affects other (MOC operations has a workaround)

27460 Unexpected Decline of RR though SA time available in TUT

Opened by HST; for Release 3, adjusted TUT retrieval mechanism – watch

27455 Events marked Completed prior to execution time

Opened by HST, first time noticed – watch (workaround is to call NCC scheduler for event modifications if needed)

27444 Bulk Modify time slip processes events incompletely

Opened by HST; may be related when multiple connections for the same connection ID is enabled; contact SN OPS for assistance (see SN Alert notice)

27396 IP GUI doesn't show all IPs

Opened by WSC O&M, first time noticed – watch

27356 Shift Change Does not always take effect

Opened by JSC, first time noticed – watch

SNAS Release 3 DRR – March 2, 2010

10 1 delivery plan
10.1 Delivery Plan

Go/No Go at DRR (March 2nd) Marty Antholzner

Release NAM (no DAS availability, move to legacy, Mike Miller

customers will be supported by OPS schedulers)

March 9 Delivery

Mike Miller – Delivery Lead

T-0 to T+6 hours

Perform cold database backups on OPS DB instance

Shut-down and restart for single DBA user Juan Gonzalez

Run Purge scripts to remove dynamic data Mike Goen

Run scripts to reformat Oracle DB files on OPS Juan Gonzalez instance Mike Shih

Perform cold backup of Ops database Juan Gonzalez

Activate Release 3 (10.1) OPS on EIF servers Scott Robinson

Validate successful delivery switch Mike Miller /

Manny Rios

“Back to operations” NAM (with Release 3 MOC Client) Mike Miller

Delivery Complete, SNAS users back to operations using Release 3

SNAS Release 3 DRR – March 2, 2010

customers ready for transition
Customers Ready for Transition
  • MCEs and NOMs contacted each MOC using SNAS operationally by email and/or phone

Status

Misson User of for Rel 3

  • ALOS NCC unknown
  • CNOFS (Hanson, Kirkland) NCC/DAS unknown
  • EO-1 NCC testing
  • FGST NCC/DAS Ready
  • GALEX NCC unknown
  • ISS NCC Ready* expecting a 3/8 transition
  • LDBP/ULDBP NCC/DAS Will be Ready by next mission
  • SPTR-2 NCC Ready
  • Swift NCC/DAS Ready
  • THEMIS NCC Ready
  • TIMED NCC unknown
  • WISE NCC Ready

SNAS Release 3 DRR – March 2, 2010

summary and recommendation
Summary and Recommendation

All testing was completed and successful

HA to be performed once OPS mode is up

All IDRs addressed

Non-impacting to SN Customer operations

Workarounds documented – via Alert notice

Back-out plans in place

Both system and database will be copied for back-out

Backups to be reapplied for back-out, if needed

Final verification of customer readiness feedback

Recommend Delivery – baseline SNAS 10.1 (candidate.5)

“Back to Operations” NAM ready to be issued to SN Community

SNAS Release 3 DRR – March 2, 2010

follow on activities
Follow-on Activities

Training of TOCC and MOC personnel available

via WSC personnel in the ANCC

via NOM phone/email support

Upgrade of OPS mode servers to COTS versions

Return to server redundancy

High Availability count verification

Formal Delivery package – to be checked into WSC CM

Media and release letter shipped from GCP

SNAS Release 3 DRR – March 2, 2010

release 3 content wishlist items
Release 3 Content - Wishlist items
  • W/L 13 Combine NCC and DAS scheduling.
  • W/L 25 Provide tools to support log management
  • W/L 41 COTS upgrades (Linux 5.3, JRE 1.6.0_15, Eclipse, etc.)
  • W/L 42 Streamline MOC main menu
  • W/L 46 Allow O&M to select a user to send message to
  • W/L 47 Localization of client.prop file
  • W/L 53 Provide O&M review history
  • W/L 59 Add Event ID to Confirmed Events Reports
  • W/L 61-13 Pattern display drops, until configuration is saved.
  • W/L 61-14 Display doesn't index back to where user's last input was made.
  • W/L J/L11 It's preferable to provide the capability for user to select colors of Alert panel text and background.
  • W/L J/L16 The default start time of Active Events Summary should be the current time

SNAS Release 3 DRR – March 2, 2010

release 3 content ops discrepancies 1 of 2
Release 3 Content – Ops Discrepancies(1 of 2)
  • 52475 SNAS/Server - High Availability - failed counts not incrementing
  • 56443 A large number of requests disappeared from the EIF database
  • 56490 KASAR normal SSC GUI will not except values
  • 56491 Continuous red alerts when DAS is disconnected
  • 56493 O&M Client must warn user when manual SNIF restart is required
  • 56494 SNIF sends SARs for unassigned SIC on another SIC's connection
  • 56495 NumberFormatExceptions in SNIF log files
  • 56499 TCP UPD Configuration inhibits display in GUI
  • 56500 TCP/IP Message causes exception
  • 56501 Intermittent display update issue on Active Events Summary
  • 56524 SNIF transmitter thread queue overstock when connection is down
  • 56526 SNAS O&M Client Cannot Delete Obsolete User Accounts

SNAS Release 3 DRR – March 2, 2010

release 3 content ops discrepancies 2 of 2
Release 3 Content – Ops Discrepancies (2 of 2)
  • 56786 Lost Connectivity with DAS and SDIF On SNAS
  • 56879 SNIF exception when Acq Failure Notification message received
  • 57068 LDBP Unable to Schedule or GCMR DAS events via SNAS
  • 57069 SWIFT SNAS Client Drops UPD Logging
  • 57143 WISE Unable to Schedule events receiving constant alarms
  • 57239 FGST not receiving data since DASCON reboot
  • 57251 SNAS SSC Parameters incorrect read back
  • 57293 TDRS 10 / SGLT 2 LDBP GCMR Processing
  • 57303 TDRS 10 / SGLT 2 LDBP GCMR Processing
  • 57311 TDRS-6 / SGLT-1 SSA2 and MAR LDBP were unable to send GCMRs
  • 57318 TDRS 6 / SGLT 1 LDBP GCMR Processing

SNAS Release 3 DRR – March 2, 2010

release 3 content interim drs at
Release 3 Content – Interim DRs (AT)
  • 27382 SNAS delivery 3 isn't generating UPD selects on AT
  • 27384 Bulk Replace is losing TSW constraining
  • 27385 EPS file Type Entry fields complain even when not needed
  • 27386 TSW message on TCP/IP Interface alert message missing data
  • 27393 TSW transmission is intermittent
  • 27413 Reports include events outside of requested time frame
  • 27419 Modification of Schedule (RAMR) Using Graphic Timeline
  • 27420 USMs created from SNAS GUI not forward to TCP/IP clients
  • 27423 DAS Schedule Clone Feature Using Graphic Timeline
  • 27425 Error processing reconfig GCMR from TCP EPS
  • 27430 Schedule Request Summary Request Message doesn't conform to the ICD
  • 27446 Make minimum duration default to specified duration
  • 27462 Problems adding new DAS SSCs
  • 27480 Resetting TSW flag on RR against Confirmed SARs

SNAS Release 3 DRR – March 2, 2010

release 3 content bugs 1 of 3
Release 3 Content – Bugs (1 of 3)
  • 159 SNAS log files must not contain binary data
  • 203 Unnecessary pull down options
  • 207 OAM Client cannot approve/reject a request
  • 369 Allow O&M to select a user to send message to
  • 405 Recurrent scheduling generates SARs with incorrect times
  • 407 Localization of client.prop file
  • 417 Alias missing from Available SSC panel
  • 419 Uncaught exception when user's certificate files not found
  • 428 Incorrect Services displayed on Active Schedule Request Summary
  • 469 Provide O&M review history
  • 519 Add Event ID to Confirmed Events Reports
  • 523 Duplicate active events have incorrect "Service Type Antenna" info
  • 536 Various StreamCorruptionExceptions
  • 544 MOC Client log file using local timezone on SAR data details
  • 545 Return receipts being lost between SAM and MOC Client
  • 606 Purge of UPD data failed on WSC EIF2 database
  • 608 Various StreamCorruptionExceptions
  • 610 SAM-Sve connections lost due to timeouts
  • 641 Bulk import does not validate the reference Id against the SIC
  • 649 intf check's on Orbital Parameter panel can't be modified
  • 653 Schedule Request Summary Filters : upper/lower bounds fields need numeric validation
  • 655 EnumExtStatusExpCode enum error
  • 658 Need DB commit/ rollback capability when saving / deleting from RS
  • 659 Active Events Summary Filters: Event ID Criteria upper/lower bounds fields need numeric validation
  • 660 SAM is triggering a "Full" garbage collection every 11 seconds
  • 661 MOC Client disconnect from SAM - digit count range invalid; Various StreamCorruptionExceptions
  • 667 SAR Panel doesn't stop one of its threads when it closes
  • 668 Duplicate calls to addWindowListener in SnasFrame subclasses should be removed

SNAS Release 3 DRR – March 2, 2010

release 3 content bugs 2 of 3
Release 3 Content – Bugs (2 of 3)
  • 669 String values should be compared using .equals, not ==
  • 672 Need a Recurrent Scheduling Request Message for the EPS ICD
  • 673 Cannot print fully detailed Active Events Summary
  • 675 Active Event Summary panel is pulsing
  • 676 Active Schedule please wait notification panel not always closed when data is received
  • 677 AlertProcessor receipt timer should be cancelled on Logout
  • 679 Define Orbital Constraints panel has multiple bugs (including many NullPointerException)
  • 681 SRM files from EPS interface contain multiple SRMs
  • 682 Cleanup code causes multiple MOC Client windows to get NullPointerException when user logs out
  • 688 Not All EPS response messages using EPSTmpDir variable
  • 689 Request auto refresh active schedule data from DAS at only a third of the NCC auto refresh rate
  • 690 The bulkSar panel needs a relative time option
  • 691 Need to be able to configure SvE for a single SAM
  • 695 Need a Schedule Request Summary message for EPS
  • 696 RS Edit superprototype panel - OPS locking up
  • 697 SAM encounters "ArrayIndexOutOfBoundsException"s
  • 699 TSW Transmit Occurs with Null Input
  • 700 After MOC Client logout/login without exiting, hourly TUT stops
  • 701 Exception when modifying RS pattern
  • 702 Panels locked by under popping Critical popup panel
  • 703 Rejected RR can't be corrected and resubmitted
  • 704 USMs periodically disappear and reappear on Graphic Timeline
  • 705 KASARIF panels store UI Channel ID I Channel wrong;
  • 706 RS Pattern editor loses panel focus
  • 708 Functionality discrepancy for MOC Controller position
  • 709 Issues with User-Defined TDRS Constraint Setup
  • 710 Deactivation of Save to Timeline Button for Graphical Timeline Replace Requests
  • 712 EPS native USM file transfer duplicated

SNAS Release 3 DRR – March 2, 2010

release 3 content bugs 3 of 3
Release 3 Content – Bugs (3 of 3)
  • 713 MOC does not get notified of SSC changes for a DAS SSC
  • 714 Specify the start time property to look for active events
  • 715 Add checkbox to reverse the background of the Alert Summary display from blank to white
  • 717 PurgeDatabase utility does not purge UPD_LOG
  • 720 Title of ActiveEventsSummary printout should not read 'Active Schedule’
  • 722 Add an OAM Delete User option
  • 725 RS pattern names longer than 15 characters cause exceptions
  • 726 Bulk Modify Uses Database Defaults for Replace Requests
  • 729 NullPointerException for Erroneous Passphrase at Login
  • 730 Objects sent to SAM after a MOC Client reconnect may be invalid due to "cleanup" code
  • 732 ClassCastException in SNIF during startup
  • 737 Incorrect msg class used for report responses generated by EPS
  • 738 ConcurrentModificationException causes SNIF to stop working
  • 739 Incorrect Active Events Summary Details Filtered Set Report
  • 741 Toggling between Relative and Absolute time on RR Panel Changes Service Stop/Duration
  • 742 SNIF doesn't set start/stop time correctly for some TSW Messages.
  • 743 ConcurrentModificationException in ActiveScheduleRequestingThread of SDIF
  • 747 MOC client freezes during Re-create USM actions
  • 749 Older SNAS application log files should be compressed
  • 751 Reports include events outside of requested time frame
  • 754 Stray lock file for Active Schedule Upload causes MOC Client to freeze
  • 757 Query Active Schedule Upload Not Working
  • 759 Service Time Format Switch When Cloning a Replace Request in Graphical Scheduling
  • 761 Replace Request transmitted with Invalid Minimum Duration
  • 767 SAM's "Force Logoff" of MOC/OAM Client doesn't always work
  • 768 Cannot add new DAS SSC--get NullPointerException
  • 769 Protocol strings from DAS SSC Panel not interpreted properly

SNAS Release 3 DRR – March 2, 2010

release 3 rtvm 1 of 4
Release 3 RTVM (1 of 4)

SNAS Release 3 DRR – March 2, 2010

release 3 rtvm 2 of 4
Release 3 RTVM (2 of 4)

SNAS Release 3 DRR – March 2, 2010

release 3 rtvm 3 of 4
Release 3 RTVM (3 of 4)

SNAS Release 3 DRR – March 2, 2010

release 3 rtvm 4 of 4
Release 3 RTVM (4 of 4)

SNAS Release 3 DRR – March 2, 2010
