2. BizTalk RFID in Real World Deployments Markus Landler
BizTalk Field Program Manager EMEA
Microsoft Corporation
3. Agenda What Can RFID Do For You?
Analyst Perspectives
Real World RFID Applications
Microsoft & RFID
Partner Ecosystem
4. What Can RFID Do For You?
5. Real-Time Visibility
6. The Benefits of Visibility
7. Analyst Perspectives
8. Recent Analyst Quote:
9. RFID Market | Market development
10. Real World RFID Deployments
11. BizTalk RFID in the Real World iGPS - 2nd Largest RFID implementation in North America, Plastic pallets contain RFID tags, Prevents losses and theft, Optimizes pallet use, Enables accurate invoicing, Eases inventory management
Blue C Sushi - Sushi restaurant in Seattle, RFID tag sushi plates, Chefs know whats on a plate, how long its been on the belt, and exactly when it is taken off, Improves inventory & quality, Chefs receive alerts to make more of certain type of sushi
Tekho Company Ltd. -The An Pin Live Fish S/T Center, working with the Southern Innovation Center of the Institute for Industry and Information in Taiwan has developed a system using Microsoft BizTalk RFID to trace the farming, transport, quality and end usage of live fish for the food service industry. This system includes development of a database for tracking information, such as water temperature, amount of feed, type of feed, water quality and farm lot location for each individual fish. When the fish are trapped live for shipment to restaurants, they are individually tagged with RFID tags which are correlated to the database information. When the fish is later selected for consumption and captured at the restaurant the tamperproof RFID tag is scanned so that the fish history is available to the consumer.
CHEP (Commonwealth Handling Equipment Pool) CHEP, the largest pallet and container leasing company in the world, has adopted BizTalk RFID in their distribution centers worldwide to more quickly and accurately track their assets. The new process not only provides customers with more accurate billing information but also enables
iGPS - 2nd Largest RFID implementation in North America, Plastic pallets contain RFID tags, Prevents losses and theft, Optimizes pallet use, Enables accurate invoicing, Eases inventory management
Blue C Sushi - Sushi restaurant in Seattle, RFID tag sushi plates, Chefs know whats on a plate, how long its been on the belt, and exactly when it is taken off, Improves inventory & quality, Chefs receive alerts to make more of certain type of sushi
Tekho Company Ltd. -The An Pin Live Fish S/T Center, working with the Southern Innovation Center of the Institute for Industry and Information in Taiwan has developed a system using Microsoft BizTalk RFID to trace the farming, transport, quality and end usage of live fish for the food service industry. This system includes development of a database for tracking information, such as water temperature, amount of feed, type of feed, water quality and farm lot location for each individual fish. When the fish are trapped live for shipment to restaurants, they are individually tagged with RFID tags which are correlated to the database information. When the fish is later selected for consumption and captured at the restaurant the tamperproof RFID tag is scanned so that the fish history is available to the consumer.
CHEP (Commonwealth Handling Equipment Pool) CHEP, the largest pallet and container leasing company in the world, has adopted BizTalk RFID in their distribution centers worldwide to more quickly and accurately track their assets. The new process not only provides customers with more accurate billing information but also enables
12. Case Study: iGPS
13. Customer Scenario: iGPS Background Problem Statement:
Reusable Transport Items (RTI) Inventory Management
Need for 100% item level visibility
Fact based usage transactions
Requirements:
Production Solution vs. Pilot
Application/Solution must provide scalability to 100s of sites and >100 million assets
14. Customer Scenario: iGPS Process Pallet Pool for Major Retailers
End-to-End Solution
15. Customer Scenario: iGPS Topology
16. iSUM Deployments
17. iGPS Pallet Pooling video http://msblogs/rfid/Shared%20Documents/Videos/iGPS_CS_300Kbps.wmvhttp://msblogs/rfid/Shared%20Documents/Videos/iGPS_CS_300Kbps.wmv
18. Case Study: Wells Fargo
20. Tracks Laptop assets as they leave facilities
Guards to identify high risk assets
Compare owner picture with person leaving the facility
Investigate exceptions
Displaced HP Built in one month what they couldnt achieve in 9 months and hundreds of thousands of $! IBM refused to participate
Laptop Tracking Application
21. Microsoft & RFID
22. MSFT & RFID Notes (hidden) Lower Total Cost of Ownership (TCO)
Make RFID Simple
Broad Plug and Play device support
Reduce time to build RFID solutions
Rich platform and tools for RFID solutions
Rapid software development kit
Reduce deployment time
Backup/restore configurations
Upgrade firmware across all devices
Leverage existing investments in systems
ERP or other systems that are already deployed
Business Intelligence Systems NEXT: BizTalk Server: Evolution of a Platform
23. BizTalk RFID goals Enable widespread adoption
Make RFID Simple
Support beyond only RFID
Reduce Total Cost of Ownership
Reduce time to build solutions
Reduce deployment time
Leverage existing investments in systems/solutions
24. BizTalk RFID's E2E Perspective
25. E2E Perspective: Microsoft Logical Overview
26. Microsoft & RFID Mobile
27. Why Mobility? 90% of code out of 1000 lines for POC was for mobile reader Jim Bowyer(PCL Construction ATU)
BizTalk RFID has taken real time visibility to edge of enterprise but stopped at the doors with fixed reader Xterprise
TCO can be drastically reduced by using Mobile RFID devices Chempoint
28. New Device Form Factors
29. What is BizTalk RFID Mobile? A lightweight platform that runs on the device
Supported on Windows CE 5.0 and Windows Mobile 5.0 platforms
Enables rapid mobile application development
Provides additional services on the device to communicate with Server
30. Mobility Scenarios: Examples The set of scenarios span across several verticals. Just two of them shown here as examples.
Will not go into details of each. Just take one example and talk about it.The set of scenarios span across several verticals. Just two of them shown here as examples.
Will not go into details of each. Just take one example and talk about it.
31. Microsoft & RFID Roadmap
32. BizTalk Server RFID Roadmap
33. Partner Ecosystem
34. MSFT & RFID Notes (hidden) Robust, Reliable Building Blocks
Diverse Ecosystem - 20+ Core H/W Partners
Connected Enterprise-Ready Solutions
Last mile Connectivity Across Applications, Verticals and Segments (Enterprise to SMB)
100+ Partners WW!
BizTalk RFID + Partners Provide a Low Barrier for Entry
Enterprise RFID Solutions in a Box
Single Platform for End-end Deployments (TCO, ROI)
Device Abstraction/Management on Windows (HUGE) NEXT: Core Partner Ecosystem
35. Core Partner Eco-System
36. Thank You!
37. Q & A
38. Appendix
39. Case Study: Blue C Sushi
40. Blue C Sushi: Profile Hip, fast growing, high-tech, restaurant chain
Established in 2003
3 Seattle area locations
~50 employees
Kaiten Style Sushi
Currently >3K Kaiten Style Sushi restaurants in Japan
Food is presented and delivered on a conveyor belt
Color and quantity of plates determines customer bill
41. Blue C Sushi: RFID Solution Project Goals
Maintain high standard of quality control
Improve business intelligence
Remain aesthetically pleasing
Solution Components
BizTalk Server 2006 R2
Kikata Ebisu Live Inventory Management Software Application
Intermec RFID Hardware
IF 5 fixed readers
RFID Antennas in Cutting Boards and Conveyor
RFID tags on every plate
Heat/moisture tolerant to handle rigors of daily restaurant activities, including hot dishwashing cycles ROI metrics call outROI metrics call out
42. Link to case study and video: http://www.microsoft.com/casestudies/casestudy.aspx?casestudyid=201405Link to case study and video: http://www.microsoft.com/casestudies/casestudy.aspx?casestudyid=201405
43. Blue C Sushi RFID Process Flow Plate is commissioned
Chef assigns menu item to each plate
Puts plate on the belt.
Belt reads (cycle of 5.5 minutes):
When plates are added
When plate is removed
And/or how long the plate is on the belt
All chefs are notified when the 1hr metric is up. The chefs pull the sushi off the belt.
Chefs notified of supply/demand productions.
Biztalk provides reporting for the manager of the store.
Plate is commissioned
Chef assigns menu item to each plate
Puts plate on the belt.
Belt reads (cycle of 5.5 minutes):
When plates are added
When plate is removed
And/or how long the plate is on the belt
All chefs are notified when the 1hr metric is up. The chefs pull the sushi off the belt.
Chefs notified of supply/demand productions.
Biztalk provides reporting for the manager of the store.
44. Case Study: Continental AG
46. Xterprise Hub and Spoke Architecture
47. Siemens-VDO Solution Benefits
48. Case Study: Tekho Fish Tracking
49. Fresh Fish Tracking Fram to Restaurant video http://www.microsoft.com/casestudies/casestudy.aspx?casestudyid=4000000640http://www.microsoft.com/casestudies/casestudy.aspx?casestudyid=4000000640
50. Case Study: Killdeer Mountain Manufacturing
51. KMMs work on this program has been fundamental in creating the RFID SCOUT program which is being driven by the Dept. of Defense to ensure that 2nd and 3rd tier suppliers are able to more effectively and efficiently provide parts to large OEMs like Boeing.
KMMs work on this program has been fundamental in creating the RFID SCOUT program which is being driven by the Dept. of Defense to ensure that 2nd and 3rd tier suppliers are able to more effectively and efficiently provide parts to large OEMs like Boeing.
52. KMM: How it Works Receive Sales order from Exostar network used by Boeing and others to deliver orders to suppliers
BizTalk received the order and transformed the order into something consumable by Great Plains(ERP used by Killdeer)
GP integration was done by e-Connect.
Once order is received a manufacturing order was created in GP and Picking list was printed. This included printed RFID label using Avery(Paxar) equipment. I am sure Jeanne helped a lot on this front.
After this the Picking list along with RFID tag travelled through he whole manufacturing processes. At various points we had Alien portals to read the tags and track all the points where processing was happening.
All this information was shared through Share Point portal.
At the end final shipment was tracked and information was updated in Share Point Portal.
Currently the information is internal to Killdeer but next phase will allow Boeing to receive this information and integrated into their Sharepoint portal to track information from all the suppliers.
Value of BizTalk:
The glue binding all of these systems together is Microsoft BizTalk Server 2006 R2. KMM and RFID SCOUT rely on BizTalk RFID Infrastructure to gather, filter, and clean RFID data from edge devices, such as handheld readers. In addition, KMM uses BizTalk Server for Business Activity Monitoring (BAM) alerts. BizTalk enables the overall system to provide more accurate and timely predictive analytics, triggers, and business alerts, all of which are generated from BizTalk Server.
The alerts are especially important in a just-in-time environment. The BizTalk Server 2006 R2 RFID Infrastructure, together with BAM alerts, notifies KMM if the company reaches an out-of-limit or out-of-sync condition on the shop floor, allowing appropriate actions to be taken immediately.
BizTalk Server will also be used to generate an RFID shipping compliance alert to Boeing, through an EDI 856 ASN notification. Using the BizTalk native RFID Infrastructure, management tools, and application services for device/tag interaction, Microsoft Dynamics GP users effectively have a large-enterprise RFID solution in a box.
HARDWARE
One of the goals of the RFID SCOUT project is to develop a solution that is not vendor specific. Microsoft Biztalk R2 RFID Infrastructure was chosen with this vendor neutrality in mind so SMEs who use the RFID SCOUT toolkit will not be constrained to the vendors who developed the toolkit.
For this phase of the project, the following hardware is currently being deployed. All hardware used for the RFID SCOUT project will be required to be compatible with the Microsoft Biztalk R2 RFID Infrastructure.
Label Printers
Handheld bar code / RFID reader
RFID Readers & Antennas
Wireless Mobile RFID Carts
RFID Smart Labels
LABEL PRINTERS
The Monarch M09855RFMPE label printer manufactured by Paxar will be used for printing labels. The Monarch M09855RFMPE can be used to not only print standard bar code labels; it can also be used to encode RFID smart labels. Theses RFID smart labels will be a critical component in using RFID to further automate KMMs processes.
Because not all labels produced will require the extra cost of a RFID tag, each location that will be instrumented to produce RFID smart labels will also have a label printer that is not loaded with RFID smart labels. The system being developed will automatically feed the label to be printed to the correct label printer. In this manner there is no need for the operator to select the correct printer or swap out the more expensive RFID labels for standard bar-code labels.
Paxars innovative Monarch M09855RFMPE printer/encoder offers the latest in GEN 2, multi-protocol encoding capabilities.
Handheld Bar Code/RFID Reader
Three Symbol MC9090 RFID enabled handheld terminals supplied by Maximum Data provide mobile computing for the implementation. The RFID Readers will allow users to read RFID smart tags using a mobile handheld device. The devices will offer an integrated antenna with good drop-to-concrete characteristics, both integrated bar code and RFID capabilities, wireless local area networking (LAN) and sound ergonomics. The MC9090 Multi-protocol readers can read EPC Gen 1 and Gen 2 RFID tags. The MC9090 Readers with dense-reader mode (DRM) allow a large number of readers to concurrently communicate without interfering with each others signals.
RFID Readers & Antennas
The Alien Technology ALR-9800 multi-protocol Gen2 RFID readers will be used in this phase for work in process tracking as well as for taking inventory of RFID labeled inventory items.
The ALR-9800 is a new-generation reader ideal for efficient implementation of RFID on a small or large scale with high level performance, lower initial and ongoing costs, and accelerated return-on-investment (ROI).
Wireless Mobile RFID Carts
Paxar developed mobile wireless carts will be outfitted with RFID readers to showcase the benefits of mobile RFID in situations such as KMMs regularly changing manufacturing layout as well as the benefits of a mobile inventory station.
Receive Sales order from Exostar network used by Boeing and others to deliver orders to suppliers
BizTalk received the order and transformed the order into something consumable by Great Plains(ERP used by Killdeer)
GP integration was done by e-Connect.
Once order is received a manufacturing order was created in GP and Picking list was printed. This included printed RFID label using Avery(Paxar) equipment. I am sure Jeanne helped a lot on this front.
After this the Picking list along with RFID tag travelled through he whole manufacturing processes. At various points we had Alien portals to read the tags and track all the points where processing was happening.
All this information was shared through Share Point portal.
At the end final shipment was tracked and information was updated in Share Point Portal.
Currently the information is internal to Killdeer but next phase will allow Boeing to receive this information and integrated into their Sharepoint portal to track information from all the suppliers.
Value of BizTalk:
The glue binding all of these systems together is Microsoft BizTalk Server 2006 R2. KMM and RFID SCOUT rely on BizTalk RFID Infrastructure to gather, filter, and clean RFID data from edge devices, such as handheld readers. In addition, KMM uses BizTalk Server for Business Activity Monitoring (BAM) alerts. BizTalk enables the overall system to provide more accurate and timely predictive analytics, triggers, and business alerts, all of which are generated from BizTalk Server.
The alerts are especially important in a just-in-time environment. The BizTalk Server 2006 R2 RFID Infrastructure, together with BAM alerts, notifies KMM if the company reaches an out-of-limit or out-of-sync condition on the shop floor, allowing appropriate actions to be taken immediately.
BizTalk Server will also be used to generate an RFID shipping compliance alert to Boeing, through an EDI 856 ASN notification. Using the BizTalk native RFID Infrastructure, management tools, and application services for device/tag interaction, Microsoft Dynamics GP users effectively have a large-enterprise RFID solution in a box.
HARDWARE
One of the goals of the RFID SCOUT project is to develop a solution that is not vendor specific. Microsoft Biztalk R2 RFID Infrastructure was chosen with this vendor neutrality in mind so SMEs who use the RFID SCOUT toolkit will not be constrained to the vendors who developed the toolkit.
For this phase of the project, the following hardware is currently being deployed. All hardware used for the RFID SCOUT project will be required to be compatible with the Microsoft Biztalk R2 RFID Infrastructure.
Label Printers
Handheld bar code / RFID reader
RFID Readers & Antennas
Wireless Mobile RFID Carts
RFID Smart Labels
LABEL PRINTERS
The Monarch M09855RFMPE label printer manufactured by Paxar will be used for printing labels. The Monarch M09855RFMPE can be used to not only print standard bar code labels; it can also be used to encode RFID smart labels. Theses RFID smart labels will be a critical component in using RFID to further automate KMMs processes.
Because not all labels produced will require the extra cost of a RFID tag, each location that will be instrumented to produce RFID smart labels will also have a label printer that is not loaded with RFID smart labels. The system being developed will automatically feed the label to be printed to the correct label printer. In this manner there is no need for the operator to select the correct printer or swap out the more expensive RFID labels for standard bar-code labels.
Paxars innovative Monarch M09855RFMPE printer/encoder offers the latest in GEN 2, multi-protocol encoding capabilities.
Handheld Bar Code/RFID Reader
Three Symbol MC9090 RFID enabled handheld terminals supplied by Maximum Data provide mobile computing for the implementation. The RFID Readers will allow users to read RFID smart tags using a mobile handheld device. The devices will offer an integrated antenna with good drop-to-concrete characteristics, both integrated bar code and RFID capabilities, wireless local area networking (LAN) and sound ergonomics. The MC9090 Multi-protocol readers can read EPC Gen 1 and Gen 2 RFID tags. The MC9090 Readers with dense-reader mode (DRM) allow a large number of readers to concurrently communicate without interfering with each others signals.
RFID Readers & Antennas
The Alien Technology ALR-9800 multi-protocol Gen2 RFID readers will be used in this phase for work in process tracking as well as for taking inventory of RFID labeled inventory items.
The ALR-9800 is a new-generation reader ideal for efficient implementation of RFID on a small or large scale with high level performance, lower initial and ongoing costs, and accelerated return-on-investment (ROI).
Wireless Mobile RFID Carts
Paxar developed mobile wireless carts will be outfitted with RFID readers to showcase the benefits of mobile RFID in situations such as KMMs regularly changing manufacturing layout as well as the benefits of a mobile inventory station.
54. Partner Solutions on BizTalk RFID
55. Driving Enterprise-wide Supply Chain Visibility BizTalk/SAP RFID Connector
