preprocessing support for large scale process mining of sap transactions

Preprocessing support for large scale process mining of SAP transactions

Jon Espen Ingvaldsen

Jon Atle Gulla

overview
Overview
  • Motivation
  • Process mining SAP data
  • EVS ModelBuilder
    • Preprocessing steps
    • Algorithm for constructing process instances
    • Mapping to MXML
  • Discussion & Experiences
process mining project

Interprete

Business

Understanding

Explore

Models

Extract

Process Instances

Information

Systems

Process mining project
process mining sap data
Process mining SAP data
  • Documents that refer to each other
    • Example:
  • Manual document operations are done by use of transactions
    • ME21 – Create Purchase Order
    • VA02 – Change Sales Order
  • All document operations are logged with user reference and timestamp

PR

PO

OC

process mining sap data5
Process mining SAP data
  • n to n mapping between business processes transaction codes
  • n to n mapping between transaction codes and tasks
  • Large amounts of data
  • Multiple of database tables involved
evs modelbuilder
EVS ModelBuilder
  • Developed as a set of plugins to Eclipse
  • Tested and applied at Nidar AS to investigate their purchase agreement processes
preprocessing process
Preprocessing process
  • Define a process mining project
  • Define access properties for involved database sources
  • Define event types
  • Define business object types
  • Define relationships between event types and business object types
how do we define event types
How do we define event types?
  • Type name
  • Key attributes
    • Ensure unique identification
  • Timestamp attribute and format
    • Tells when the event occurred and how to parse the timestamp values
  • Relationships to BO types
    • Tells which BOs that were involved in the event
  • Discriminators
example of an event description
Example of an event description
  • Type name:
    • ALTER PURCHASE ORDER
  • Key attributes:
    • CDHDR.CHANGENR
  • Timestamp attributes:
    • CDHDR.UDATE (ddMMyyyy) and CDHDR.TIME (hhmmss)
  • Discriminators:
    • CDHDR.OBJECTCLAS = ”EINKBELEG”
examples of constructed events
Examples of constructed events

Type: ALTER PURCHASE ORDER

Key: CDHDR.CHANGENR = 00021

Timestamp: 1. June 2007, 14:01:23

Type: ALTER PURCHASE ORDER

Key: CDHDR.CHANGENR = 00024

Timestamp: 4. June 2007, 11:52:04

how do we define business object types
How do we define Business Object types?
  • Type name
  • Key attributes
    • Ensure unique identification
  • Value attribute
    • Provides a textual description of the BO
  • Analysis features
    • Information that describe the BO
  • Relationships to other BO types
  • Discriminators
examples of business object descriptions
Examples of Business Object descriptions
  • Type name: USER
  • Key attributes: USR01.BNAME
  • Value attribute: USR01.NAME1
  • Analysis features: (NONE)
  • Discriminators: (NONE)
examples of constructed business objects
Examples of constructed business objects

Type: USER

Key: USR01.BNAME = JACKSON

Value: Michael Jackson

Type: USER

Key: USR01.BNAME = SIMPS

Value: Homer Simpson

how do we define relations
How do we define relations?
  • Relations consist of:
    • Two end points
    • Textual description
    • Mapping attributes / path
example of a relation
Example of a relation

Type: USER

Key: USR01.BNAME = JACKSON

Value: Michael Jackson

Relation name:

Has user / Executes

Mapping attributes:

CDHDR.USERNAME = USR01.BNAME

Type: ALTER PURCHASE ORDER

Key: CDHDR.CHANGENR = 00021

Timestamp: 1. June 2007, 14:01:23

example of an event and its relations
Example of an event and its relations

Type: DEPARTMENT

Key: USR01.ABTLG = Los Angeles

Value: Los Angeles

Type: USER

Key: USR01.BNAME = JACKSON

Value: Michael Jackson

Type: PURCHASE REQUISITION

Key: EBAN.BANFN = 007866

Value: 007866

Type: ALTER PURCHASE ORDER

Key: CDHDR.CHANGENR = 00021

Timestamp: 1. June 2007, 14:01:23

Type: TRANSACTION

Key: TSTC.TCODE = ME21N

Value: Create Purchase Order

Type: PURCHASE ORDER

Key: EKKO.EBELN = 002121004

Value: 002121004

construction of process instances

14. June

17. June

2. June

21. June

22. June

Construction of process instances
slide19
MXML
  • The input format for ProM
  • Requirements for events (AuditTrailEntries) in MXML:
    • Reference to an activity
    • Reference to a process instance
    • Reference to a performer
    • Labeled with a timestamp
    • Ordered on timestamp within the process instance
mapping to mxml
Mapping to MXML

To construct AuditTrailEntries inMXML we need to:

Type: USER

Key: USR01.BNAME = JACKSON

Value: Michael Jackson

Selects the BO type that represents

the orginators

Selects the BO type that represents

the workflow element

Type: ALTER PURCHASE ORDER

Key: CDHDR.CHANGENR = 00021

Timestamp: 1. June 2007, 14:01:23

Make use of the event timestamp

Type: TRANSACTION

Key: TSTC.TCODE = ME21N

Value: Create Purchase Order

discussion experiences
Discussion & Experiences
  • Still a effort is required!
  • Preprocessing support have most value:
    • When mining longer process chains
    • A lot of database tables are involved
  • Stores data source descriptions, not the process of transforming the data
    • Ensures reusability across process mining projects.
  • Enable process mining of processes that spans multiple information systems
