1. Otosclerosis Steven Powell
SpR ENT
2. Outline Viva
Questions
Definitions
Anatomy and Physiology
Pathology
Aetiology
Clinical Features
Diagnosis
Treatment Options
3. Take Homes Exam!
Cahart effect/ notch
Multisided surgery
Glasgow benefit plot
7. Paradoxes and questions Is otosclerotic bone sclerotic?
Is a reparative granuloma a granuloma?
Why aren’t people as grateful when you do the second side?
How can the bone conduction be better than the air conduction in these patients?
8. Explain this
9. Definitions A localised hereditary disorder affecting endochondral bone of the otic capsule which is characterised by disordered resorption and deposition of bone.
10. Embryology Ectoderm forms otic pit and otocyst
With neural crest cells forms membranous labyrinth
Mesenchyme enclosing otocyst becomes chondrified to form otic capusle
Ossification begins 16 weeks
Dense bone- petrous
Channels remain- oval window (footplate and annular ligament)
11. Anatomy
12. Anatomy
13. Anatomy Stapes
Anterior crura, posterior crura, footplate
Anterior crus thinner
Stapedius inserts posteriorly into neck and posterior crus
Footplate convex superiorly, straight inferiorly
3mm long, 1.4 mm wide
Attached to bony margins by annular ligament
14. Physiology Middle ear is impedance matching system
Higher impedance of fluid
Size differential
Lever action
Couples sound preferentially to one window of cochlea
15. Bone Conduction- Cahart Effect
16. Pathology Normally very little remodelling of bone
Bone remodelling (blasts and clasts)
Active (spongiotic) areas
Inactive (sclerotic) areas
Commonest sites
Anterior to oval window 80-90%
Round window niche 30%
17. Histology
18. Pathology Clinical otosclerosis
Histological otosclerosis
Cochlear otosclerosis
19. Pathophysiology CHL Original thinking progressive air bone gap
Bony ankylosis>otosclerosis>fibrous
Now appears to be associated with stapedovestibular joint space
Mucosa fibroproliferative
Schwarte’s sign
20. Pathophysiology SNHL Otosclerosis in cochlear endosteum
Action on spiral ligament
Cytokine mediated
Rare without cochlear otosclerosis
21. Pathophysiology SNHL
22. Epidemiology British Study of Hearing
2% M=F, but at CHL >30dB 3F:1M
10% prevalence in temporal bones, but ? selection
23. Aetiology Genetics
Autosomal dominant, incomplete penetrance
Sporadic
COL1A1 gene defects
Measles
Autoimmune
Biochemical factors
Pregnancy
24. Clinical Features Decreased hearing
Tinnitus (50-70%)
May be no clinical signs
Schwartze’s rare
Normal TM
Abnormal TM
25. Schwartze’s Sign
26. Investigations Pure tone audiogram
Conductive hearing loss
Mixed hearing loss
Tympanometry
CT
MRI
27. Conductive Hearing Loss
28. Mixed Hearing Loss
29. CT
30. Differential Diagnosis Congenital ossicular abnormalities
Ossicular fixation
Ossicular errosion
Ossicular dislocation
Tympanosclerosis
Osteogenesis imperfecta type 1!
31. Management Options Watch- natural history
Conventional hearing aids
BAHA
Cochlear implant
Stapes surgery
Fluorides
32. Hearing Aids 4 scenarios
Primary treatment CHL
Mixed hearing loss
Combination after surgery to reduce CHL to serviceable level
Rescue treatment
BAHA
Cochlear implant (not a hearing aid)
33. History of Surgery 1876 Kessel- removed footplate
1888 Boucheron- rocked footplate
Fell into disrepute
1938 Lempert- Fenestration
1952 Rosen- Mobilisation
1956 Shea- stapedectomy and prosthesis
34. Surgery Used to be threshold of 20dB gap for operating, but now CHL of 10dB may be operated on
Contraindictions
Pregnancy
Active infection
35. Surgery Anaesthesia general v local
Per-meatal or endaural
Tympanomeatal flap
Curette bone
Assess ossicular chain
Measure distance
36. Surgical Techniques- stapedotomy
37. Stapedotomy Techniques Drill
Lasers
Tissue to seal- vein
Type of piston
Size of piston
38. Surgical Techniques- Stapedectomy
39. CT
40. Surgical Problems Floating footplate
Obliterated footplate
CSF gusher
Facial nerve dehiscence/ prolapse
41. Post-Operative Complications Conductive Hearing Loss
Displacement of Prosthesis
Necrosis LPI
Bony regrowth
42. Postoperative Complications Sensorineural hearing loss- rates vary depending on paper 1-10%
Extensive drilling
Floating footplates
Perilymph leak
Delayed SNHL
43. Post- Operative Complications Facial nerve injury
Vertigo
Perilymph fistula
Reparative granuloma
Discomfort to noise
Taste changes
Cholesteatoma
Meningitis
44. Stapedectomy v stapedotomy Stapedectomy
Better low frequency hearing gain
Stapedotomy
Better HF gain
Lower incidence: perilymph fistula, SNH impairment, post-op vertigo, revision surgery
45. Surgical Issues Unilateral
Second side surgery
46. Glasgow Benefit Plot
47. Belfast Rule of Thumb Operated ear brought to 30dB or better or within 15dB of contralateral ear
48. Revision Surgery 92% for CHL
2% dizziness/ SNHL/ fistula
More problems
Adhesions
Ossicular problems
Higher risk SNHL
49. Paradoxes and questions Is otosclerotic bone sclerotic?
Is a reparative granuloma a granuloma?
Why aren’t people as grateful when you do the second side?
How can the bone conduction be better than the air conduction in these patients?
50. Questions Otosclerosis is only partially sclerotic. A larger part may be spongiotic
A reparative granuloma is a misnomer and is granulation tissue
“Over correction” of the air bone gap is explained by the Cahart effect
Second side surgery often doesn’t improve overall hearing level as demonstrated by Glasgow Benefit Plot
51. Summary Otosclerosis is a disorder of bone resorption and deposition in the otic capsule bone/ petrous temporal bone
Its commonest manifestation is conductive hearing loss +/- sensorineural loss
Treatment options of aiding versus surgery should be weighed up in context of the audiometry, contralateral ear and patient preference.
