Honeypots and Honeynets A New Response to Cybercrime Analysis NAAG Seattle 04

1. Honeypots and Honeynets A New Responseto CybercrimeAnalysisNAAG Seattle 04/14/03 �Know Your Enemy� is the purpose of the Honeynet Project. The book you see listed above was written by the Project based on their two years of research . You can find out more about the book online at http://www.honeynet.org/book/�Know Your Enemy� is the purpose of the Honeynet Project. The book you see listed above was written by the Project based on their two years of research . You can find out more about the book online at http://www.honeynet.org/book/

2. Agenda The Honeynet Project The Enemy Honeypot Basics Honeypots In Use Legal Implications

3. Honeynet Project Goals Awareness: To raise awareness of the different types of honeypots that exist Information: To teach and inform about the application of honeypots Research: To spur thought provoking discussion and help drive innovation and research in this emerging space

4. The Threat is Real The blackhat community is extremely active 20+ unique scans a day (20/hour on UW network) Fastest time honeypot manually compromised, 15 minutes: worm, 92 seconds Default RH 6.2 life expectancy is 72 hours (fresh Windows 2000 install on UW network: 2 hours) 100% - 900% increase of activity from 2000 to 2001 Its only getting worse http://www.honeynet.org/papers/stats/ Keep in mind this statistical information was gathered during 2000-2001. We fully believe that the threats on the Internet are exponentially more active due to the release of highly automated tools, such as worms and auto-rooters.Keep in mind this statistical information was gathered during 2000-2001. We fully believe that the threats on the Internet are exponentially more active due to the release of highly automated tools, such as worms and auto-rooters.

5. Know Your Enemy

6. Rising Attack Sophistication Black hats have the initiative; attack whatever they want, whenever they want Public knows very little about the black hats (Who are they? How do they attack? Why?) Arms races, and the bad guys are always ahead

7. Methodology One of the most common tactics seen is attacking targets of opportunity �Drive by shootings on the information superhighway� Scanning as many systems as possible and going for the easy kill If only 1% of systems are vulnerable, and you scan over 1 million hosts, you can potentially hack into 10,000 systems

8. What are they looking for? Keep in mind this statistical information was gathered during 2000-2001. We fully believe that the threats on the Internet are exponentially more active due to the release of highly automated tools, such as worms and auto-rooters.Keep in mind this statistical information was gathered during 2000-2001. We fully believe that the threats on the Internet are exponentially more active due to the release of highly automated tools, such as worms and auto-rooters.

9. Evolution Firewalls Early 90�s Must have � deployed before anything else Intrusion Detection System (IDS) Mid to late 90�s We can�t guard everything, so let�s watch the network for suspicious traffic Honeypots Early 2000 Not only do we want to know when the black hats are attacking, but also answer the question, Why? Let�s learn rather than just react

10. Concept of Honeypots A security resource who�s value lies in being probed, attacked or compromised Has no production value; anything going to/from a honeypot is likely a probe, attack or compromise Used for monitoring, detecting and analyzing attacks

11. The Role Of Honeypots In The Enterprise Augments Firewalls and IDS Research Incident Response / Forensics Deception / Deterrence

12. Advantages Fidelity � Information of high value Reduced false positives Reduced false negatives Simple concept Not resource intensive Return on Investment

13. Disadvantages Labor/skill intensive Risk Limited field of view Does not protect vulnerable systems

14. Today's honeypots Military, government organizations, security companies applying the technologies Primarily to identify threats and learn more about them Commercial application increasing everyday

15. Utility � Identifying new exploits

16. Future Honeypots are now where firewalls were eight years ago Beginning of the �hype curve� Predict you will see five more commercial honeypots by the end of 2003 Enhanced policy enforcement capabilities Advance development in Open Source solutions Integrated firewall/IDS/honeypot appliances

17. Gen IIHoneynet

18. Virtual Honeynet

19. Live Demo

20. Top 10 attacked ports

21. Attacks logged

22. IRC traffic plugin output

23. Legal Issues Entrapment Liability Privacy

24. Entrapment Applies only to law enforcement Useful only as defense in criminal prosecution Still, most legal authorities consider honeypots non-entrapment

25. Liability Any organization may be liable if their honeypot is used to attack or damage third parties. Civil issue, not criminal Example: T.J. Hooper v. Northern Barge Corp. (No weather radios) Decided at state level, not federal This is why the Honeynet Project focuses so much attention on Data Control.

26. Privacy No single federal statute (USA) concerning privacy Electronic Communications Privacy Act (amends Title III of the Omnibus Crime Control and Safe Streets Act of 1968) Title I: Wiretap Act (18 USC 2510-22) Title II: Stored Communications Act (18 USC 2701-11) Title III: Pen/Trap Act (18 USC � 3121-27)

27. Questions? Emaildittrich@u.washington.edu Slides available at:http://staff.washington.edu/dittrich/talks/NAAG.ppt
