  1. StreamInsight02 – Querying Events in SQL Server 2008 R2 StreamInsight SQL10R2UPD05-DECK-02 [Presenter Name][Presenter Title] [Company Name]

  2. Module Overview • Introducing StreamInsight • Querying Events in StreamInsight • Designing StreamInsight Event Models and Adapters • Installing, Deploying, and Maintaining the StreamInsight Runtime Engine

  3. Agenda • Querying StreamInsight Using LINQ • Demo: Querying StreamInsight Using LINQ • Using Advanced Query Options • Demo: Using Advanced Query Options • Lab: Querying StreamInsight with LINQ

  4. Query Elements • Projection • Filtering • Joins • Unions • Aggregations • Event Windows • Hopping Window, Tumbling Window • Snapshot Window

  5. LINQ-Based Queries • Read from an input stream • Outgoing events sent to an output stream

  6. Query Element: Projection • Selects required fields from a stream for new stream • May create a new type or refer to an existing type • Cannot use constructor (must use field assignment) • May apply calculations to the data

  7. Query Element: Filtering • Restrict events included in resulting event stream • Propagates event if where clause evaluates to true

  8. Query Element: Joins • Correlates values from different streams • Supports inner joins, equijoins, cross joins • Checks overlapping time intervals • Checks join conditions

  9. Query Element: Unions • Combines events from two streams into a single stream • Can be cascaded to union more than two streams

  10. Query Element: Aggregations • Supported aggregations • Avg • Sum • Count • Min • Max • User-defined • Computed over events within a window (interval) • Can only be applied to windows

  11. Query Element: Event Windows • Allows computation against events within an interval • The following operations are permitted on windows: • Aggregation • TopK • User-defined operations • Windows are time-based or count-based • Do not change the underlying events • Can have input and output policies

  12. Query Element: Hopping Window • Hop forward in time by a fixed period • Defined by window size and hop size • Operators apply to events within the window

  13. Variation: Tumbling Window • Simplified form of hopping window • Interval and hop size identical

  14. Query Element: Snapshot Window • Defined by start/end times of events in the stream • No fixed grid along the timeline • No parameters in the window definition • Only output policy is required

  15. Count Windows • Based on count of events rather than time • One form of count window available at RTM • Others likely in the future • Currently only support user-defined aggregates

  16. Querying StreamInsight Using LINQ SQL10R2UPD05-DEMO-02 Demo

  17. Agenda • Querying StreamInsight Using LINQ • Demo: Querying StreamInsight Using LINQ • Using Advanced Query Options • Demo: Using Advanced Query Options • Lab: Querying StreamInsight with LINQ

  18. Advanced Query Elements • TopK • Group • Timestamp Modification

  19. Query Element: TopK • Ranks events in a stream • Limits events to specified number

  20. Project Rank Back into Stream • May want ranking to be part of stream • Lambda expression used • “Rank” and “Payload” properties

  21. Query Element: Group • Partitions events into event groups • Uses LINQ “group by” operator • Aggregates can be performed on groups • Access to grouping key possible but at RTM requires explicit typing

  22. Grouping on Several Keys • Each unique key combination produces a separate group

  23. ApplyWithUnion • Aggregate is computed on the stream then joined back to the stream

  24. Extending StreamInsight Events • Built-in operators flexible but will not cover all requirements • You might want to reuse existing .NET libraries • StreamInsight platform is extensible through • User-defined operators • User-defined functions • User-defined aggregates • .NET code deployed as assemblies • Temporal snapshot operator framework allows user-defined operators

  25. User-Defined Functions • Allow reuse of existing libraries

  26. User-Defined Aggregates

  27. Exposing UDAGG to LINQ

  28. Using Advanced Query Options SQL10R2UPD05-DEMO-03 Demo

  29. Resources • StreamInsight Website • http://www.microsoft.com/sqlserver/2008/en/us/R2-complex-event.aspx • StreamInsight Books Online • http://msdn.microsoft.com/en-us/library/ee362541(SQL.105).aspx • StreamInsight Forums • http://social.msdn.microsoft.com/Forums/en-US/streaminsight/threads • StreamInsight Whitepaper • http://download.microsoft.com/download/F/D/5/FD5E855C-D895-45A8-9F3E-10AFADBE51A/Microsoft%20CEP%20Overview.docx
