  1. Enabling Interoperability for the Utility Enterprise And TESTING

  2. Components for Substation Automation Systems with IEC 61850 Communication

  3. Testing Tools for IEC 61850 GOOSE, Sampled Values, and Client/Server Communication

  4. Testing Group Certification of Interoperability and Conformance Testing for the Smart Grid

  5. Karlheinz Schwarz

  6. IEC 61850, IEC 61400-25, IEC 62351, … • GLOBAL Standards for Systems • Monitoring, Protection, Automation, Control, Supervision, …, Engineering, Configuration, Security, Gateways to RTU Protocols • Information Models • Generation (Wind, PV, Hydro, …), AC/DC Transmission, Distribution, Protection, Asset Monitoring, Storage, …, SmartGrids (UML) • Configuration Language • System Configuration Language (SCL) for Systems and Devices (XML) • Communication • Communication Services for real-time and SCADA (GOOSE, SV, MMS, DNP3, IEC 60870-5-104, TCP/IP, UDP, …, native Ethernet)

  7. We Offer: • Stack and API Integration • Embedded Controller • Software Support • Gateways (DNP3, Modbus, 104, …) • Consulting • Training http://iec61850.com http://blog.iec61850.com 3,200+ Experts from 800+ Companies from 80+ Countries trained in 175+ Courses by 2013-01

  8. IEC 61970 for Transmission IEC 61968 for Distribution IEC 62325 for Markets Connecting the Utility World Through a Common Data Model

  9. Model-Driven Integration Using CIM • Increase Flexibility & Manage Complexity using CIM • Training Programs to Build Staff Knowledge • Use Case & Model Development • Systems & Application Integration Services • Off-the-Shelf CIM Adapters & Products BOOTH #1846

  10. ICCP-TASE.2 for Control Centers & Power Plants • Robust Field-Proven Technology with Thousands of Operational Installations • Development Tools for SCADA/EMS/DMS • Source Code for Embedded Systems • Off-the-Shelf ICCP-TASE.2 Interfaces BOOTH #1846

  11. IEC 61850 For Power System Automation & Control • Wide Area Protection using GOOSE for Remedial Action Systems (C-RAS) • Portable Source Code for Embedded Systems • Off-the-Shelf IEC 61850 Interfaces • Interoperability Assured With 100K’s of Devices Operational Using SISCO Technology BOOTH #1846

  12. Visit SISCO in Booth #1846 WWW.SISCONET.COM CIM Consultationand Integration Services and Products ICCP-TASE.2 Products and Services IEC 61850 Solutionsand Products

  13. Improving Power System Automation Using the IEC 61850 Standard

  14. Leading Expertise in IEC 61850 Consulting Training Realization Specification IT solutions for the power industry www.it4power.com

  15. Customized IEC 61850 Trainings

  16. A User Community for Secure Smart Grid Systems

  17. ‘ Our products are at their ’ ’ ‘ ‘ best when the environment around them is at its worst. ’ RuggedCom designs and manufactures rugged communications networks for mission critical applications in harsh environments. WAN LAN RuggedCom designs and manufactures rugged communications networks for mission critical applications in harsh environments.

  18. Utility Grade Applications

  19. An Open File Format for Energy Consumer Information Exchange

  20. Visit us in Booth #1318 Source Code Library Quickly add IEC 61850 support to your device Available in: ANSI Standard C, C++, .NET Platform and Operating System Independent Small footprint – ideal for embedded devices Ed. 2 Support Now Shipping!

  21. Visit us in Booth #1318 61850 Test Suite • Windows Application • Supports IEC 61850 & 60870-6 • Simulate Client and/or Server • Manage SCL Files • NEW! Insight functionality adds: • Custom graphical displays • Scripted simulation via flowchart
