SEND IT TO THE MOON

David Heck

Advanced Manufacturing Research & Development

Boeing – Phantom Works, St. Louis, Mo

slide3

Space Shuttle Return to Flight

  • July 2005 Discover
    • Returned with 13 tons of ISS trash
      • 26,000 pounds total
      • old equipment, packaging, wiring
      • waste water, human waste, etc
slide4

Returned with 13 tons of ISS trash (2 years worth)

    • 26,000 pounds total
    • old equipment, packaging, wiring
    • waste water, human waste, etc
    • Paid lots of $$ to get it to orbit
    • Paying more to bring it home
slide8

Shower Head

Vacuum Hose

slide9

Vacuum Hose

Sit here

Footrest

slide12

3558 g/CM-d TOTAL

  • 1918 g Human Waste = 54%
  • 423 g bio-degradable
  • Total degradable = 66%

(5)

589

(5)

231

In-Situ Resource Utilization (ISRU)

slide13

26,000 pounds total of trash

    • old equipment, packaging, wiring
    • waste water, human waste, etc
    • Based on typical ISS output,
      • 54% human waste
      • 66% bio-related
    • Actual composition:
      • 14,410 lbs. human waste
      • 1,600 lbs. other bio-degradable
slide14

Why is this important ?

  • Launch costs are prohibitive
  • Delta IV Medium –
    • $130 million puts 25,000 pounds in LEO
    • about $5000 per pound to LEO
    • Can land 4400 pounds on Lunar surface
    • $30,000 per pound to Lunar surface
slide16

Why In-Situ ?

  • 6 ounce can of Wasabi Peas -
  • 12 bottle of ketchup -
  • Not having to ship EVERYTHING
  • up from the Earth -

$11,250

$22,500

PRICELESS

slide17

Living off the land

In-Situ Resource Utilization (ISRU)

slide19

Lunar Landings, circa 1970

  • 6 Apollo
  • 3 Luna
  • 840 lbs.
  • Wash U. regional node for analysis

11

slide20

4.5 %

Titanium

6 %

5.5 %

40 %

14 %

19 %

slide21

40% oxygen – rocket oxidizer, O2

  • 19 % silicon – glass & ceramics
  • 14% iron - iron & steel products – construction
  • 6% Titanium - high temperature & spacecraft
  • 5.5% Aluminum – light weight spacecraft parts
  • 4.5%Magnesium – light weight parts, alloy element
  • Others: Chrome, Manganese, Sulphur, Potassium, Carbon (00.014%)
    • 850 pounds from 6 sites. What else could we find ?
slide24

Lunar Industry

  • Mining
    • Robotic Sweeper – 2 foot wide, 1 inch regolith depth
    • Moving at 1 mile per hour
    • (5280 ft per hour = 1.5 ft per sec)
    • Gathers 880 ft3 PER HOUR
    • = 10 ft x 10 ft x 8.8 feet high
    • @13% Iron, 25% utilization yields 28 ft3 of IRON
    • = 42 - 4 ft X 4 ft X 1 inch sheets PER HOUR !

ADD Carbon = STEEL

slide25

Lunar Industry

  • Ground transport
    • lunar bus, carts, miners, rovers
    • Maglev trains & tracks
    • Mass driver launchers
  • Structures
    • blast deflectors, reflectors, antennas, sun shades
    • tanks, towers, rails/tracks
    • habitats, work areas
    • power transmission
  • Systems
    • Gas & fluid processing equipment & machines
    • Waste processing & recycling
    • Power generation & transmission
slide26

Spherical Tanks

“Stick” Reflectors

slide28

How do we get it there ?

  • Three main steps
    • Push into Trans-Lunar Injection trajectory
    • Brake into Lunar orbit (LOI)
    • De-orbit & land on the Moon
    • Requires lots of Fuel
slide29

How do we get it there ?

  • Easy Way -
    • Upper Stage Chemical Rocket booster
    • Traditional rocket powered Lander
    • Lots of mass to push to Moon
    • Requires lots of Fuel
    • How Much ??
slide30

Lessons from Apollo*

  • Data from NASA Apollo 11 Press Kit
  • Shows spacecraft weight delivered to LEO
    • (Low Earth Orbit)
  • Shows weights for each portion of Apollo 11
    • Command & Service Module
    • L.E.M. (Descent and Ascent stages)
    • Various sub-systems (water, ECS package, etc.)
  • Propellant weights for each stage, engine specs
  • Allows calculation of “Parametric” values
slide34

Lessons from Apollo*

Trans Lunar Injection Summary

  • For every 10,000 lbs in LEO, Apollo puts 3300 lbs in TLI
  • Requires LOX/LH2 J-2 class engines
  • Payload Ratio is .33
  • Delta II (7925H-10L) can place 10,120 lbs in LEO
    • Current MB-60 engine is higher performance than J-2
    • Isp = 467 versus Isp = 420 for J-2
    • Required propellant = 10,120*.666*(420/467) = 6019 lbs
    • Payload to LLO = 10,120-6019 = 4101 lbs (extra 761#)
  • Delta IV (5,4) can place 25,300 lbs in LEO
    • Propellant = 15,048 lbs
    • Payload to TLI = 10,252 lbs
    • Payload Ratio is .33
slide35

Lessons from Apollo*

  • Lunar Orbit Insertion
  • Apollo Summary
    • Command Service Module/LEM weight at TLI = 100,369
    • LOI Propellant used = 12,011 lbs MMH/NTO
    • Apollo Isp = 318 versus Isp = 338 for RS-72
    • Fuel fraction = .112 ……. Payload fraction = .887
  • Delta II (TLI = 4101 lbs) payload to LLO = 3,639 lbs
  • Delta IV (5,4)(TLI = 10,252) payload to LLO = 9,099 lbs
  • Payload Ratio is . 887
slide36

Lessons from Apollo*

  • Lunar LANDING
  • Apollo Summary
    • LEM weight 33,205 (Apollo 11)
    • Descent Propellant used = 18,100 lbs MMH/NTO
    • Payload to Lunar Surface = 14,501 lbs ….
    • Apollo Isp = 318 versus Isp = 338 for RS-72
    • Apply to LEM weights, current fractions are …
    • Fuel fraction = .513 ……. Payload fraction = .487
  • Delta II (LLO = 3639 lbs) payload to Lunar Surface = 1,772 lbs
  • Delta IV (LLO = 9,099) payload to Lunar Surface = 4431 lbs !!!!
  • Payload fraction = .487
slide37

Lessons from Apollo*

  • Summary of TLI, LOI, LL
  • TLI fraction = .33 LOI fraction = .887
  • L Landing = .487
  • Delta IV (5,4) puts 25,300 lbs in LEO
  • Lands 4431 pounds on the surface = 17% Payload
  • For our 8,800 pounds of … schtuff, we need 52,000 pounds of fuel
  • @ $5,000 per pound, cost = $258,000,000
slide38

Other Ideas

  • Mars Rover Landing Bag
  • Ion Propulsion
    • ISP = 8,000 vs. 460 for LH2
    • Fuel weight now 4,000 lbs
    • Cost is $20,000,000
slide39

IS THIS REALLY GOING TO HAPPEN ?

US South Pole Research Station

University of Arizona Controlled Environment Ag. Center

http://ag.arizona.edu/ceac/CEACresearch/International/004.htm

slide41

University of Arizona Controlled Environment Ag. Center

Mars Simulation Development Unit

http://ag.arizona.edu/ceac/CEACresearch/International/004.htm
