  1. FI-WARE Overview JuanjoHierro TelefonicaDigital, Coordinator and Chief Architect, FI-WAREjhierro@tid.es, @JuanjoHierro http://www.fi-ppp.eu http://www.fi-ware.eu

  2. The Future Internet Public-Private Partnership (FI-PPP) tourism Transport, Mobility and Logistics • The aim of the FI-PPP is to place Europe in the best position to capture new opportunities in the Future Internet, derived from digitalization of economy sectors • This requires creating an generic, open and standard platform (FI-WARE) around which a dynamic innovation ecosystem can be created engaging developers and entrepreneurs e-government SmartEnergyGrid … eHealth EC provides half of the funding: Industry driven, major industry players involved Pan-european dimension

  3. What is genuine in the FI-PPP • Better suited to align with roadmap of product developments by partners: • Industry- and Implementation-driven approach • Results exploitable in the short-medium term (4-5 years) rather than in the long-term (10-15 years) • Targeted to attract audiencebeyond the research communitywho will be fund to develop applications on top of FI-WARE • Developers • Entrepreneurs • Public Administrations • Commitment for exploitation required: • Commercial offer in the short term; or • Delivery of results in open source otherwise

  4. FI-WARE: positioning Europe towards opportunities derived from the digitalization of sectors A Core Platform that lower the barriers for innovation A sustainable innovation ecosystem Lower the Risk  Open, implementation driven Make it simpler  Simple yet powerful APIs 3

  5. FI-WARE: positioning Europe towards opportunities derived from the digitalization of sectors A Core Platform that lower the barriers for innovation A sustainable innovation ecosystem Lower the Risk  Open, implementation driven Make it simpler  Simple yet powerful APIs 4

  6. FI-WARE GenericEnablers (GEs) • A FI-WARE Generic Enabler (GE): • set of general-purpose platform functions available through APIs • Building with other GEs a FI-WARE Reference Architecture • FI-WARE GE Specifications are open (public and royalty-free • FI-WARE GE implementation (FI-WARE GEi): • Platform product that implements a given GE Open Spec • There might be multiple compliant GEis of each GE Open Spec • Available FI-WARE GEis published on the FI-WARE Catalogue • The FI-WARE project will deliver at least one reference implementation of FI-WARE GEs: • Based upon results of previous R&D projects • Publicly available Technical Roadmapupdated in every release • Licensed with no costs within the FI-PPP program • Commercialized under FRAND conditions or license as open source

  7. FI-WARE: Targeting developers needs What How Connect apps to the physical world IoT-M2M Enablers Manage open data at large scale and transform it into knowledge Built-in APIs & tools Data/Context Enablers Benefit from open innovation(crowd-sourcing, apps composition) Integration and Composition Enablers Business & Delivery Framework (revenue-share, cross-selling, …) Reach target users, monetize Ensuring Privacy, Security and Trust Security Enablers Advanced Cloud Enablers Take the most of infrastructures while keeping costs lower and under control Enablers easing interface to Network and Devices access from everywhere, adapt to devices

  8. FI-WARE: Major Technical Chapters Technical Chapters How IoT Services Enablement IoT-M2M Enablers Built-in APIs & tools Data/Context Management Data/Context Enablers Integration and Composition Enablers Apps/Services Ecosystem & Delivery Business & Delivery Framework (revenue-share, cross-selling, …) Security Security Enablers Advanced Cloud Enablers Cloud Enablers easing interface to Network and Devices I2ND

  9. Take the most of infrastructures while keeping costs lower and under control

  10. VM provisioning

  11. Storage provisioning

  12. Management of Blueprints

  13. Gathering, publishing, processing and analyzing private and open data at large scale

  14. Context • OMA NGSI Context Management is about management of Context data (aka Context Information) • Context Information is always relevant to “entities”, although entities can be anything (applications, users, things, …) Applications ContextBroker

  15. Simple yet powerful interaction model Application subscription_id_1 = subscribe (consumer1, expr1, duration1) updateContext notifyContext ContextBroker 2 ContextConsumer 1 Context Producer query queryContext ContextConsumer 2 registerContext (ContextProvider, what, duration2) ContextProvider (maybeanotherContextBroker) Application

  16. FI-WARE Context/Data Management Platform Applications Processing/AnalysisAlgorithms OMA NGSI-9/10 ContextBroker(Orion/CAP) Gathered data isinjectedforprocessing/analysis Data generatedeitherby CEP orBigDataispublished BigDataAnalysis/Processing (COSMOS) Gathered data injectedfor CEP-likeprocessing Directbigdatainjection DistributedContextSources ComplexEventProcessing - CEP (PROTON) Processed data isinjectedforprocessing/analysis Programming of rules Context/Data Management Platform

  17. Easing connection to the physical world

  18. FI-WARE IoT-M2M & Context/Management altogether Applications FI-WARE NGSI-9/10 Directconnectionforhigher performance (entities: things, other) BigData Analysis Other sources Context Broker IoT-enabled Context Management CEP NGSI IoT Adapter FI-WARE NGSI-9/10 Device-level Management API (entities: things) IoTConfigMan IoT Broker IoT Backend Device Management FI-WARE NGSI-9/10 Backend Backend Native NGSI IoT Agent Native NGSI IoT Agent Gateway/Device Platform GEs Gateway/Device Platform GEs Gateway/Device Platform GEs Gateway/Device Platform GEs

  19. Enabling co-creation through advanced Data/Services Composition and Mashup

  20. Reaching target users, monetize

  21. Architecture of the Apps Chapter

  22. Ensuring Privacy, Security and Trust

  23. Proposal (Accounting+Monitoring) NSN/DT IdM 4 Authentication +Json token 1 request Oauth-Enabled Client App 2 redirecttoIdMOAuth 6 Jsontoken + clientid + clientsecret 5 Jsontoken 7 Access token 11 Access token 8 request + token Accounting + Monitoring 12 Access token + attrib Proxy Keystone PEP 9 requestinfo + token 14 validation result + request info + attrib 10 request info + token 13 validation result + request info + attrib Keystone Middleware Thales RBAC/XACML Asset 15 request Resource

  24. Offering rich web-based user interfaces

  25. Access from everywhere, taking the most of the network and capabilities of devices

  26. … and all … truly Open

  27. FI-WARE Instances • Future Internet Applications run on top of “FI-WARE Instances”that are built by “FI-WARE Instance Providers” upon: • selection of FI-WARE GEis (products) from the FI-WARE Catalogue • assembly of selected FI-WARE GEis with proprietary added-value products Future Internet App FI-WARE Catalogue FI-WARE Instance assemble… FI-WARE GE implementations propietary product

  28. FI-WARE Instances • There is no single universal FI-WARE Instance Future Internet App A Future Internet App B FI-WARE Instance 1 FI-WARE Instance 2 FI-WARE Catalogue

  29. FI-WARE Instances • Offering of several FI-WARE Instances may be combined FI-WARE Instance 3 FI-WARE Instance 1 FI-WARE Instance 2 FI-WARE Catalogue Future Internet App B Future Internet App A

  30. FI-WARE: positioning Europe towards opportunities derived from the digitalization of sectors A Core Platform that lower the barriers for innovation A sustainable innovation ecosystem Lower the Risk  Open, implementation driven Make it simpler  Simple yet powerful APIs 29

  31. Building the FI-WARE ecosystem: the vision Commercial facility FI-WARE Catalogue • 3rd FI-WARE Open Call: • Take up of FI-WARE results by Internet application developers and entrepreneurs • Creation and support of a dynamic innovation ecosystem • Achieve maximum market visibility Instructions for creation of dedicated GE instances Instructions for using Global shared GE instance Common pan-europeanFI-WARE shared facility for Trials (XiFi shared trial facility) Trial 2 FI-Lab (FI-WARE Open Innovation Lab) Specific UC Trial facilities Trial 1 30

  32. FI-LAB (FI-WARE Open Innovation Lab) • FI-LAB will be a case example of a FI-WARE Instance. It: • Provides Cloud hosting capabilities so third parties can run experimental Future Internet Applications and test them • Make Generic Enablers implementations available for experimentation: • Global accessible instances provided “as a Service” • Deployable as dedicated instances by application providers using Cloud blueprint management functions • Will be operated under central control and be accessible from a dedicated website. • Each FI-WARE GEi, as well as the FI-LAB itself, will have a specific support tracker • Users can setup accounts, adhering to certain terms and conditions 31

  33. FI-PPP and 3rd facilities: opportunities to explore Location platform Network of FI-WARE Backend Datacenters ID providers Experimental Facilities (networks) Experimental Facilities (sensors) SMART Home Lab SMART City Lab SMART Biz Lab

  34. What comes next • Ambitious FI-WARE promotion campaign (4,2 M€ investment during May 2013 – April 2014 period) • Launch of the FI-WARE Open Innovation Lab at London Campus Party (September 3-8) • Presence in 50 startup weekend events across Europe • Hackathons, Development contests (870 K€ in awards) • 100 M€ of funding for SMEs and Web entrepreneurs developing products on top of FI-WARE: • to be canalized through incubators, accelerators, SME associations • projects starting in 2014 • Design and deployment of pan-european FI-WARE trial facility to be launch in April 2014 • Proposal for FI-WARE continuation phase (23 M€) 33

  35. Opportunities for all Application sponsors (business, cities, etc) • Connect to innovators • Put their data at work • Visibility, promotion • Costs saving • Better service to customers • Corporate Reputation Entrepreneurs, Developers • Ability to test with real data • Ability to run trials with real users • Visibility, promotion • Hosting of permanent showcase • Connection to potential customers • Acceleration of product development FI-WARE Technology Providers • Added value to just the technology • Connecting to entrepreneurs: Revenue-sharing opportunities

  36. Thanks ! http://fi-ppp.eu http://fi-ware.eu 35
