1. Genitourinary Trauma François Dufresne
McGill Emergency Medicine
February 13th 2002
2. The Case of Jeremy 23 y.o male
Driver, Seatbelted
Frontal Impact, High Speed (? 100Km/h)
Airbag +
Other driver dead
Car completely destroyed
Empty EtOH bottles in the OTHER car
Patient was conscious at the scene.
On scene: BP=85/50 HR:120 RR:22 Sat:98% - Ugences-Santé brings you Jeremy with this story…- Ugences-Santé brings you Jeremy with this story…
3. Jeremy… A: Clear. C-spine protection. Backboard+
B: A/E symetric. O2 Sat N. No crepitus. Trachea central.
C: BP:100/60 HR:100 Mentating well.
D: GCS=15 PERL.
Pt is exposed.
O2 - iv – monitor
Temperature N Capillary Glucose N
4. Jeremy AMPLE
C/O abdo. Pain + “hip” pain
C/O right lower leg pain
Secondary Survey
Spleen normal. Mild suprapubic tenderness.
Pelvic instability
Probable right tibial #
No gross blood at meatus. Rectal Normal.
“Doctor, can I put a Foley?”
5. Jeremy What are your concerns?
Foley?
What will be the usefulness of dipstick?
Dipstick good enough? U/A?
What if he has microscopic hematuria?
What if he has a pelvic fracture?
Any different if you had blood at meatus?
Urethrogram? Cystogram? Abdominal CT?
Worried about the kidneys? Bladder?
Does the low BP changes your suspicion for a GU injury?
- So those are all questions that, I hope, you’ll be able to answer at the end of the presentation.- So those are all questions that, I hope, you’ll be able to answer at the end of the presentation.
6. Introduction GU Trauma overlooked
10-20% of all injured patients
Long term morbidity
Impotence
Incontinence
Life-threatening injuries first GU trauma, because of its very often non life-threatening injuries and its subtle presentation, is very often overlooked and poorly recognized in the emergency departement. However, approximateley 10-20% of all injured patients have some kind of GU involvement which can lead to very debilitating long term sequalae such as incontinence and impotence.
Although the more life-threatening injuries of the primary survey must be addressed first, we must be alert to the clues pointing to the presence of GU injuries.
So in the OVERALL management of all trauma patients, it is very important that we have a complete understanding of GU injuries, how to deal with it and how it can impact on patient outcome.
Being good at managing trauma patients doesn’t only mean being good at putting chest tubes. GU trauma, because of its very often non life-threatening injuries and its subtle presentation, is very often overlooked and poorly recognized in the emergency departement. However, approximateley 10-20% of all injured patients have some kind of GU involvement which can lead to very debilitating long term sequalae such as incontinence and impotence.
Although the more life-threatening injuries of the primary survey must be addressed first, we must be alert to the clues pointing to the presence of GU injuries.
So in the OVERALL management of all trauma patients, it is very important that we have a complete understanding of GU injuries, how to deal with it and how it can impact on patient outcome.
Being good at managing trauma patients doesn’t only mean being good at putting chest tubes.
7. Plan Urethral Injury
Bladder Injury
Hematuria in Trauma
Kidney Injury - So I’m going to talk about the different method of investigations, the evidence behind it and the management of the different injuries.
- Hematuria: I’m going to review the evidence behind what we do or should do.
- I will not talk about uretheral because it is rare and usually from penetrating injuries (and I want to focus on blunt trauma). I will not talk also about external genitalia injuries because this is probably a talk in itself, obvious on exam and usually left to the urologist.- So I’m going to talk about the different method of investigations, the evidence behind it and the management of the different injuries.
- Hematuria: I’m going to review the evidence behind what we do or should do.
- I will not talk about uretheral because it is rare and usually from penetrating injuries (and I want to focus on blunt trauma). I will not talk also about external genitalia injuries because this is probably a talk in itself, obvious on exam and usually left to the urologist.
8. Definitions Upper tract
Kidney
Ureters
Lower tract
Bladder
Urethra
External genitalia for purposes of investigation and staging of urologic injuries, GU traum is divided into…
Each category is futher subdivided on the basis of a blunt or penetrating mechanism of injury.
I’m going to focus on BLUNT trauma during my talk.for purposes of investigation and staging of urologic injuries, GU traum is divided into…
Each category is futher subdivided on the basis of a blunt or penetrating mechanism of injury.
I’m going to focus on BLUNT trauma during my talk.
9. Urethral Trauma Almost exclusively in male
Significant morbidity
Stricture
Incontinence
Impotence
If unrecognized:
Converting partial to complete tear
Inaccurate assessment of U/O
Foley catheter implication
Female: severe pelvic fracture and bony displacement along with lacerations through the bladder neck and vagina are present in cases of urethral trauma.
Morbidity: 15% (stress) incontinence in this study by Andrich: Men from 19-51! In previous studies, depending on the method used to repair the urethra, the rate of Incontinence/impotence is up to 70%, needing RE-operation to correct the problem.
Journal of Urology, 1996 Oct.: Stricture:49-97%. Impotence:0-36%. Incontinence: 0-21%. (Impotence and incontinence is a complication of procedures with less strictures.
…and as you learned in your ATLS, Foley catheter is C.-I. if you suspect urethral trauma.Female: severe pelvic fracture and bony displacement along with lacerations through the bladder neck and vagina are present in cases of urethral trauma.
Morbidity: 15% (stress) incontinence in this study by Andrich: Men from 19-51! In previous studies, depending on the method used to repair the urethra, the rate of Incontinence/impotence is up to 70%, needing RE-operation to correct the problem.
Journal of Urology, 1996 Oct.: Stricture:49-97%. Impotence:0-36%. Incontinence: 0-21%. (Impotence and incontinence is a complication of procedures with less strictures.
…and as you learned in your ATLS, Foley catheter is C.-I. if you suspect urethral trauma.
10. Anatomy Male urethra divided into four segments:
Protatic urethra
urogenital diaphragm: Membranous urethra
Bulbous urethra
Pendulous urethraMale urethra divided into four segments:
Protatic urethra
urogenital diaphragm: Membranous urethra
Bulbous urethra
Pendulous urethra
11. important anatomical features: - urogenial diaphragm attaches to bones of pelvis
- prostate attaches to symphysis pubis by puboprostatic ligaments.
Important to differentiate anterior VS posterior because injuries are caused by different mechanisms, involve different symptoms and are treated differently.
important anatomical features: - urogenial diaphragm attaches to bones of pelvis
- prostate attaches to symphysis pubis by puboprostatic ligaments.
Important to differentiate anterior VS posterior because injuries are caused by different mechanisms, involve different symptoms and are treated differently.
12. Posterior Urethra Violent external force
Pelvic # in ? 90%
Pelvic # : 5-25% of Posterior urethral injury
Pelvic # in 80-95%
Pelvic # in 80-95%
13. Clinical Features Gross hematuria in 98%
Inability to void
Blood at urethral meatus
Pelvic / suprapubic tenderness
Penile / scrotal / perineal hematoma
Boggy / high-riding prostate/ ill-defined mass on rectal examination. inability to void…actually you tell them not to do so !
Physical findings can be minimal because the bladder neck remains competent.
…=urethral injury until proven otherwise : NO FOLEYinability to void…actually you tell them not to do so !
Physical findings can be minimal because the bladder neck remains competent.
…=urethral injury until proven otherwise : NO FOLEY
14. Digital Rectal Exam in Trauma Porter et al. Am Surg, 2001.
Prospective
Level II Trauma Center.
423 patients.
DRE on all.
7 (1.7%) pelvic fracture. NO Urethral injury
Prostate exam didn’t change management
This study that was looked at in one of the Journal Watch…
But…patients less sick (level II), less GU injuries/pelvic fracture…
So if you here in the future people quoting this study to argue about the uselessness of the rectal exam, keep in mind that these patients were not the sickest ones.This study that was looked at in one of the Journal Watch…
But…patients less sick (level II), less GU injuries/pelvic fracture…
So if you here in the future people quoting this study to argue about the uselessness of the rectal exam, keep in mind that these patients were not the sickest ones.
15. Posterior Urethral rupture - so the rationale behind the findings on rectal exam…- so the rationale behind the findings on rectal exam…
16. Diagnosis:Retrograde Urethrogram Pretest KUB film
Supine position
Injection of 25ml of water-soluble contrast
Different techniques
X-ray when 10ml left and after 25ml
Post-voiding x-ray.
KUB to identify pelvic fracture, bony displacement, foreign objects.
Christmas tree adapter on the end of a 60cc syringe.KUB to identify pelvic fracture, bony displacement, foreign objects.
Christmas tree adapter on the end of a 60cc syringe.
17. Retrograde Urethrogram
18. Retrograde Urethrogram:Interpretation Contrast extravasation + Contrast in bladder
Contrast extravasation only -limits: spasm of urether can limit extravasation or passage in bladder.
TYPE I: Stretching/Elongation of urethra
TYPE II: Partial or complete rupture of prostatomembranous urethra: extravasation above urogenital diaphragm (pelvis)
TYPE III: Partial or complete rupture of prostatomembranous urethra + rupture of urogenital diaphragm and bulbous urethra: extravasation in pelvis AND perineum. (2X as common and more severe).
TYPE IV: Bladder neck involved
TYPE V: ONLY anterior urethra.-limits: spasm of urether can limit extravasation or passage in bladder.
TYPE I: Stretching/Elongation of urethra
TYPE II: Partial or complete rupture of prostatomembranous urethra: extravasation above urogenital diaphragm (pelvis)
TYPE III: Partial or complete rupture of prostatomembranous urethra + rupture of urogenital diaphragm and bulbous urethra: extravasation in pelvis AND perineum. (2X as common and more severe).
TYPE IV: Bladder neck involved
TYPE V: ONLY anterior urethra.
19. Partial Tear
20. Complete Tear
21. Management Partial tear
careful passage of 12-14 Fr. Foley.
If any resistance: Urology
Complete tear:
Urology + suprapubic cath.
If Foley already there and suspect tear:
LEAVE FOLEY IN PLACE
Small tube alongside the foley
Angiocath 16-gauge
Modified urethrogram
22. Management…by Urology Controversial
Complete VS Partial
Posterior VS Anterior
Foley X 3-14 days
Suprapubic catheters
Surgical approach / Endoscopy
Delayed repair usually - I don’t want to get into the details because this is obviously not our field anymore…- I don’t want to get into the details because this is obviously not our field anymore…
23. Foley Catheter NO if you suspect a urethral injury
Most of urethral injuries:
Pelvic # or Gross hematuria
Initial bladder effluent MUST be looked at.
Danger to convert partial into complete
Successful passage ? complete tear
NEVER REMOVE A FOLEY WHEN YOU SUSPECT A PARTIAL TEAR AFTERWARDS.
ANY colored urine other that yellow
again, if you have any of the physical findings mentionned earlier, you MUST suspect a urethral injury and you CAN’T put a foley until you have proved that the urethra is intact.
..=blood…of course, severe rhabdomyolysis can produce large amount of myoglobin, there’s hemoglobinuria, food/Rx…
again, if you have any of the physical findings mentionned earlier, you MUST suspect a urethral injury and you CAN’T put a foley until you have proved that the urethra is intact.
..=blood…of course, severe rhabdomyolysis can produce large amount of myoglobin, there’s hemoglobinuria, food/Rx…
24. important anatomical features: - urogenial diaphragm attaches to bones of pelvis
- prostate attaches to symphysis pubis by puboprostatic ligaments.
Important to differentiate anterior VS posterior because injuries are caused by different mechanisms, involve different symptoms and are treated differently.
important anatomical features: - urogenial diaphragm attaches to bones of pelvis
- prostate attaches to symphysis pubis by puboprostatic ligaments.
Important to differentiate anterior VS posterior because injuries are caused by different mechanisms, involve different symptoms and are treated differently.
25. Anterior Urethra More common than posterior
Direct trauma
Usually NO pelvic #
Blood at meatus
Unable to micturate
Penile/Scrotal/Perineal
Contusion
Hematoma
Fluid collection - bulbous injury is the most common urethral injury
- direct trauma so history is very suggestive (fall astride a bicycle, post, etc.)- bulbous injury is the most common urethral injury
- direct trauma so history is very suggestive (fall astride a bicycle, post, etc.)
26. Sleeve Hematoma Penile injury confined by Buck’s fascia. Corporal rupture during intercourse. Scrotum normal.
SLEEVE hematoma.Penile injury confined by Buck’s fascia. Corporal rupture during intercourse. Scrotum normal.
SLEEVE hematoma.
30. Butterfly Hematoma Anterior urethral rupture through Buck’s fascia confined by Colles’ fascia.
Anterior urethral rupture through Buck’s fascia confined by Colles’ fascia.
31. Anterior Urethral Rupture - Urine filling penis and scrotum and extending into abdomen beneath Scarpa’s fascia. No extension into thigh.- Urine filling penis and scrotum and extending into abdomen beneath Scarpa’s fascia. No extension into thigh.
32. Testicular hematoma (right testicle) in the dromedary. This is usually caused by testicular trauma due to fighting with other males
I think that from now on I will not say: “As equiped as a horse” but: “as equiped as a dromedary” !!!
Testicular hematoma (right testicle) in the dromedary. This is usually caused by testicular trauma due to fighting with other males
I think that from now on I will not say: “As equiped as a horse” but: “as equiped as a dromedary” !!!
33. Anterior Urethra:Management NO Foley if injury suspected
Retrograde Urethrogram
Urology:
Surgical Treatment - very similar to posterior injury for an Emerg point of view.- very similar to posterior injury for an Emerg point of view.
34. Bladder Trauma Adult: Extraperitoneal organ
Bladder dome = weakest point
Blunt: 60-85%
MVA: #1 cause
Important to recognize
Pelvic/abdominal wall abscess/necrosis
Peritonitis
Intra-abdominal abscess
Sepsis / Death
Peds: Intraperitoneal until 6 y.o
Better protection in adult b/c it is in the pelvis. In peds, it is higher.
Bladder dome… this is were the peritoneum is adjacent to the bladder…
Peds: Intraperitoneal until 6 y.o
Better protection in adult b/c it is in the pelvis. In peds, it is higher.
Bladder dome… this is were the peritoneum is adjacent to the bladder…
35. - There is a close relationship between the dome of the bladder and the peritoneal cavitiy.- There is a close relationship between the dome of the bladder and the peritoneal cavitiy.
36. Types of rupture Extraperitoneal
Most common
Pelvic # in 89-100%
Bladder rupture in 5-10% of all pelvic #
Intraperitoneal
Extravasation of urine in abdomen
Sudden force to full bladder
Associated injuries +++ Mortality (20%)
pelvic #…thought to be a spicule of bone. Also: tear at ligamentous attachement / force of blunt trauma
Extraperitoneal: urine collects in perivesicular space
Increased intraluminal pressure and rupture at the WEAKEST point of bladder.
Associated injuries not more frequent but more severe (40% of cases).
Combined: 10% with mortality up to 60%
pelvic #…thought to be a spicule of bone. Also: tear at ligamentous attachement / force of blunt trauma
Extraperitoneal: urine collects in perivesicular space
Increased intraluminal pressure and rupture at the WEAKEST point of bladder.
Associated injuries not more frequent but more severe (40% of cases).
Combined: 10% with mortality up to 60%
37. Clinical Presentation
98% : Gross hematuria
2%: Microscopic hematuria + Pelvic #
100%: Gross hematuria
85% Pelvic #
Hx and P/E: non specific. As discussed before, low abdo pain, inability to void, ecchymosis over suprapubic and pelvic region, …
Cystography: MUST R/O urethral injury before putting Foley in.Hx and P/E: non specific. As discussed before, low abdo pain, inability to void, ecchymosis over suprapubic and pelvic region, …
Cystography: MUST R/O urethral injury before putting Foley in.
38. Investigation Cystography: Gold standard
CT Cystography : New trend
Peng et al. AJR 1999.
Prospective study
55 patients. 5 bladder rupture
Cystography VS. CT cystography
Ruptures confirmed by Surgery
100% sensitive and specific
39. Investigation… Deck et al. Journal of Urology, 2000.
Retrospective study
316 patients with CT Cystography
Sensitivity/Specificity = 95% and 100%
But 78% and 99% for intraperitoneal rupture
Comparable to Cystography alone
Identifies other injuries
40. Standard Helical CT Pao et al. Acad Radiol 2000.
With IV contrast
Misses bladder rupture
100% sensitive if “free fluid” criteria used.
Can R/O bladder injury if NO free fluid.
Not specific.
Not accepted as diagnostic tool. - Some people thought: « Well, if we’re gonna do a CT for abdominal injury, maybe it will pick up bladder injuries as well ».- Some people thought: « Well, if we’re gonna do a CT for abdominal injury, maybe it will pick up bladder injuries as well ».
41. Treatment Penetrating injuries: OR
Blunt
Intraperitoneal: Almost all OR
Extraperitoneal: Urethral cath. drainage x 7-10 days.
42. Hematuria Hardeman and al. Journal Urol, 1987.
Prospective study
506 patients
IVP in all. CT/arteriography/O.R. PRN
Shock: BPs<90 at any time
25 Injuries
ALL had either
Gross hematuria
Shock + microhematuria Before I get to the kidney injuries, I want to talk about Hematuria in the context of trauma. What’s the evidence, how should interpret that and what should we do with it.
Injuries: 15 kidney, 8 bladder, 2 urethra.
Before I get to the kidney injuries, I want to talk about Hematuria in the context of trauma. What’s the evidence, how should interpret that and what should we do with it.
Injuries: 15 kidney, 8 bladder, 2 urethra.
43. Hardeman et al. … 365 (52 %) had microhematuria only
174 D/C’ed , F/U and no problem
191 admitted
1 renal contusion (Grade I)
2 minor lacerations (Grade II)
No complication
44. Mee et al. Journal Urol, 1989 Prospective
1146 patients
IVP = Gold standard
ALL significant renal injuries had either:
Gross hematuria
Microscopic hematuria + shock
Intensity of hematuria ? Severity of injury A name to remember is « Mee et al. » From San Francisco who did a lot of work on this topic and who is referred to in all the papers discussing this issue.
shock: in the field OR in EDA name to remember is « Mee et al. » From San Francisco who did a lot of work on this topic and who is referred to in all the papers discussing this issue.
shock: in the field OR in ED
45. Gross « Hematuria »: False + Alphamethyldopa
Ibuprofen
Levodopa
Metronidazole
Nitrofurantoin
Phenazopyridine
Phenolphtalein-containing laxatives
Rifampin
Beets/berries
46. Microscopic hematuria… 8 major studies
3406 adult blunt trauma with microscopic hematuria and NO shock.
0.23% major renal injuries (?gradeII)
No imaging necessary for that group
F/U 3-4 weeks to R/O underlying pathology.
BUT…
47. Microscopic hematuria… Patients with pelvic # often excluded from studies.
Penetrating trauma excluded.
Pediatric population excluded
« Rapid Deceleration injuries »
Urinalysis on FIRST urine.
Pelvic # : urethral or bladder injuries usually. Most are Renal injuries ONLY. +/- Can’t extend to urethral/bladder injuries.
Penetrating trauma = imaging if suspect injury
Peds: I will not get into the details, but any child with suspected kidney injury and hematuria (even if microscopic (>50 RBC/hpf) and NO shock) needs imaging.
Not the 3rd urine because nobody told the patient or someone threw it away in the sink…
So what if the nurse tells you that there is “trace” of blood…do you rely on it? Do you have to spin it?Pelvic # : urethral or bladder injuries usually. Most are Renal injuries ONLY. +/- Can’t extend to urethral/bladder injuries.
Penetrating trauma = imaging if suspect injury
Peds: I will not get into the details, but any child with suspected kidney injury and hematuria (even if microscopic (>50 RBC/hpf) and NO shock) needs imaging.
Not the 3rd urine because nobody told the patient or someone threw it away in the sink…
So what if the nurse tells you that there is “trace” of blood…do you rely on it? Do you have to spin it?
48. Dipstick vs. U/A Daum et al. AM J Clin Pathol, 1988.
Prospective
178 patients
Abdominal Trauma
Dipstick AND Microscopic examination Vs. U/A…in the context of trauma…Vs. U/A…in the context of trauma…
49. Daum et al. some authors define it as more than 5, some more that 10 and some don’t define it at all!
Normal excretion of RBC in urine corresponds to about 2-3 RBC/hpf. Recommendations today: >5 RBC/hpf.
A false positive dipstick result for red blood cells may occur in the presence of either hemolysis (hemoglobinuria) or myoglobinuria. A false-negative result may occur if the patient is taking either vitamin C or captopril. (Emerg Clinic North Am, august 2001).
When in contact with an organic peroxidase substrate, hemoglobin catalyzes the reaction and causes subsequent oxidation of a chromogen indicator, which changes color according to the degree and amount of oxidation.
recent ingestion of large amounts of vitamin C inhibits peroxidase reaction.
some authors define it as more than 5, some more that 10 and some don’t define it at all!
Normal excretion of RBC in urine corresponds to about 2-3 RBC/hpf. Recommendations today: >5 RBC/hpf.
A false positive dipstick result for red blood cells may occur in the presence of either hemolysis (hemoglobinuria) or myoglobinuria. A false-negative result may occur if the patient is taking either vitamin C or captopril. (Emerg Clinic North Am, august 2001).
When in contact with an organic peroxidase substrate, hemoglobin catalyzes the reaction and causes subsequent oxidation of a chromogen indicator, which changes color according to the degree and amount of oxidation.
recent ingestion of large amounts of vitamin C inhibits peroxidase reaction.
50. Dipstick vs. U/A Chandhoke et al. J Urol, 1988.
Prospective study
339 patients
Suspected blunt renal trauma
Dipstick AND microscopic examination
51. Chandhoke et al. Specificity very low (<60%). So if positive, always confirm with U/A.
So the message to take home is that anything on the dipstick that’s more than trace: U/ASpecificity very low (<60%). So if positive, always confirm with U/A.
So the message to take home is that anything on the dipstick that’s more than trace: U/A
52. Kidney Injury Retroperitoneal organ
Cushoned by perinephric fat
Gerota’s fascia
Along T10 - L4
Ribs 10-12
Fixed only through pedicle.
1.2L of blood / min
53. Kidney Injury… Blunt trauma: 80-90%
Rapid deceleration / Direct blow
MUST be suspected if
Trauma to back / flank / lower thorax / upper abdomen
Flank pain / low rib #
Hematuria / Ecchymosis over the flanks
Sudden decelaration / Fall from height.
Lumbar transverse process # - However, 5-10% will NOT have hematuria…- However, 5-10% will NOT have hematuria…
54. Lumbar Transverse Process Fractures Prospective study (1994-1999)
Lumbar spine #
191 patients
Transverse # in 29%
Abdominal organ injuries 47% vs. 6%
Kidney: 1/3
Liver: 1/3
Spleen: 1/4
abdominal organ injuries…I don’t need to tell you that it was statistically significant…
Correlated by another study: Patten et al. Frequency and Importance of Transverse Process Fractures in the Lumbar Vertebrae at Helical Abdominal CT in patients with Trauma. Radiology; 215:831-834; 2000.abdominal organ injuries…I don’t need to tell you that it was statistically significant…
Correlated by another study: Patten et al. Frequency and Importance of Transverse Process Fractures in the Lumbar Vertebrae at Helical Abdominal CT in patients with Trauma. Radiology; 215:831-834; 2000.
55. Classification of Injury 5 Classes of Renal Injury : - created by the American Association for the Surgery of Trauma.- created by the American Association for the Surgery of Trauma.
56. Grade I Contusion
Hematuria
Urologic studies N
Hematoma
Subcapsular
Non expanding
Parenchyma N
57. Grade II Hematoma
Perirenal
Nonexpanding
Laceration
< 1.0 cm
Renal cortex only
No urinary extravasation
58. Grade III
Laceration
> 1.0 cm
Renal cortex only
No urinary extravasation
Intact collecting system
59. Grade IV Laceration
Renal cortex
Renal medulla
Collecting system
Vascular
Main renal artery/vein injury with contained hemorrage.
60. Grade V Completely shattered kidney.
Avulsion of renal hilum (pedicule) which devascularizes kidney.
61. Pedicule Injury -The adventice and the media being much more elastic than your intima, they stretch but the intima tears.-The adventice and the media being much more elastic than your intima, they stretch but the intima tears.
62. Organ Injury Severity Scale Validated lately: Journal of Trauma, 2001
Predicts the need for surgery
Need for surgery ; nephrectomy rates:
Grade I: 0 ; 0%
Grade II: 15 ; 0%
Grade III: 76 ; 3%
Grade IV: 78 ; 9%
Grade V: 93 ; 86%
63. Investigation IVP
Used to be intial exam of choice.
Very poor sensitivity for penetrating injury
Limitation in staging renal injuries
Not 1st choice anymore. Only if pt unstable.
Contrast CT
Study of choice if stable
More sensitive and specific for staging
Detects other abdominal injuries Angiography reserved for inconclusive CT.Angiography reserved for inconclusive CT.
64. Management Penetrating trauma:
Imaging for ALL (9%: NO hematuria)
Blunt trauma Imaging:
Gross hematuria
Microscopic hematuria (?5 RBC/hpf) + shock (BPs?90)
Any child with > 50 RBC / hpf penetrating trauma with suspected renal injury (location of wound, direction of projectile…)
Shock in the field OR in the ED.penetrating trauma with suspected renal injury (location of wound, direction of projectile…)
Shock in the field OR in the ED.
65. Management… Absolute indication for Surgery:
Uncontrollable renal hemorrage
Multiply lacerated, shattered kidney
Main renal vessels avulsed
Penetrating injuries usually
Grade I-II
conservative
Grade III-IV
Conservative if stable hemodynamically vs. surgery
Grade V
Surgery
67. Back to Jeremy… First urine: Dipstick +++ (15 RBC/hpf)
Pelvic x-ray: Straddle #
69. Jeremy… First urine: Dipstick +++ (15 RBC/hpf)
Pelvic x-ray: Straddle #
Keypoints…
BP: 85/50 on scene
Microhematuria
Pelvic #
NO FOLEY
-What are you worried about now? Answer: URETHRA +/- Bladder…but also kidney (shock).-What are you worried about now? Answer: URETHRA +/- Bladder…but also kidney (shock).
70. Jeremy… Urology consulted
Retrograde urethrogram: N
CT cystogram: N
Contrast CT to look for renal injury: Grade II renal injury.
71. Conclusion No Foley if you suspect urethral trauma
Gross hematuria OR microhematuria + Shock = GU Trauma.
Pelvic # + Microhematuria GU investigation
Don’t remove Foley if you suspect a partial tear of urethra afterwards.
Microhematuria alone : No imaging …but F/U.
In peds: Imaging for ALL hematuria. To be excellent at dealing with a trauma patient doesn’t only mean to be good at taking care of the difficult airway and putting chest tubes, though more spectacular.
To be excellent at dealing with a trauma patient doesn’t only mean to be good at taking care of the difficult airway and putting chest tubes, though more spectacular.
72. The End
